AN-80i System
PTP & PMP
User Manual
70-00072-01-07
Proprietary Redline Communications © 2010
Page 1 of 106
Sept 18, 2008

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AN80IE and is the answer not in the manual?

Questions and answers

Related Manuals for Redline Communications AN80IE

Summary of Contents for Redline Communications AN80IE

  • Page 1 & AN-80i System PTP & PMP User Manual 70-00072-01-07 Proprietary Redline Communications © 2010 Page 1 of 106 Sept 18, 2008...
  • Page 2 All rights reserved Sept 18, 2008. The information in this document is proprietary to Redline Communications Inc. This document may not in whole or in part be copied, reproduced, or reduced to any medium without prior consent, in writing, from Redline Communications Incorporated.

  • Page 3: Table Of Contents

    System Configuration Screen..............30 Ethernet Configuration ............... 30 Wireless Configuration ............... 33 Controls ..................... 38 Users Management ................39 AN-80i Product Options Screen ............. 41 Upload Software ..................42 70-00072-01-07 Proprietary Redline Communications © 2010 Page 3 of 106 Sept 18, 2008...
  • Page 4 CLI Command Summary ................ 66 Connecting with Telnet ................67 CLI Command Set ................. 67 5.3.1 Chgver ....................67 5.3.2 Clear ....................68 5.3.3 Del ..................... 68 5.3.4 Enable ....................68 70-00072-01-07 Proprietary Redline Communications © 2010 Page 4 of 106 Sept 18, 2008...
  • Page 5 3.650 - 3.700 GHz Radio: FCC & IC Antennas ........98 Regional Codes ..................99 Security Keys and Certificates ............. 101 Security Certificate and Key CLI Commands ........102 70-00072-01-07 Proprietary Redline Communications © 2010 Page 5 of 106 Sept 18, 2008...
  • Page 6 Table 41: CLI - upgrade ..................83 Table 42: CLI - user ................... 83 Table 43: CLI - whoami ..................83 Table 44: Diag. - Factory Default Settings ............84 70-00072-01-07 Proprietary Redline Communications © 2010 Page 6 of 106 Sept 18, 2008...
  • Page 7 Table 65: Security -- Runtime Keys and Certificates ........102 Table 66: Security -- User Key and Certificate Files......... 102 Table 67: Spec. - Glossary ................104 70-00072-01-07 Proprietary Redline Communications © 2010 Page 7 of 106 Sept 18, 2008...
  • Page 8 Figure 37: CLI - Connecting via Telnet .............. 67 Figure 38: CLI - Recovering Lost IP Address ............. 85 Figure 39: Diag: - Saving Parameters in NVRAM ..........86 70-00072-01-07 Proprietary Redline Communications © 2010 Page 8 of 106 Sept 18, 2008...

  • Page 9: Important Safety & Service Notices

    AN-80i, mast, lead-in wire and discharge unit, location of discharge unit, size of grounding conductors and connection requirements for grounding electrodes. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 9 of 106 Sept 18, 2008...

  • Page 10: Important Warning Symbols

    The remaining energy on the Ethernet cable shield and center conductor can be directed safely to ground by using a lightning arrestor in series with the cable. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 10 of 106 Sept 18, 2008...

  • Page 11: Deployment In The Usa -- Fcc Notices

    Warning: Changes modifications expressly approved Redline Communications could void the user’s authority to operate the equipment. Refer to section 7.6: FCC & IC Certified Antennas for additional information. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 11 of 106 Sept 18, 2008...

  • Page 12: Installation And Operation

    3650-3700 MHz. The AN-80i outdoor transceiver and antenna must be professionally installed. Changes or modifications not expressly approved by Redline Communications could void the user’s authority to operate the equipment. Do not operate an AN-80i outdoor transceiver until you have confirmed the FCC- specific options key is loaded and active (operating range restricted to 3650-3700 MHz).

  • Page 13: Ul Information

    Use the following table to record important system information: Product Information AN-80i SN: MAC Address PoE SN: Model #: Antenna Model No.: Antenna SN: Serial Number Stickers 70-00072-01-07 Proprietary Redline Communications © 2010 Page 13 of 106 Sept 18, 2008...

