Jiffy J-2000 Parts & Wiring Diagram

MODEL J-2000

Parts Diagram

1
5
2
3
4
13
6
7
12
15
17
16
20
27
29
28
Jiffy Steamer Company, LLC
4462 Ken-Tenn Highway (38261)
Phone: 1-731-885-6690
8
9
10
14
11
23
24
19
22
21
26
Post Office Box 869
Fax: 1-731-885-6692 Web: www.jiffysteamer.com
Worldwide Leader in Steaming Equipment Since 1940
Should you ever need replacement parts for your Jiffy Steamer, you may purchase
them separately. Use this convenient diagram and parts list to identify any part you
may need. Please reference the Jiffy Steamer part number, model number and
serial number when ordering.
Jiffy
Key Steamer
# Part #
1030
1 Rod Set and Nut Complete with Metal Studs
2 0035 Hook Section of Rod Set
3 0036 Middle Section of Rod Set
0037
4 Bottom Section of Rod Set
5 0043 Metal Threaded Cap Screw for Rod Set
0039
6 Metal Threaded Stud for Rod Sections
1031
7 1/2" Split Clench Ring for Rod Set
8 1032 Rod Set Nut
0253
9 Plastic Steam Head/Handle Replacement Kit
10 0251 Plastic Head/Handle Hose Attachment Complete
0280 Hose Per Foot (Black in Color)
1100
11 J-2000 Plastic Housing Kit
12 1140 J-2000 Water Caddy Complete
with Check Valve Cap
1141
13 J-2000 Water Caddy Complete
with out Check Valve Cap
0027A Replacement Check Valve Cap
1106
14 Round Beauty Grommet for J-2000 Housing
15 1125 Green Lighted Contura Rocker Switch - 120 Volt
1126
Green Lighted Contura Rocker Switch - 230 Volt
16 0132 Cord Set complete with Strain Relief
17 0146B Cord Strain Relief
0148
18 Internal Wire Set
1193 Heating Unit Kit (wiring included) for Models with
Green Lighted Contura Rocker Switch - 120 Volt
Cord Set and 4 1/2" Water Line
1194 Heating Unit Kit (wiring included) for Models with
Green Lighted Contura Rocker Switch - 230 Volt
Cord Set and 4 1/2" Water Line
19 0161B Heating Unit Assembly (no wiring included) for Models with
25
Green Lighted Contura Rocker Switch - 120 Volt
Cord Set and 4 1/2" Water Line
0162B Heating Unit Assembly (no wiring included) for Models with
Green Contura Lighted Rocker Switch - 230 Volt
Cord Set and 4 1/2" Water Line
20 0030 Brass 90 Degree Elbow Joint
18 1130
21 3/8" x 1/4" Straight Brass Fitting for
Heating Element Housing
22 1191 Copper Water Line (4 1/2" length)with Nuts and
Compression Rings
23 0160 L-290 Thermostat
0195
24 Fusible Link Clamp
0151
25 Fusible Link Wire with Insulated Lug
26 1120 Bottom Plate with Casters
0011
27 Bottom Plate Casters (Set of 4)
28 0010 Screws for Bottom Plate (4 Screws Total)
ACCESSORIES
29 1050 Jiffy Steamer Assembly Wrench
1062 Steam Cleaning "B" Brush Hose Attachment $60.00
1063
Spare Brush for the "B" Hose Attachment
0254 Metal Head/Wood Handle Hose
Attachment Complete
0256
Metal Head / Wood Handle Only
0269 Replacement Wooden Handle
(for Metal Steam Heads)
0898
Liquid Cleaner - 3 Ten (10) Ounce
Bottles per Package*
*Not Available for Export.
Union City, Tennessee 38281-0869
Part Description
United States of America
E-mail: jsinfo@jiffysteamer.com
List
Price
$ 25.50
$ 6.50
$ 7.50
$ 7.50
$ 1.50
$ 1.50
$ 0.50
$ 6.00
$ 22.00
$ 50.00
$ 3.00
$ 58.00
$ 28.00
$ 24.25
$ 3.75
$ 2.00
$ 9.00
$ 9.00
$ 9.50
$ 1.50
$ 9.00
$ 81.50
$ 81.50
$ 62.50
$ 62.50
$ 2.50
$ 2.50
$ 4.00
$ 8.00
$ 1.50
$ 3.00
$ 18.00
$ 6.50
$ 0.75
$ 4.00
$ 8.00
$70.00
$37.50
$ 7.00
$15.00
Form 4100
