RedCONNEX
TM
AN-80i PTP & PMP
System
User Manual
70-00072-01-04b
Proprietary Redline Communications © 2007
October 31, 2007
Page 1 of 94

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RedCONNEX AN-80i PTP and is the answer not in the manual?

Questions and answers

Related Manuals for Redline Communications RedCONNEX AN-80i PTP

Summary of Contents for Redline Communications RedCONNEX AN-80i PTP

  • Page 1 RedCONNEX AN-80i PTP & PMP System User Manual 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 1 of 94...
  • Page 2 Additionally, Redline makes no representations or warranties, either expressed or implied, regarding the contents of this product. Redline Communications shall not be liable for any misuse regarding this product. The information in this document is subject to change without notice.

  • Page 3: Table Of Contents

    3.10 SNMP Settings Screen................38 3.10.1 Change SNMP Community ..............39 3.10.2 Change SNMP Trap Configuration............40 3.11 Spectrum Sweep ..................41 PMP Operation..................43 Introduction....................43 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 3 of 94...
  • Page 4 Clear ....................64 5.3.3 Del ....................... 64 5.3.4 Enable ....................64 5.3.5 Freq ..................... 65 5.3.6 Get....................... 65 5.3.7 Load..................... 67 5.3.8 New ..................... 67 5.3.9 Ping ..................... 67 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 4 of 94...
  • Page 5 Table 9: PMP - Basic Pass-Through Group Settings .......... 45 Table 10: PMP - Packet Classification ..............45 Table 11: PMP Maximum Achievable UBR............47 Table 12: PMP - Basic Pass-Through Group Configuration Settings....60 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 5 of 94...
  • Page 6 Table 45: Spec. - FCC & IC Certified Antennas: 5.8 GHz PMP Operation ..89 Table 46: Spec. - Regional Identification Codes ..........90 Table 47: Spec. - Glossary.................. 91 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 6 of 94...
  • Page 7 Figure 35: CLI - Connecting via Telnet ............... 63 Figure 36: CLI - Recovering Lost IP Address............80 Figure 37: Diag - Saving Parameters in NVRAM ..........81 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 7 of 94...

  • Page 8: Important Safety & Service Notices

    AN-80i, mast, lead-in wire and discharge unit, location of discharge unit, size of grounding conductors and connection requirements for grounding electrodes. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 8 of 94...

  • Page 9: Important Warning Symbols

    Improperly grounded connections are also a source of noise that can cause sensitive equipment to malfunction. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 9 of 94...

  • Page 10: Fcc & Ic Notice

    This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 10 of 94...

  • Page 11: Ul Information

    Use the following table to record important system information: Product Information AN-80i SN: MAC Address PoE SN: Model #: Antenna Model No.: Antenna SN: Serial Number Stickers 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 11 of 94...

  • Page 12: System Overview

    RedCONNEX User Manual Chapter The Access Node 80i system is manufactured by Redline Communications -- a world leader in design and production of Broadband Fixed Wireless (BFW) systems. Figure 1: Intro - AN-80i Components The AN-80i is a high-performance, high-speed wireless Ethernet bridge for use in a commercial, industrial, business, or government environment.

  • Page 13: Ethernet Port

    (four-point) antenna mounting bracket is available for mounting two foot flat panel and parabolic antennas. Grounding Connection A ground-lug is provided on the AN-80i chassis. Use this connection to terminate a grounding wire. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 13 of 94...

  • Page 14: Indoor Power Block (Poe Power Adapter)

    OUTPUT (DATA & POWER) connector. Connecting customer premises Ethernet equipment directly to the OUTPUT (DATA & POWER) connector on the Power-over-Ethernet power adapter may damage customer equipment. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 14 of 94...

  • Page 15: Antenna Alignment

    It is recommended to monitor the RSSI measurements to achieve maximum signal strength when performing fine adjustments to the subscriber antenna. Refer to the AN-80i Installation Guidelines for detailed instructions. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 15 of 94...

  • Page 16: Web Interface - Ptp

    If the IP address, or the user name and password cannot be determined. See section 6.2: Procedure to Restore Factory Settings on page 80. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 16 of 94...

  • Page 17: System Menu

    Figure 5: Web - System Menu The administrator (admin) has unrestricted access to all screens. All other users have viewing access only. See 3.7: Users Management on page 34 for details. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 17 of 94...