  • Page 14: System Overview

    Manual AN-80i Chapter The Access Node 80i system is manufactured by Redline Communications -- a world leader in design and production of Broadband Fixed Wireless (BFW) systems. Figure 1: Intro - AN-80i Components The AN-80i is a high-performance, high-speed wireless Ethernet bridge for use in a commercial, industrial, business, or government environment.

  • Page 15: Ethernet Port

    (four-point) antenna mounting bracket is available for mounting two foot flat panel and parabolic antennas. Grounding Connection A ground-lug is provided on the AN-80i chassis. Use this connection to terminate a grounding wire. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 15 of 106 Sept 18, 2008...

  • Page 16: Indoor Power Block (Poe Power Adapter)

    Figure 3: Intro - Indoor Power-over-Ethernet (PoE) Module - AC Model 2.5.2 DC Power Adapter The DC power adapter input is auto-sensing 18 - 60 VDC. Figure 4: Intro - Indoor Power-over-Ethernet (PoE) Module - DC Model 70-00072-01-07 Proprietary Redline Communications © 2010 Page 16 of 106 Sept 18, 2008...

  • Page 17: Antenna Alignment

    It is recommended to monitor the RSSI measurements to achieve maximum signal strength when performing fine adjustments to the subscriber antenna. Refer to the AN-80i Installation Guidelines for detailed instructions. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 17 of 106 Sept 18, 2008...

  • Page 18: Web Interface - Ptp

    If the IP address, or the user name and password cannot be determined. See section 6.2: Procedure to Restore Factory Settings on page 85. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 18 of 106 Sept 18, 2008...

  • Page 19: System Menu

    Figure 6: Web - System Menu The administrator (admin) has unrestricted access to all screens. All other users have viewing access only. See 3.7: Users Management on page 39 for details. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 19 of 106 Sept 18, 2008...

  • Page 20: System Information

    Re-align the antenna. remote system. Wireless Signal LED The wireless signal LED lights when a wireless link is established. Signal indications are different based on the Adaptive Modulation setting: 70-00072-01-07 Proprietary Redline Communications © 2010 Page 20 of 106 Sept 18, 2008...

  • Page 21: Table 3: Wireless Signal Led Indication

    The connected Ethernet device is If the AN-80i is connected to a host operating at 10Base-T. computer or server operating at 10Base-T, this is normal operation. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 21 of 106 Sept 18, 2008...

  • Page 22: Table 7: Ethernet Link/Collision Led Diagnostics

    Collision and duplex settings. If manual settings are Incompatible Ethernet port (FD LED not available, both devices must be set to speed. blinks) auto-negotiate. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 22 of 106 Sept 18, 2008...

  • Page 23: General Information

    Software Version: Displays the software version in use. Time Since System Start: Time since the system was last reset/powered-on. Start Up Time: Time and date the system was last reset/powered-on. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 23 of 106 Sept 18, 2008...

  • Page 24: Ethernet

    Yes - RF link successfully established with remote-end AN-80i. No - RF link not established with remote-end AN-80i. Uncoded Burst Rate: The current uncoded burst rate for the link. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 24 of 106 Sept 18, 2008...

  • Page 25: System Status

    RF Channel Frequency: User-assigned RF channel. Tx Power: The current transmit power level. If ATPC is enabled, this value may be different than the Tx Power setting in the screen. System Configuration 70-00072-01-07 Proprietary Redline Communications © 2010 Page 25 of 106 Sept 18, 2008...

  • Page 26: Ethernet Lan Statistics

    (discarded by remote-end due to errors). Controls Reset Statistics: Click this button to zero the counters for the wireless and Ethernet LAN Statistics displayed on this page. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 26 of 106 Sept 18, 2008...

