Leveling
Leveling Instructions
It is IMPORTANT to level the machine to ensure good spin performance and effective detergent and fabric softener
dispensing.
A spirit level is provided with your machine. Use this to level your machine, placing it bottom side down in the locations
specified below (ensure the surfaces are clean). The machine is level when the bubble sits in the center, within the two
lines.
Your washer is equipped with self-locking feet to ensure they do not move once you have leveled your machine. To
adjust the feet, tip the washer back or forward to locate the foot you wish to adjust, pull down gently and then twist to
move it up or down to the required level. Repeat if necessary.
After leveling, the corners of the washer should be clear of the floor (by at least 2/5" (10 mm) and the
machine must not rock in any direction).
1. If not already installed, fit the rubber inserts into
all 4 feet on the base of the machine.
2. Extend all 4 feet by three full turns before
moving the machine to its final position.
3. Move the machine to its final position using the
top corners to maneuver the product into place
(do not push against the center front of the
machine). We recommend a minimum
clearance of 3⁄4" (20 mm) each side and 2" (50
mm) at the rear of the machine.
4. With the lid closed, place the spirit level at the
center back of the lid (near the control panel). If
not level, pull the machine out and adjust the
rear feet until the machine is level side to side
when in position.
https://producthelp.fisherpaykel.com/us/Wash/Top_Loaders/AquaSmart_Eco/WL4027G1/User_Guide_WL4027G1/05_leveling
Updated: Fri, 16 Sep 2022 07:37:44 GMT
Powered by
1
Advertisement
Table of Contents
Related Manuals for Fisher & Paykel AquaSmart WL4027G1
Summary of Contents for Fisher & Paykel AquaSmart WL4027G1
- Page 1 Leveling Leveling Instructions It is IMPORTANT to level the machine to ensure good spin performance and effective detergent and fabric softener dispensing. A spirit level is provided with your machine. Use this to level your machine, placing it bottom side down in the locations specified below (ensure the surfaces are clean).
- Page 2 5. Open the lid. Place spirit level on the flat surface on the left side, inline with the center of the basket. If necessary, adjust the front left foot until the machine is level 6. Move the spirit level to the right side, in line with the center of the basket.
- Page 3 Fig.10 Leveling - Step 7 Completing your Installation • Turn on the water and check all hose connections for leaks. Make sure there are no kinks in the hoses. Check the hose connections for leaks again after 24 hours. • Uncoil the power cord, remove and discard the plastic pin cover, and plug into wall socket and turn the power Installation Test Cycle Your washer must be correctly installed before use.
- Page 4 • The lid will be locked from the start of the cycle until the cycle is complete for safety reasons. To open the lid during operation, you must touch START/PAUSE. • Supervise children at all times to ensure they do not play with the washer. •...
- Page 5 shock by providing a path of least resistance for electric current. This appliance is equipped with a cord that has an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. Specification subject to change without notice.