  • Page 18: System Information

    PTP Slave: AN-80i waits passively, monitoring the selected channel(s) until polled by the PTP Master. Software Version: Displays the software version in use. Time Since System Start: Time since the system was last reset or powered-on. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 18 of 94...

  • Page 19: Ethernet

    Yes - RF link successfully established with remote-end AN-80i. No - RF link not established with remote-end AN-80i. Uncoded Burst Rate: The current uncoded burst rate for the link. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 19 of 94...

  • Page 20: System Status

    AN-80i and negotiating the UBR (modulation and coding) for the wireless link. PTP Slave: This unit waits passively, monitoring the selected channel(s) until polled by the PTP Master. RF Channel Frequency: User-assigned RF channel. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 20 of 94...

  • Page 21: Ethernet Lan Statistics

    (discarded by remote-end due to errors). Controls Reset Statistics: Click this button to zero the counters for the wireless and Ethernet LAN Statistics displayed on this page. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 21 of 94...

  • Page 22: System Logs Screen

    1015 Options Key Save: OK 1016 Options Key Properties Load: OK 1017 Options Key Properties Save: OK 1018 Options Key Activated: OK 1019 Data server started: OK 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 22 of 94...
  • Page 23 2013 System Description Save: ERROR 2014 Options Key Load: ERROR 2015 Options Key Save: ERROR 2016 Options Key Properties Load: ERROR 2017 Options Key Properties Save: ERROR 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 23 of 94...
  • Page 24 Int Procs starrt: ERROR 2047 ID action not possible 2048 ID validation: ERROR 2049 HW validation: ERROR 2050 FTP: ERROR 2051 RF frequency validation: ERROR 2099 UNKNOWN MESSAGE 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 24 of 94...

  • Page 25: System Configuration Screen

    System Location: Enter additional descriptive details about this AN-80i. The description can be any combination of letters and numbers. Contact: Enter additional descriptive details about this AN-80i. The description can be any combination of letters and numbers. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 25 of 94...

  • Page 26: Table 3: Configuration - 802.1P Priority Settings

    Ethernet equipment. The auto-negotiate feature works correctly only when both communicating Ethernet devices are configured for auto-negotiate. Duplex mismatches may result in an unexpected loss of communications. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 26 of 94...
  • Page 27 VLAN ID. Important: The VLAN network support should be verified before enabling this feature to ensure the AN-80i system will be reachable using the VLAN tagged traffic. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 27 of 94...

  • Page 28: Wireless Configuration

    Important: To minimize interference, the channel frequencies for AN-80i links operating in close proximity should be separated by a minimum of the channel size in use (to avoid overlapping bands). 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 28 of 94...

  • Page 29: Figure 11: Web - Wireless Configuration Screen

    These are the (optional) scan intervals for this PTP Slave. The last settings saved in non- volatile memory will be loaded when the PTP Slave is rebooted. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 29 of 94...

  • Page 30: Table 4: Web - Max. Power (In Dbm) And Modulation Settings

    Table 4: Web - Max. Power (in dBm) and Modulation Settings Modulation BPSK QPSK 16 QAM 64 QAM Code Rate Max Tx Power 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 30 of 94...
  • Page 31 When disabled, the modulation and code settings are entered manually using the Uncoded Burst Rate setting. See Table 4: Web - Max. Power (in dBm) and Modulation. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 31 of 94...

  • Page 32: Table 5: Web - Ethernet Status Indication

    When encryption is enabled, no Ethernet packets can be transferred over-the-air unless encryption is enabled on the remote-end AN-80i, and the correct Encryption Key is entered on both AN-80i units. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 32 of 94...

  • Page 33: Controls

    (also terminating the five minute timer). If the Save button is not selected, the AN-80i is automatically rebooted and the previously saved settings are reloaded. System Reboot: Click this button to immediately reboot the AN-80i. All statistics counters are reset. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 33 of 94...

  • Page 34: Users Management

    Use this dialog to add a new user. User name: Enter a name for the new user (15 characters max.). Group: Select a group for the new user. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 34 of 94...

  • Page 35: Table 6: Web - Screens And User Access

    The following table lists the default login names and passwords. Table 7: Web - Default System Users Group User Name Default Password user user user admin admin admin 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 35 of 94...

  • Page 36: An-80I Product Options Screen

    3 Mbps UBR, DFS permanently enabled, region based common frequency range, no enhanced options (i.e., AES). A valid options key must be entered to enable PMP mode operation. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 36 of 94...