  • Page 27: System Logs Screen

    Options Key Properties Load: OK 1017 Options Key Properties Save: OK 1018 Options Key Activated: OK 1019 Data server started: OK 1021 Upgrade: OK 1023 Firmware configuration: OK 70-00072-01-07 Proprietary Redline Communications © 2010 Page 27 of 106 Sept 18, 2008...
  • Page 28 Options Key Properties Save: Error 2018 Options Key Activated: Error 2019 No Options Key 2020 Fail to start the data server 2021 Data server 2022 Data server 70-00072-01-07 Proprietary Redline Communications © 2010 Page 28 of 106 Sept 18, 2008...
  • Page 29 Int Procs start: Error 2047 ID action not possible 2048 ID validation: Error 2049 HW validation: Error 2050 FTP: Error 2051 RF frequency validation: Error 2099 Unknown Message 70-00072-01-07 Proprietary Redline Communications © 2010 Page 29 of 106 Sept 18, 2008...

  • Page 30: System Configuration Screen

    Contact: Enter additional descriptive details about this AN-80i. The name may be up to thirty (30) alpha-numeric characters including a-z, A-Z, 0-9, dash (-), and underscore (_). 70-00072-01-07 Proprietary Redline Communications © 2010 Page 30 of 106 Sept 18, 2008...

  • Page 31: Table 9: Web - 802.1P Priority Settings

    Ethernet devices are configured for auto-negotiate. Duplex mismatches may result in an unexpected loss of communications. It is recommended to manually configure Ethernet devices to 100Base-T / full duplex. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 31 of 106 Sept 18, 2008...
  • Page 32 VLAN ID. Important: The VLAN network support should be verified before enabling this feature to ensure the AN-80i system will be reachable using the VLAN tagged traffic. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 32 of 106 Sept 18, 2008...

  • Page 33: Wireless Configuration

    AN-80i PTP Master. When the Auto Scan field is checked, click on the blue text adjacent to the check box to display Frequency Ranges 70-00072-01-07 Proprietary Redline Communications © 2010 Page 33 of 106 Sept 18, 2008...

  • Page 34: Figure 13: Web - Wireless Configuration Screen

    Slave has deregistered and is scanning for a PTP Master. This list is not saved permanently, and is discarded when the PTP Slave is rebooted. Reload: Display the saved (Local) scan intervals. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 34 of 106 Sept 18, 2008...

  • Page 35: Table 10: Maximum Tx Power Settings (Dbm) For An-80I Radio

    Appendices professional installer. See section 7: for a list the maximum transmit power setting based on the antenna gain for a series of frequency settings. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 35 of 106 Sept 18, 2008...
  • Page 36 Modulation Reduction Level: Enter the number of modulation/coding levels to step down during re-transmission of errored wireless packets. Each step down lowers the UBR. The level can be set from 0 to 7 (recommended value = 2). 70-00072-01-07 Proprietary Redline Communications © 2010 Page 36 of 106 Sept 18, 2008...

  • Page 37: Table 11: Web - Ethernet Status Indication

    Redline 64-bit: Redline proprietary encryption scheme, compatible with AN-50e. AES 128-bit: Advanced Encryption Standard using 128-bit encryption. AES 192-bit: Advanced Encryption Standard using 192-bit encryption. AES 256-bit: Advanced Encryption Standard using 256-bit encryption. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 37 of 106 Sept 18, 2008...

  • Page 38: Controls

    Def Cfg: Click this button to change all configuration settings to factory default values. Chg Ver: Click this button to toggle between software versions (on next reboot). 70-00072-01-07 Proprietary Redline Communications © 2010 Page 38 of 106 Sept 18, 2008...

  • Page 39: Users Management

    Admin Password: Enter the administrator password (security feature). Change: Click the Change button to make these changes effective. Add User Use this dialog to add a new user. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 39 of 106 Sept 18, 2008...

  • Page 40: Table 12: Web - Screens And User Access

    The following table lists the default login names and passwords. Table 13: Web - Default System Users Group User Name Default Password user user user admin admin admin 70-00072-01-07 Proprietary Redline Communications © 2010 Page 40 of 106 Sept 18, 2008...

