  • Page 1 Quick Reference for End Users BurnerTronic BT300 Fault Codes for Software Version 3.9 Sensors and Systems for Combustion Engineering www.lamtec.de...

  • Page 3: Table Of Contents

    Table of Contents Table of Contents General Information ............3 Validity of these Instructions .

  • Page 4: General Information

    • BT341 Faults NOTICE The LAMTEC burner controls use different methods to detect fault messages between main processor and watchdog processor: BT300/ETAMATIC/FMS/VMS/FA1: The bus transmission does not generally use different fault numbers to distinguish between watchdog processor and main processor faults. In order to distinguish the main processor fault messages from the watchdog processor fault messages, an offset of 10000 is added to the watchdog processor faults.

  • Page 5: List Of Fault Codes

    List of Fault Codes List of Fault Codes Restarts according to TRD (P301 = 0 and P328 > 0) and EN676 (P301 = 2 and P328 > 0): The restart counter increases automatically at every burner start. The number of restarts is reset if •...
  • Page 6 List of Fault Codes P301 = 0 P301 = 2 Description Flame OFF during operation – Check curve settings – Check flame sensor – Check flame stability – Check positioning of the flame sensor – Check fuel valves – Check fuel supply –...
  • Page 7 List of Fault Codes P301 = 0 P301 = 2 Description Flame signal is lost during the 2 safety time. – Check ignition point – Check spark igniter and pilot burner – Check flame sensor – Check flame stability – Check positioning of the flame sensor –...
  • Page 8 List of Fault Codes P301 = 0 P301 = 2 Description Flame signal appears too early during ignition (pilot burner). If parameters 302 and 303 are set to value 3 or 4, only the ignition flame may be present during ignition (up to the begin- ning of the second safety time).
  • Page 9 List of Fault Codes P301 = 0 P301 = 2 Description Different operation modes on both controllers Main processor and watchdog processor detect the digital input signal at slightly different times. A signal change is hap- pening only for such a short time that only one of the two pro- cessors detects it.
  • Page 10 List of Fault Codes P301 = 0 P301 = 2 Description Monitoring band exceeded for too long. Channel – Check the damper for ease of movement. In the event of stiffness, clean the damper and make it smooth-running. – Check the function of the actuator without damper and replace if necessary.
  • Page 11 List of Fault Codes P301 = 0 P301 = 2 Description A servo motor cannot find the reference position. Channel – Check the damper’s smooth-running to the reference position. (see chapter Adjusting of the Actuators in the BT300 manual print no. DLT1201). –...
  • Page 12 List of Fault Codes P301 = 0 P301 = 2 Description Maximum permissible CO voltage exceeded CO Probe voltage +1V Offset Cold start may have been interrupted  Probes not yet ready for use – Remove probe and check in air: Replace the probe if necessary –...
  • Page 13 List of Fault Codes P301 = 0 P301 = 2 Description Program monitoring time (FAT) exceeded. Indication number Description see chapter 4 Assignment of the Programme Monitoring Time - Fault 600 A fault occurs during valve leakage test: Gas pressure is still present.
  • Page 14 List of Fault Codes P301 = 0 P301 = 2 Description 1 *1) 1 *1) Invalid drop of the safety interlock chain system – Check contacts and wiring of the safety interlock chain. 1 *1) 1 *1) Invalid drop of the safety interlock chain gas –...
  • Page 15 List of Fault Codes P301 = 0 P301 = 2 Description Optional Oil pressure is too low. – Make sure that oil is available. – Check oil pressure. – Check oil pressure switch. – Check oil filter – Check oil regulator Invalid change of the operation mode Fault during an internal self-test.
  • Page 16 List of Fault Codes P301 = 0 P301 = 2 Description Spark igniter is on for too long. Up to version 3.8.0.0, the maximum switch-on time is calculated from different parameters of the BT300. From version 3.9.0.0, this time is set in parameter 338. 721- Internal fault –...
  • Page 17 List of Fault Codes P301 = 0 P301 = 2 Description Valve leakage test: Main gas valve 1 is leaking. Main valve 1 is leaking (see BT300 manual DLT1205 chapter Valve leakage check of main valves). – Check the function of the gas pressure switch. –...
  • Page 18 List of Fault Codes P301 = 0 P301 = 2 Description BT300 leaves SETTING mode automatically after 24 hours. The BT300 has a hard coded time out of 24 hours for setting the burner. This Timeout has expired. – Reset fault. –...
  • Page 19 List of Fault Codes P301 = 0 P301 = 2 Description Internal fault Channel – Reset fault – If the fault still exists: Send error number and diagnostic code to the technical support. – Replace the device Directly controlled channel runs to an invalid position Channel + set point position...
  • Page 20 EN 14459 allows only 4 remote fault resets every 15 min. The fault reset is monitored by LSB Remote Software, UI300, LAMTEC SYSTEM BUS and field bus. Exceeding the num- ber of fault resets causes the fault shot-down 889 and further remote fault resets are ignored.
  • Page 21 List of Fault Codes P301 = 0 P301 = 2 Description Internal fault – Reset fault – If the fault still exists: Send error number and diagnostic code to the technical support. – Replace the device DFM: Fuel selection relay is defective or no/inconsistent feedback Invalid fuel selection in the DFM or inconsistent feedback from DFM.