  • Page 37: Upload Software

    5. When the transfer has completed successfully, use the System Configuration screen to select which software version to load on the next system reboot (does not switch automatically following upload). 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 37 of 94...

  • Page 38: Snmp Settings Screen

    The Chg buttons can be used to add, edit, or delete community settings. Figure 15: Web - SNMP Configuration Screen SNMP Community Management Community Name: Displays the SNMP community name for each entry (maximum of eight entries). 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 38 of 94...

  • Page 39: 3.10.1 Change Snmp Community

    Read&Write: Grant read and write access permission for this entry. Change Community: Click the Change Community button to copy these settings to the community settings table. This action does not permanently save changes. To save 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 39 of 94...

  • Page 40: 3.10.2 Change Snmp Trap Configuration

    This action does not permanently save changes. To save changes to the SNMP trap settings you must click the Save Traps button in the SNMP Configuration screen. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 40 of 94...

  • Page 41: Spectrum Sweep

    Use the configuration Test feature (system configuration screen) to remotely (over-the-air) disable the remote transmitter for 5 minutes (uncheck the Radio Enable field) and then recover automatically. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 41 of 94...

  • Page 42: Table 8: Web - Performing A Spectrum Sweep

    Use Web/CLI to disable radio on remote-end. Use 'test' function to PTP Master /PMP save and remote end will restore radio operation automatically after Sector Controller 5 minutes. Figure 19: Web - Spectrum Sweep Results 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 42 of 94...

  • Page 43: Pmp Operation

    The following menu items are available for configuring and monitoring the PMP functions. See Table 7: Web - Default System Users on page 35 for the factory default usernames and passwords. Figure 20: PMP - Main Menu 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 43 of 94...

  • Page 44: Functional Description

    The packets tagged with VID=107 are classified as data traffic, while the packets tagged with VID=108 are classified as voice traffic. Figure 22: PMP - VLAN Tagged Traffic Example 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 44 of 94...

  • Page 45: Minimum Setup Requirements

    Through If a pass-through Group has been defined, classified packets are forwarded based Traffic on the rules for tagged traffic. The packet VLAN information is not modified. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 45 of 94...

  • Page 46: Pmp Screens

    Max. Distance [km]: Enter the distance to the subscriber located farthest away from the sector controller (outer boundary of sector). This parameter is used to optimize communications with the subscribers. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 46 of 94...

  • Page 47: Link Screen

    Max UL Burst Rate: Select the uplink burst rate for unicast traffic from the subscriber to the sector controller (based on link budget calculations). Table 11: PMP Maximum Achievable UBR Uncoded Burst Rate (Mbps) SINADR (dB) 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 47 of 94...

  • Page 48: Group Screen

    If the sector controller Ethernet port is enabled, a VLAN tag is added (outermost) and set to the VID ( VLAN ID field) for this and the packet is forwarded to Group Group the sector controller Ethernet Port. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 48 of 94...

  • Page 49: Wireless Traffic Parameters

    Rate Max DL Burst Rate - 1 requiring a higher broadcast/multicast rate (e.g., video), a higher setting can be used at the risk of less reliable retransmissions. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 49 of 94...

  • Page 50: Connection Screen

    Tagged: Select tagged to associate a unique VID with this . Further Connection processing is performed at the sector controller based on the configuration Group associated with this Connection 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 50 of 94...

  • Page 51: Wireless Traffic Parameters

    Burst Rate - 1 DL QoS Level: Enter the UBR for downlink unicast traffic for this connection. UL QoS Level: Enter the UBR for uplink unicast traffic for this connection. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 51 of 94...

  • Page 52: Browse Screens

    Connections Link Delete: Click on any line to delete that . A link can not be deleted until all Delete Link referencing this link are deleted. Connections 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 52 of 94...

  • Page 53: Groups Screen

    Connections Group Delete: Click on any line to delete that can not be deleted until all Delete Group Group referencing this are deleted. Connections Group 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 53 of 94...

  • Page 54: Connections Screen

    Status that Connection Expand: Click on any line to display the browse screen. Expand Connections Delete (Delete): Click on any line to delete that Delete Connection 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 54 of 94...

  • Page 55: Statistics Screens

    Burst Rate: The current uncoded burst rate for the link. RSSI: RSSI measured since the last screen refresh. SINADR: Average signal to interference, noise, and distortion ratio measured since the last screen refresh. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 55 of 94...