  • Page 41: An-80I Product Options Screen

    3 Mbps UBR, DFS permanently enabled, region based common frequency range, no enhanced options (i.e., AES). 3. A valid options key must be entered to enable PMP mode operation. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 41 of 106 Sept 18, 2008...

  • Page 42: Upload Software

    When the transfer has completed successfully, use the System Configuration screen to select which software version to load on the next system reboot (does not switch automatically following upload). 70-00072-01-07 Proprietary Redline Communications © 2010 Page 42 of 106 Sept 18, 2008...

  • Page 43: Snmp Settings Screen

    Port: Destination port address associated with this SNMP alarm. Community: Community associated with this SNMP alarm. Chg: Click the Chg button to modify the settings for the adjacent entry. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 43 of 106 Sept 18, 2008...

  • Page 44: 3.10.1 Change Snmp Community

    This action does not permanently save changes. To save changes to the community settings you must also click the Save Comm button in the SNMP Configuration screen. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 44 of 106 Sept 18, 2008...

  • Page 45: 3.10.2 Change Snmp Trap Configuration

    This action does not permanently save changes. To save changes to the SNMP trap settings you must click the Save Traps button in the SNMP Configuration screen. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 45 of 106 Sept 18, 2008...

  • Page 46: Spectrum Sweep

    Use the configuration Test feature (system configuration screen) to remotely (over-the-air) disable the remote transmitter for 5 minutes (uncheck the Radio Enable field) and then recover automatically. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 46 of 106 Sept 18, 2008...

  • Page 47: Table 14: Web - Performing A Spectrum Sweep

    Use Web/CLI to disable radio on remote-end. Use 'test' function to PTP Master /PMP save and remote end will restore radio operation automatically after Sector Controller 5 minutes. Figure 21: Web - Spectrum Sweep Results 70-00072-01-07 Proprietary Redline Communications © 2010 Page 47 of 106 Sept 18, 2008...

  • Page 48: Pmp Operation

    The following menu items are available for configuring and monitoring the PMP functions. See Table 13: Web - Default System Users on page 40 for the factory default usernames and passwords. Figure 22: PMP - Main Menu 70-00072-01-07 Proprietary Redline Communications © 2010 Page 48 of 106 Sept 18, 2008...

  • Page 49: Functional Description

    VID=107 are classified as data traffic, while the packets tagged with VID=108 are classified as voice traffic. Figure 24: PMP - VLAN Tagged Traffic Example 70-00072-01-07 Proprietary Redline Communications © 2010 Page 49 of 106 Sept 18, 2008...

  • Page 50: Minimum Setup Requirements

    Through If a pass-through Group has been defined, classified packets are forwarded based Traffic on the rules for tagged traffic. The packet VLAN information is not modified. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 50 of 106 Sept 18, 2008...

  • Page 51: Pmp Screens

    Max. Distance [km]: Enter the distance to the subscriber located farthest away from the sector controller (outer boundary of sector). This parameter is used to optimize communications with the subscribers. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 51 of 106 Sept 18, 2008...

  • Page 52: Link Screen

    Max UL Burst Rate: Select the uplink burst rate for unicast traffic from the subscriber to the sector controller (based on link budget calculations). Table 17: PMP Maximum Achievable UBR Uncoded Burst Rate (Mbps) SINADR (dB) 70-00072-01-07 Proprietary Redline Communications © 2010 Page 52 of 106 Sept 18, 2008...

  • Page 53: Group Screen

    VLAN ID, or the outermost VLAN ID tag does not match the VLAN ID for . Only one pass-through can be defined for each sector controller. If Group Group 70-00072-01-07 Proprietary Redline Communications © 2010 Page 53 of 106 Sept 18, 2008...

  • Page 54: Wireless Traffic Parameters

    Rate Max DL Burst Rate - 1 requiring a higher broadcast/multicast rate (e.g., video), a higher setting can be used at the risk of less reliable retransmissions. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 54 of 106 Sept 18, 2008...

  • Page 55: Connection Screen

    Tagged: Select tagged to associate a unique VID with this . Further Connection processing is performed at the sector controller based on the configuration Group associated with this Connection 70-00072-01-07 Proprietary Redline Communications © 2010 Page 55 of 106 Sept 18, 2008...

