- Page 1 Blue Installation manual Blue 12, 16, 21 & HE EN V4.5...
- Page 2 This document is copyrighted and any reproduction of all or part of this document is strictly prohibited, except with the written permission of Hamwells Nederland B.V. The contents of this document are subject to change without notice. The illustrations in this manual may differ from the delivered products. The product shown is for illustration purposes and may differ in color or model from the delivered product.
-
Page 3: Table Of Contents
Contents Safety instructions Symbols Warranty Dimensions Blue basic 1. Installation Blue base Installation instructions Parts checklist Parts Blue base 2. Installation options glass panel / thermostat / shower set Parts checklist 3. Calibration and maintenance Installation manual Blue | V4.5... -
Page 4: Safety Instructions
Symbols The following marking conventions are used throughout This installation guide refers to the Hamwells Blue 12, 16, 21 and HE. Here you will find all the steps you need to go through for a correct this installation guide to draw attention to certain topics installation of the Blue. -
Page 5: Warranty
Blue. If warnings and safety instructions are not followed, there is a risk of danger to people, water damage or damage to the Blue. Hamwells Nederland B.V. is not liable for unsafe situations, accidents and damage, which are the result of among other things: •... -
Page 6: Dimensions Blue Basic
Power supply (mains): 100-240 VAC Max. power consumption: 42W (12, 16, 21, HE) *Including WWHR pipe of desired length 38 cm 15 cm 35 cm Front view Back view Side view Blue 12 Blue 16 Blue 21 Blue HE Installation manual Blue | V4.5... -
Page 7: Installation Blue Base
1. Installation Blue base... -
Page 8: Installation Instructions
Installation instructions This chapter explains how to install the Blue basic. To install the glass panel / thermostat / shower set, go to chapter 2 after installing the Blue basic. Installation steps specific to the Blue HE are included separately. Tools such as drills, screwdrivers, mounting kit and wrenches are not included. -
Page 9: Parts Blue Base
Parts Blue basic 1x Blue basic pre-assembled: - WWHR (Waste Water Heat Recovery) frame - WWHR pipe (12, 16, 21, HE) - Pump 1x water line (50 1x water line (50 cm, - Power supply with cable without plug cm, cold tap water) cold tap water) - Water line (100 cm) WWHR-pipe to pump - Water line (100 cm) sensor unit to pump... - Page 10 1. Temporarily hang the 2. Level the installation frame and mark installation frame on the wall the (mounting) holes. Subsequently, drill using two screws the holes and screw the frame in place. The frame must hang completely level. Floor Installation manual Blue | V4.5...
- Page 11 3. Connect the cold water supply Connect the cold water supply to the WWHR inlet using a flexible water line. Make sure that the Cold water connection water line has a gasket. of the Blue HE Installation manual Blue | V4.5...
- Page 12 4. Connect the drain set 5. Connect the drain set to the to the WWHR pipe(s) sewer system Use the proper drain pipes and gaskets to connect the drains. The WWHR has drain pipes with a 50mm diameter. Blue HE Blue HE Installation manual Blue | V4.5...
- Page 13 6. Place and level the sensor unit. 7. Connect the supplied bend (32 mm) to the back of the sensor unit and connect it to your drain. We do not recommend pouring Use PVC adhesive after you have concrete around the sensor unit. connected the bend to the drain.
- Page 14 7. Connect a siphon (40 mm) to the sensor unit. Make sure that the overflow is lower than the shower drain. Shower drain Shower drain Overflow Overflow Side view Front view Installation manual Blue | V4.5...
- Page 15 8. Connect the water line to the sensor unit 9. Perform the drain test By pouring water into the siphon, you test Make sure that the water line has a gasket. whether all drain parts are watertight. Installation manual Blue | V4.5...
- Page 16 10. Connect the wiring harness to the sensor unit Only connect the main power after everything else is connected! 11. Check if the Blue is working properly (See chapter 3. Calibration and maintenance.) Installation manual Blue | V4.5...
-
Page 17: Installation Options Glass Panel / Thermostat / Shower Set
2. Installation options glass panel / thermostat / shower set... -
Page 18: Parts Checklist
32,6 cm Parts checklist Parts glass panel The glass panel with or without holes / thermostatic tap / shower set is supplied complete. These must be installed per component at the relevant location. Only use the supplied connection water lines for the supplied thermostatic tap and shower set. - Page 19 Parts thermostatic tap Parts shower set 1x thermostatic tap 1x main shower 1x water line (150 cm, main shower to the thermostatic tap) 1x water line (50 cm) 1x water line (80 cm, thermostatic tap to the hand shower) 1x set of control buttons 1x hand shower set Installation manual Blue | V4.5...
- Page 20 1. Mount the frame of the secondary wall There are various options such a metal stud or wooden framework. This varies by location. Frame and retaining wall are not included. Installation manual Blue | V4.5...
- Page 21 2. Mount wall plates (not included) and connect the water water lines from the hand and main shower head. The water line of the hand shower can be connected to either the left or right side. This is connected to the thermostatic tap later.
- Page 22 3. Mark holes in the watertight wall in Dimensions holes wall Dimensions frame front of the frame and cut them out. 16 mm 28 cm 32,9 cm The waterproof wall is not included. With the shower set option, you must also mark and cut Thermostat out/drill the holes for the connections.
- Page 23 4. Place the waterproof wall 5. Tile the wall Installation manual Blue | V4.5...
- Page 24 6. Place the frame on the tiles and seal 7. Install the thermostatic tap the outer edge between the tiles and with the 3 screws the frame with hybrid sealant The frame has 2 cm mounting space all around. The temperature stop must be calibrated at 38 °C. See the manual supplied with the thermostat.
- Page 25 8. Connect the water lines to 9. Open the WWHR valve the thermostatic tap Main shower WWHR output (option shower set) Make sure that the water line has a gasket. Hand shower (option shower set) Hot water supply Handle in line with the valve Installation manual Blue | V4.5...
- Page 26 10. Install the glass panel 11. Install the control knobs The glass panel is secured with magnets. Slide the knobs well back and secure Use glass suction cups to place the glass panel. them with an Allen key. Place the glass panel without holes if you are not using the supplied thermostat.
- Page 27 12. Mount the main shower 13. Mount the hand shower Use PTFE sealing cord. Elbow connection is not included. Installation manual Blue | V4.5...
-
Page 28: Calibration And Maintenance
3. Calibration and maintenance... - Page 29 1. Check if the Blue works properly Fill the siphon and drain completely (approx. 2 liters of water). When you turn on the Blue for the first time or when the power is reconnected or turned on, you will hear the sound of the pump pumping out the water.
- Page 30 2. Maintenance To keep the Blue in perfect condition, it is recommended to clean the shower on a regular basis. This chapter describes the cleaning and maintenance intervals. The table below is an overview of maintenance. We recommend that you never use aggressive cleaning agents such as thinner or acetone.