  • Page 22: Assignment Of Configuration Fault 107

    Assignment of Configuration Fault 107 Assignment of Configuration Fault 107 Description Too many channels are activated. No channel at all is configured. Permanent spark igniter is configured (P302, P303), but no pilot flame monitoring device is present (P 800). Pre-purge suppression by external signal is not implemented. Fuel change by OFF and an unlimited post purge time is configured.
  • Page 23 Assignment of Configuration Fault 107 Description Configuration of the controllers incorrect: 1 = O trim is inactive, but the O correctional range is not 0 2 = CO controller is inactive, but the CO correctional range is not 0 3 = CO controller is inactive Requirements: At least one of the monitors that can be activated by parameter P225, P244 or P241 must be ON 4 = Safe O...

  • Page 24: Assignment Of The Programme Monitoring Time - Fault 600

    Assignment of the Programme Monitoring Time - Fault 600 Assignment of the Programme Monitoring Time - Fault 600 Description No effects of the CO/O controller The number of 250 000 burner starts has exceeded Adjustment mode is active Fuel selection is missing Safety interlock chain system is open Air pressure is still pending Safety interlock chain oil is open...
  • Page 25 Assignment of the Programme Monitoring Time - Fault 600 Description 2005 Automatic restart 2006 CPI / POC signal was missing at the start-up...

  • Page 26: Assignment Of Internal Fault 999

    Assignment of Internal Fault 999 Assignment of Internal Fault 999 Description The signal at the terminals changes rapidly for several seconds (100 ms - 200 ms). Stabilise the signal: – Check wiring for loose contacts. – Check pressure switch: Is the pressure safely above or below the set pressure thus preventing the pressure switch from oscillating? Terminal X.10.2 = burner ON Terminal X.10.1 = fault reset...
  • Page 27 Assignment of Internal Fault 999 Description Relay contact jams, does not drop or is controlled externally. – Disconnect the plug of the affected relay output from the BT300 and check whether the error is still present. If yes: Replace the device. If no: Search for an external source of malfunction.

  • Page 28: Assignment Of Co/O 2 Control Faults Or Information

    Assignment of CO/O Control Faults or Information Assignment of CO/O Control Faults or Information NOTICE Depending on the parameter settings, either O trim is deactivated or a fault switching of the burner is triggered (P 142). Factory setting: P 142 = 0 (CO/O control is inactive, burner is not switched off) ot = O control temporarily deactivated - automatic reset if values OK again.
  • Page 29 Assignment of CO/O Control Faults or Information CO faults - Fault description information 0004 fault No probe dynamics - O trim is deactivated (P118) No probe dynamics can be detected. – Correction range in BT300 too small or set to ’0’ 0 = Default setting.
  • Page 30 Assignment of CO/O Control Faults or Information faults - Fault description information 0018 fault Internal fault: O setpoint curve is incorrect. – Reset fault – If the fault still exists: Send error number and diagnostic code to the technical support. –...
  • Page 31 0040 CO fault There is no CO edge information available on the LAMTEC SYSTEM BUS. Lambda Transmitter is incorrectly configured or not connected to LSB. LSB connection is twisted. Lambda Transmitter is not in measuring mode (malfunction/cold start).
  • Page 32 Assignment of CO/O Control Faults or Information Fault/ Comment informa- tion 0043 CO fault Cell resistance of the CO sensor is outside the monitoring range. The probe is too cold. Heating capacity is too low – Check wiring for probe heating and correct if necessary. –...
  • Page 33 Assignment of CO/O Control Faults or Information Fault/ Comment informa- tion 0052 CO fault The CO edge signal is not plausible. The CO edge signal was present constantly for more than 60 s. The controller cannot control out of the CO. –...
  • Page 34 The information in this publication is subject to technical changes. LAMTEC Meß- und Regeltechnik für Feuerungen GmbH & Co. KG Josef-Reiert-Straße 26 D-69190 Walldorf Telefon: +49 (0) 6227 6052-0 info@lamtec.de Telefax: +49 (0) 6227 6052-57 www.lamtec.de Print no. | Copyright  2022...