  • Page 56: Wireless Traffic Parameters

    DL QoS Level: Enter the QoS level for downlink unicast traffic for this connection. UL QoS Level: Enter the QoS level for uplink unicast traffic for this connection. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 56 of 106 Sept 18, 2008...

  • Page 57: Browse Screens

    Connections Link Delete: Click on any line to delete that . A link can not be deleted until all Delete Link referencing this link are deleted. Connections 70-00072-01-07 Proprietary Redline Communications © 2010 Page 57 of 106 Sept 18, 2008...

  • Page 58: Groups Screen

    Connections Group Delete: Click on any line to delete that can not be deleted until all Delete Group Group referencing this are deleted. Connections Group 70-00072-01-07 Proprietary Redline Communications © 2010 Page 58 of 106 Sept 18, 2008...

  • Page 59: Connections Screen

    Status that Connection Expand: Click on any line to display the browse screen. Expand Connections Delete (Delete): Click on any line to delete that Delete Connection 70-00072-01-07 Proprietary Redline Communications © 2010 Page 59 of 106 Sept 18, 2008...

  • Page 60: Statistics Screens

    RSSI: RSSI measured since the last screen refresh. SINADR: Average signal to interference, noise, and distortion ratio measured since the last screen refresh. Lost Frames: Number of frames lost. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 60 of 106 Sept 18, 2008...

  • Page 61: Group Statistics

    Packets Received: Number of Ethernet packets received over the wireless interface. Controls Reset: Click to zero the statistics values. Reset Refresh: Click to update the statistics display. Refresh 70-00072-01-07 Proprietary Redline Communications © 2010 Page 61 of 106 Sept 18, 2008...

  • Page 62: Connection Statistics

    Packets Received: Number of Ethernet packets received over the wireless interface. Controls Reset: Click to zero the statistics values. Reset Refresh: Click to update the statistics display. Refresh 70-00072-01-07 Proprietary Redline Communications © 2010 Page 62 of 106 Sept 18, 2008...

  • Page 63: System Status - Pmp Wireless Statistics

    Prior to completing this setup, no Ethernet data traffic can be transmitted over the wireless interface. The procedures provided below include steps to setup a basic working configuration for initial testing, and then to introduce VLAN traffic controls. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 63 of 106 Sept 18, 2008...

  • Page 64: Configure Pass-Through Operation

    Enter the Group ID in the Group ID field. Set the DL QoS Level and UL QoS Levels. Default is 'MAX Burst Rate Value - 1'. Setting the value to zero (0) disables all traffic. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 64 of 106 Sept 18, 2008...

  • Page 65: Step 4: Save Configuration

    Repeat steps 1 through 6 for each Connection in the Group. Step 3: Save Configuration Click Save in the left-hand menu to permanently save and activate all settings. The system will now pass only VLAN tagged traffic. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 65 of 106 Sept 18, 2008...

  • Page 66: Cli Interface

    √ √ upgrade Upload a software binary image to the AN-80i. √ √ user View/modify the user/password configuration. √ whoami Display login name for this Telnet session. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 66 of 106 Sept 18, 2008...

  • Page 67: Connecting With Telnet

    Table 21: CLI - chgver Parameter/Description √ √ Enter this command to toggle between software versions. The setting will alternate between the two banks of memory (no parameters). chgver <Enter> 70-00072-01-07 Proprietary Redline Communications © 2010 Page 67 of 106 Sept 18, 2008...

  • Page 68: Clear

    *Not used in v3.00 software release. 5.3.4 Enable Use the enable command to re-enable a specific ID (that was disabled). Table 24: CLI - enable Parameter/Description √ enable <id> - [id number] 70-00072-01-07 Proprietary Redline Communications © 2010 Page 68 of 106 Sept 18, 2008...