  • Page 56: Group Statistics

    Packets Received: Number of Ethernet packets received over the wireless interface. Controls Reset: Click to zero the statistics values. Reset Refresh: Click to update the statistics display. Refresh 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 56 of 94...

  • Page 57: Connection Statistics

    Packets Received: Number of Ethernet packets received over the wireless interface. Controls Reset: Click to zero the statistics values. Reset Refresh: Click to update the statistics display. Refresh 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 57 of 94...

  • Page 58: System Status - Pmp Wireless Statistics

    Prior to completing this setup, no Ethernet data traffic can be transmitted over the wireless interface. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 58 of 94...

  • Page 59: Configure Pass-Through Operation

    5. Use the default values for all other fields. 6. Click the Apply button to save and activate these settings. 7. Repeat steps 1 - 6 for each subscriber station. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 59 of 94...

  • Page 60: Step 2: Create Single Pass-Through Group

    Mode SC-1 Pass SS-1 Pass [L-1]* [SC-1]* Through Through SS-2 Pass [L-2]* [SC-1]* Through *The group ID and link ID are numbers generated automatically by the AN-80i. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 60 of 94...

  • Page 61: Vlan Configuration

    7. Repeat steps 1 through 6 for each Connection in the Group. Step 3: Save Configuration Click Save in the left-hand menu to permanently save and activate all settings. The system will now pass only VLAN tagged traffic. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 61 of 94...

  • Page 62: Cli Interface

    Activate edited changes to the system configuration for a test period of five minutes. √ √ upgrade Upload a software binary image to the AN-80i. √ √ user View/modify the user/password configuration. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 62 of 94...

  • Page 63: Connecting With Telnet

    The system will logout users automatically if no commands are received (idle) for five minutes. To exit immediately from the CLI, type the following command: logout [ENTER] 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 63 of 94...

  • Page 64: Cli Command Set

    - [id number] 5.3.4 Enable Use the enable command to re-enable a specific ID (that was disabled). Table 18: CLI - enable Parameter/Description √ enable <id> - [id number] 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 64 of 94...

  • Page 65: Freq

    Current Tx power setting. √ ubrate: Current UBR value. √ wrxpkt: Number of wireless packets received. √ wrxpktd: Number of wireless packets received that were discarded. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 65 of 94...
  • Page 66 Wireless Eth Rx packets counter. √ werxpktdis: Wireless Eth Rx discarded packets counter. √ werxpkterr: Wireless Eth Rx packets with errors counter. √ wetxpkt: Wireless Eth Tx packets counter. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 66 of 94...

  • Page 67: Load

    Use the reset command to set all AN-80i statistics values to zero. Table 24: CLI - reset Parameter/Description √ √ stats: Reset the AN-80i statistics counters. reset stats <Enter> 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 67 of 94...

  • Page 68: 5.3.11 Save

    If the antenna gain is set higher incorrectly, the AN-80i is less sensitive to detecting interference, and is not operating in compliance with the UK/ETSI standard. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 68 of 94...
  • Page 69 - <VLAN priority> √ convid: Connection VLAN ID. <id> - [id number] <vid> - <VLAN ID> √ conviden: Connection VLAN enable. <id> - [id number] <mode> - <on/off> 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 69 of 94...
  • Page 70 Enable or disable the encryption function. off - Disable on - Enable If encryption is enabled, the correct encryption keys must be entered on both communicating systems. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 70 of 94...
  • Page 71 ID name. <id> - [id number] <name> - <id name> - maximum 15 characters √ lkname: Link name. <name> - <id name> - maximum 15 characters 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 71 of 94...
  • Page 72 For example, when operating in with 20 MHz channels, the separation must be greater than 20 MHz. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 72 of 94...
  • Page 73 <SysMode> - [pmpss | pmpsc] √ √ sysname: Enter the name for this AN-80i. The name can be any combination of up to 20 letters and numbers. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 73 of 94...

  • Page 74: 5.3.14 Show

    = 18 = +0:00 maxdst syslog = Off radio = Off = 2 syslogip = 192.168.25.1 radio = Off ethmode = auto http = On telnet = On 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 74 of 94...
  • Page 75 1023 - Firmware configuration: OK 000d, 00:00:26 1033 - MAC Initialization: OK 000d, 00:13:29 2039 - SNTP: Time received: OK 000d, 02:15:00 1006 - User Configuration Save: OK 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 75 of 94...

