Jiffy J-4000 Parts Diagram

MODEL J-4000
Parts Diagram
1
8
5
2
3
4
19
6
17
7
18
16
15
21
25
26
31 30
29
Jiffy Steamer Company, LLC
4462 Ken-Tenn Highway (38261)
Phone: 1-731-885-6690
13
12
11
14
22
23
24
20
28
Post Office Box 869
Fax: 1-731-885-6692
Worldwide Leader in Steaming Equipment Since 1940
Should you ever need replacement parts for your Jiffy Steamer, you may purchase
them separately. Use this convenient diagram and parts list to identify any part you
may need. Please reference the Jiffy Steamer part number, model number and
serial number when ordering.
9
Jiffy
Key Steamer
# Part #
1 1030 Rod Set and Nut Complete with Metal Studs
1034 Rod Set and Nut Complete for Drapery Steamers
2 0035 Hook Section of Rod Set
3 0036 Middle Section of Rod Set (with Barrel Stud and Cap Screw)
4 0037 Bottom Section of Rod Set
0038 Additional Middle Section of Rod Set for Drapery Steamers
5 0043 Metal Threaded Cap Screw for Rod Set
6 0039 Metal Threaded Stud for Rod Sections
10
7 1031 1/2" Split Clench Ring for Rod Set
8 1032 Rod Set Nut
9 0253 Plastic Steam Head/Handle Replacement Kit
10 0251 Plastic Head/Handle Hose Attachment Complete
0280 Hose Per Foot (Black in Color)
11 1301 J-4000 Die Cast Aluminum Housing
12 0006 Hex Beauty Rings (Set of 2)
13 0049 Water Fill Cap
0053 Funnel
14 0054 Housing Handle with Two Screws
15 0199 Rotary Power Switch and Knob
16 0201 Replacement Knob Only for Rotary Power Switch
17 1310 Red Neon Pilot Light (120 VOLT)
1311 Red Neon Pilot Light (230 VOLT)
18 0133 Cord Set complete with Strain Relief
19 0146C Cord Strain Relief
20 0050 Water Level Sight Gauge with Nuts and Washers
1353 Stainless Steel Boiler Tank Kit Complete (120 Volt)
1354 Stainless Steel Boiler Tank Kit Complete (230 Volt)
21 0074A Stainless Steel Boiler Tank with Sight Gauge
22 0058 Boiler Tank Lid with 2 Brass Fittings and 2 Beauty Rings
23 0071 Boiler Tank Screw Set (Set of 30 + 1 Tee Nut)
0061 Boiler Tank Silicone Sealer (2.8 Fluid Ounces)
0062 Boiler Tank Silicone Sealer (10.1 Fuid Ounces)
24 0075 Boiler Tank Gasket
25 1355 Heating Element (120 Volt, 1500 Watt)
1356 Heating Element (230 Volt, 1500 Watt)
1350 Heating Element (120 Volt, 1500 Watt) & Control Kit Complete $ 46.00
1351 Heating Element (230 Volt, 1500 Watt) & Control Kit Complete $ 46.00
1352 Control Kit with Seal and Hardware
1362 Hardware Kit for J-4000 Control
26 0203 Preheat Thermostat (L-170)
27
27 1314 Internal Wire Set (Set of 4 Wires)
28 1320 Bottom Plate with Four Casters
29 0017 Bottom Plate Screws (Set of 4)
30 0018 Bottom Plate Casters (Set of 4)

ACCESSORIES

31 1050 Jiffy Steamer Assembly Wrench
1062 Steam Cleaning "B" Brush Hose Attachment
1063 Spare Brush for the "B" Hose Attachment
0259 Auto Hose Attachment with Dual Metal Heads
0257 Carpet Hose Attachment
0252 7.5' Drapery Hose Attachment with Plastic Steam Head
0255 7.5' Drapery Hose Attachment with Metal Steam Head
0254 Metal Head / Wood Handle Hose Attachment Complete
0256 Metal Head / Wood Handle Only
0269 Replacement Wooden Handle (for Metal Steam Heads)
0262 Wig Hose Attachment
0274 Brass Hat Nozzle Attachment
0898 Liquid Cleaner - 3 Ten (10) Ounce Bottles per Package*
*Not Available for Export.
Union City, Tennessee 38281-0869
Web: www.jiffysteamer.com
Part Description
United States of America
E-mail: jsinfo@jiffysteamer.com
List
Price
$ 25.50
$ 29.00
$ 6.50
$ 7.50
$ 7.50
$ 7.50
$ 1.50
$ 1.50
$ 0.50
$ 6.00
$ 22.00
$ 50.00
$ 3.00
$ 72.00
$ 1.50
$ 6.50
$ 3.50
$ 7.00
$ 12.00
$ 1.50
$ 4.50
$ 4.50
$ 9.50
$ 1.50
$ 32.00
$155.00
$155.00
$ 78.00
$ 28.00
$ 6.00
$ 4.50
$ 8.00
$ 8.50
$ 28.00
$ 28.00
$ 18.00
$ 1.50
$ 8.00
$ 8.00
$ 18.00
$ 0.75
$ 6.50
$ 4.00
$ 50.00
$ 8.00
$ 82.00
$ 75.00
$ 56.00
$ 76.00
$ 70.00
$ 37.50
$ 7.00
$ 50.00
$ 13.00
$ 15.00
Form 4200