  • Page 69: Freq

    Current RF frequency setting. √ rflink: Status of the RF link. √ √ rfstatus: Status RF transmitter. √ rssimax: Maximum RSSI. √ rssimean: Mean RSSI. √ rssimin: Minimum RSSI. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 69 of 106 Sept 18, 2008...
  • Page 70 Uplink retransmitted blocks counter. √ lulrssi: Uplink RSSI. √ lulsnr: Uplink SINADR. √ luptime: Link up-time. √ regconn: Number of configured Connections. √ regstations: Number of configured stations. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 70 of 106 Sept 18, 2008...

  • Page 71: Load

    (created using script command) from a remote TFTP server. The file must be located in the TFTP default directory. <server> - [server IP address] <name> - [script file name] 70-00072-01-07 Proprietary Redline Communications © 2010 Page 71 of 106 Sept 18, 2008...

  • Page 72: Logout

    Use the reset command to set all AN-80i statistics values to zero. Table 33: CLI - reset Parameter/Description √ √ stats: Reset the AN-80i statistics counters. reset stats <Enter> 70-00072-01-07 Proprietary Redline Communications © 2010 Page 72 of 106 Sept 18, 2008...

  • Page 73: 5.3.14 Save

    1x10e-6, the system automatically steps down modulation/code rate (i.e., from 16 QAM 3/4 to 16 QAM 1/2 ) to maintain the wireless link quality. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 73 of 106 Sept 18, 2008...
  • Page 74 - <VLAN priority> √ convid: Connection VLAN ID. <id> - [id number] <vid> - <VLAN ID> √ conviden: Connection VLAN enable. <id> - [id number] <mode> - <on/off> 70-00072-01-07 Proprietary Redline Communications © 2010 Page 74 of 106 Sept 18, 2008...
  • Page 75 Enable or disable the encryption function. off - Disable on - Enable If encryption is enabled, the correct encryption keys must be entered on both communicating systems. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 75 of 106 Sept 18, 2008...
  • Page 76 - <id name> - maximum 15 characters √ √ ipaddr: Enter the IP address and subnet mask of the AN-80i. Address - IP Address Mask - Subnet Mask - Confirmation to proceed 70-00072-01-07 Proprietary Redline Communications © 2010 Page 76 of 106 Sept 18, 2008...
  • Page 77 20 MHz channels, the separation must be greater than 20 MHz. √ √ snmp: SNMP enable setting. off - Disable the SNMP agent. on - Enable the SNMP agent. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 77 of 106 Sept 18, 2008...
  • Page 78 Enable or disable the Telnet port. If the Telnet port is disabled, it will not be possible to use the CLI interface. off - Disable on - Enable Changes to this field are effective only following reboot. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 78 of 106 Sept 18, 2008...

  • Page 79: 5.3.17 Show

    = 192.168.25.1 ethmode = auto http = On telnet = On √ conns: list all Connections. <id> - [id number] Example: 192.168.25.2(show)# conns 14 27 SS-001-Data Conn 70-00072-01-07 Proprietary Redline Communications © 2010 Page 79 of 106 Sept 18, 2008...
  • Page 80 1023 - Firmware configuration: OK 000d, 00:00:26 1033 - MAC Initialization: OK 000d, 00:13:29 2039 - SNTP: Time received: OK 000d, 02:15:00 1006 - User Configuration Save: OK 70-00072-01-07 Proprietary Redline Communications © 2010 Page 80 of 106 Sept 18, 2008...
  • Page 81 = 0 * * Status codes are displayed in binary format. See section 6.4: Status Codes on page 88 for details of the RF status codes. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 81 of 106 Sept 18, 2008...

  • Page 82: 5.3.18 Snmpcommunity

    Use the test command to load the current edited (but not permanently saved) configuration settings. Table 40: CLI - test Parameter/Description √ √ config - AN-80i configuration settings test config <Enter> 70-00072-01-07 Proprietary Redline Communications © 2010 Page 82 of 106 Sept 18, 2008...

  • Page 83: 5.3.21 Upgrade

    Use the whoami command to display the username of the current Telnet session. This command is not available when logged in as administrator. Table 43: CLI - whoami Parameter/Description √ whoami - Display username for this session. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 83 of 106 Sept 18, 2008...