  • Page 76: 5.3.15 Snmpcommunity

    Set all snmp parameters to factory default settings. snmpcommunity default <idx> <Enter> del: Delete the specified community entry. snmpcommunity del <idx> <Enter> print: List all SNMP communities and associated permissions. snmpcommunity print <Enter> 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 76 of 94...

  • Page 77: 5.3.16 Snmptrap

    You must specify the TFTP server address and the full name of the binary file (including .bin extension). The AN-80i software binary file must be located in the default directory of the TFTP server. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 77 of 94...

  • Page 78: 5.3.19 User

    <username> <Enter> print: Administrators can use this command to display a list of user accounts. This option is available only for administrators. user print <Enter> 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 78 of 94...

  • Page 79: Diagnostics And Troubleshooting

    RF Channel Set by factory key. Tx power 14 dBm Encryption Enabled / no key Note: Factory defaults can only be restored using the CLI ' command. save' 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 79 of 94...

  • Page 80: Procedure To Restore Factory Settings

    System Name, System Location, System Details and Contact Frequency list SNMP configuration ID table (PMP only) 8. Power-off the PoE adapter and re-connect the network cable. Restore power to the PoE adapter. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 80 of 94...

  • Page 81: Testing And Saving System Parameters

    After five minutes, if the Save function button has not been applied, the AN-80i will reboot and load the previously saved settings. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 81 of 94...

  • Page 82: Table 35: Diag. - Web Interface Diagnostics

    If the correct IP address of the AN-80i cannot be determined, it is recommended to perform the IP recovery procedure. See section 6.2: Procedure to Restore Factory Settings on page 80. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 82 of 94...

  • Page 83: Status Codes

    AN-80i experienced an error. Reset the AN-80i. Firmware 1000 0000 Error detected in the AN-80i configuration file. Configuration Error *Displayed decimal value if this is the only active error condition. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 83 of 94...

  • Page 84: Pmp Status Codes

    PLL Errors Firmware Error No Ethernet packets received by the wireless MAC 17, 18, 19, 20, MAC Internal Errors 21, 22, 23, 24, 25, 26, 27, 28 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 84 of 94...

  • Page 85: Appendices

    Standard IEEE 802.3af (15.4 W Max.) Operating Temperature: -40 C to 60 C Dimensions/Weight: 289 mm x 190 mm x 515 mm (11.38 in x 7.50 in x 2.03 in) 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 85 of 94...

  • Page 86: An-80I Poe Specifications

    Storage Temperature: -50 to 70 C Operating Humidity: 5% to 95% Dimensions: 35 x 70 x 150 mm (1.38 x 2.76 x 5.91 in) Specifications are subject to change without notice. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 86 of 94...

  • Page 87: Etsi Certified Antennas

    12 Degree 5.250-5.850 GHz Directional Parabolic Note: The RF output power and selection must be professionally programmed and installed by the manufacturer or a trained professional installer. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 87 of 94...

  • Page 88: Fcc & Ic Certified Antennas

    -12.7 26.2 5.250-5.850 GHz Directional Parabolic Note: The RF output power and selection must be professionally programmed and installed by the manufacturer or a trained professional installer. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 88 of 94...

  • Page 89: Table 45: Spec. - Fcc & Ic Certified Antennas: 5.8 Ghz Pmp Operation

    19.4 6 GHz, OMNI 20.8 20.3 Note: The RF output power and selection must be professionally programmed and installed by the manufacturer or a trained professional installer. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 89 of 94...

  • Page 90: Regional Codes

    Where DFS is required by regional regulations, this function is permanently enabled at the factory and can not be disabled by the installer or end-user. Center frequencies. UK VNS 2107/ EN302 502 ETSI EN301893 v1.3.1 FCC Part 15 IC RSS-210 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 90 of 94...

  • Page 91: Glossary Of Terms

    A theoretic construct of an antenna that radiates its signal 360 degrees both vertically and horizontally—a perfect sphere. Generally used as a reference. Inter-exchange Carrier. A long-distance phone company. Local Exchange Carriers. The traditional local wired phone company. 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 91 of 94...
  • Page 92 The standard set of protocols used by the Internet for transferring information between computers, handsets, and other devices. TFTP Trivial File Transfer Protocol Transmitter Uncoded Burst Rate 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 92 of 94...
  • Page 93 AN-80i RedCONNEX User Manual 70-00072-01-04b Proprietary Redline Communications © 2007 October 31, 2007 Page 93 of 94...