  • Page 84: Diagnostics And Troubleshooting

    RF Channel Set by factory key. Tx power 14 dBm Encryption Enabled / no key Note: Factory defaults can only be restored using the CLI ' command. save' 70-00072-01-07 Proprietary Redline Communications © 2010 Page 84 of 106 Sept 18, 2008...

  • Page 85: Procedure To Restore Factory Settings

    System Name, System Location, System Details and Contact Frequency list SNMP configuration ID table (PMP only) Power-off the PoE adapter and re-connect the network cable. Restore power to the PoE adapter. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 85 of 106 Sept 18, 2008...

  • Page 86: Testing And Saving System Parameters

    AN-80i. The problem may be with the Internet browser or related settings on the host computer. Reboot the host computer to try to resolve the problem. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 86 of 106 Sept 18, 2008...

  • Page 87: Table 45: Diag. - Web Interface Diagnostics

    PC matches the configured subnet mask of the AN-80i. Check that the host PC's address is 192.168.25.n, where 'n' is not equal to 0,2, or 255. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 87 of 106 Sept 18, 2008...

  • Page 88: Status Codes

    AN-80i experienced an error. Reset the AN-80i. Firmware 1000 0000 Error detected in the AN-80i configuration file. Configuration Error *Displayed decimal value if this is the only active error condition. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 88 of 106 Sept 18, 2008...

  • Page 89: Pmp Status Codes

    PLL Errors Firmware Error No Ethernet packets received by the wireless MAC 17, 18, 19, 20, MAC Internal Errors 21, 22, 23, 24, 25, 26, 27, 28 70-00072-01-07 Proprietary Redline Communications © 2010 Page 89 of 106 Sept 18, 2008...

  • Page 90: Appendices

    Up to 90 Mbps average Ethernet rate (40 MHz channel) Rx Sensitivity: -88 dBm @ 3 Mbps max. PoE Cable: Up to 91 m (300 ft) Network Attributes: 802.3x Ethernet flow control 70-00072-01-07 Proprietary Redline Communications © 2010 Page 90 of 106 Sept 18, 2008...
  • Page 91 Actual Ethernet data throughput is dependent on: protocols, packet size, burst rate, transmission latency, and link distance. With lightning arrestor installed. PTP Only PMP Only Maximum power based on radio type. Specifications are subject to change without notice. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 91 of 106 Sept 18, 2008...

  • Page 92: An-80I Poe Power Adapter Specifications

        (48-00064-00) parabolic (13-00052) A3403RWP 3.4° 80i-SA-MNT 34.6    (48-00033-00) parabolic (13-00052) A36009MMO 360° 80i-SA-MNT     (48-00048-01) omni (13-00052) 70-00072-01-07 Proprietary Redline Communications © 2010 Page 92 of 106 Sept 18, 2008...

  • Page 93: Legacy Products (Not Available To Order)

    (48-00014-00) panel A6017RWS 60°    80i-HD-MNT (48-00028-00) panel A9014MTS 90°     80i-HD-MNT (48-00017-00) panel A9016RWS 90°    80i-HD-MNT (48-00029-00) panel 70-00072-01-07 Proprietary Redline Communications © 2010 Page 93 of 106 Sept 18, 2008...

  • Page 94: Etsi Certified Antennas

    90°, 4.9-5.9 GHz, sector flat panel (48-00066-00) A6017EAS 17.5 62°, 4.9-5.9 GHz, sector flat panel (48-00067-00) A2209MTFD 9°, 5.15-5.875 GHz, flat panel (48-00021-02) A2212RWP 12°, 5.250-5.850 GHz, parabolic (48-00030-00) 70-00072-01-07 Proprietary Redline Communications © 2010 Page 94 of 106 Sept 18, 2008...

  • Page 95: Ghz Radio: Etsi Certified Antennas

    120°, 4.9-5.9 GHz, sector flat panel (48-00065-00) A9016EAS 16.6 90°, 4.9-5.9 GHz, sector flat panel (48-00066-00) A6017EAS 17.5 62°, 4.9-5.9 GHz, sector flat panel (48-00067-00) A2209MTFD 9°, 5.15-5.875 GHz, flat panel (48-00021-02) 70-00072-01-07 Proprietary Redline Communications © 2010 Page 95 of 106 Sept 18, 2008...

  • Page 96: Fcc & Ic Certified Antennas

    A6015MTS 60°, 5.150-5.875 GHz, sector flat panel 18.3 (48-00014-00) A9016RWS 90°, 5.250-5.850 GHz, sector, flat 18.3 panel (48-00029-00) A6017RWS 60°, 5.250-5.850 GHz, sector, flat 17.1 panel (48-00028-00) 70-00072-01-07 Proprietary Redline Communications © 2010 Page 96 of 106 Sept 18, 2008...

  • Page 97: Ghz Radio: Fcc & Ic Certified Antennas

    50 ohms. The RF output power and selection must be professionally programmed and installed by the manufacturer or a trained professional installer. The following table lists FCC and IC certified antennas: 70-00072-01-07 Proprietary Redline Communications © 2010 Page 97 of 106 Sept 18, 2008...

  • Page 98: 3.650 - 3.700 Ghz Radio: Fcc & Ic Antennas

    PA1660EASH 60 deg., 3.3-3.8 GHz (48-00051-00) horizontal polarization only PA1590EAS 90 deg., 3.3-3.8 GHz (48-00052-00) vertical polarization only PA1590EASH 90 deg., 3.3-3.8 GHz (48-00053-00) horizontal polarization only 70-00072-01-07 Proprietary Redline Communications © 2010 Page 98 of 106 Sept 18, 2008...

  • Page 99: Regional Codes

    DE 5.8 G 5750 - 5870 5765 - 5865 Region 08 4945 - 4985 4940 - 4990 4950 - 4980 5260 - 5340 5.250 - 5.350 5265 - 5335 70-00072-01-07 Proprietary Redline Communications © 2010 Page 99 of 106 Sept 18, 2008...
  • Page 100 UK VNS 2107/ EN302 502 ETSI EN301893 v1.3.1 FCC Part 15 IC RSS-210 IC RSS-111 TKG § 55/EN302 502 9. CBP (Contention Based Protocol) as per FCC regulation CFR Part 90.1321 70-00072-01-07 Proprietary Redline Communications © 2010 Page 100 of 106 Sept 18, 2008...

  • Page 101: Security Keys And Certificates

    --- or --- ssl_key<mac>.pem 2. Use 'load' command to save customer-defined certificate and private key in 'usr' settings. Note: Use the 'minus' character to delimit the MAC address. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 101 of 106 Sept 18, 2008...

  • Page 102: Security Certificate And Key Cli Commands

    <mode> List the key and certificate files. <mode> run - displays keys currently in use. usr - displays user-specified keys and certificates (default if mode not specified). 70-00072-01-07 Proprietary Redline Communications © 2010 Page 102 of 106 Sept 18, 2008...
  • Page 103 The <mac> portion is the MAC address of the board. For example: dsa_key_00-09-02-00-01-02.pem <mode> Can be 'usr' or 'factory'. Defaults to 'usr' if mode is not specified. *Not used in v3.00 software release. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 103 of 106 Sept 18, 2008...

  • Page 104: Glossary Of Terms

    Line Of Sight. A clear direct path between two antennas, with no obstructions within the first Fresnel zone. Media Access Control. A unique number assigned to a network device. 70-00072-01-07 Proprietary Redline Communications © 2010 Page 104 of 106 Sept 18, 2008...
  • Page 105 (SSL), are cryptographic protocols that provide secure communications on the Internet for web browsing, e-mail, Internet faxing, instant messaging and other data transfers. Transmitter Uncoded Burst Rate 70-00072-01-07 Proprietary Redline Communications © 2010 Page 105 of 106 Sept 18, 2008...
  • Page 106 302 Town Centre  Suite 100  Markham, Ontario  Canada  L3R 0E8 www.redlinecommunications.com 70-00072-01-07 Proprietary Redline Communications © 2010 Page 106 of 106 Sept 18, 2008...
