Summary of Contents for Lelit PL92T
- Page 1 Extended guide EXTRA content PL92T PL92T-AUS PL92T-AS PL92T-120 230 V 240 V 220 V 120 V 50 Hz 50 Hz 50/60 Hz 60 Hz...
- Page 2 THANK YOU FOR CHOOSING A LELIT PRODUCT Register your product on care.lelit.com To get the most of your coffee machine PL92T visit our LELIT YouTube channel for insights, tutorials, tips and tricks. Save the box and all the packaging material!
- Page 3 Extended guide Index 1. Main specifications 2. Product overview 3. Factory settings 4. Equipment 5. Packing 6. First start-up 7. How to install the water softener filter 8. Espresso and coffee 9. Steam and hot water 10. Stand-by mode 11. Software features 12.
-
Page 4: Main Specifications
Elizabeth - PL92T* 1. Main specifications User Friendly Dual boiler This machine allows anyone This machine is equipped with to make a coffee as good as two boilers: one for steam it tastes at a café thanks to and hot water and made in the 3-button interface and the stainless steel (316L);... - Page 5 Extended guide PIC. 2 LCC (LELIT Control Center) is the brain of our coffee machines. It allows to control the machine functions and adjust the parameters by means of an OLED display.
-
Page 6: Product Overview
11. Back-lit manometer for coffee pre-infusion 2) extraction ON/OFF main switch 12. Steam dispensing knob Hot water dispensing button 13. LCC (LELIT Control Center) Fixed hot water wand 14. Multidirectional, anti-burn steam Coffee brewing group wand Wire grate for drip tray 15. - Page 7 4. Equipment A. 1 dose filter (7-9 g) G. LELIT 58 2-ways filterholder B. 2 doses PLUS H. LELIT 35 l water softener filter filter (14-18 g), IMS Plastic spoon for coffee powder C. Blind filter for backflushing Power cord D.
-
Page 8: First Start-Up
Use the power cord (J) to connect the machine to the electrical mains and turn ON the machine by pressing the ON/OFF (3) switch (Pic 6.2). The LCC display (13) shows the LELIT logo and the software version, the 3 buttons (1-2-4) and the manometer light up for a few seconds. - Page 9 Note. Only for the first start-up, the machine will automatically fill the boiler with water; during this operation some water will flow from the brewing group for nearly 1 minute and the LELIT logo will flash on the LCC display. Let the system finish the operation.
-
Page 10: Espresso And Coffee
Elizabeth - PL92T* 8. Espresso and coffee Choose your coffee filter, insert it into the filterholder (G) and fill it with the adequate quantity of ground coffee. Use the tamper (D) to press the coffee powder in the filterholder (G). Fix the filterholder (G) into the brewing group (6) and make sure the handle is aligned with the padlock symbol present on the group (Pic 8.1). -
Page 11: Steam And Hot Water
Extended guide 9. Steam and hot water Open the steam dispensing knob (12) by turning it anticlockwise, with the steam wand (14) pointed on the drip tray, to drain the small quantity of water. When the steam comes out close the knob. Place the milk jug (code PLA301S-M-L, not included), filled up to the beginning of the spout, under the steam wand (14) and open again the steam knob... -
Page 12: Standby Mode
Elizabeth - PL92T* 10. Stand-by mode 10.1 10.2 10.3 After 30 minutes of inactivity, the machine will go automatically in stand-by mode. The LCC display (13) and the heating elements are disabled and the coffee delivery button (1) flashes each 3 seconds (Pic 10.1). -
Page 13: Software Features
Extended guide 11. Software features Economy mode You can easily enable and disable the steam boiler by pressing just one button. The LCC display shows that the machine is ready for use. Push for more than 3 seconds. The (E) on the LCC display confirms that the machine is in "economy mode". - Page 14 Elizabeth - PL92T* The automatic purge is a cooling flush that allows to have the right extraction temperature. This function could be used before the brewing phase after having activated it. Automatic purge To use this function press together both coffee dispensing buttons.
- Page 15 Extended guide The LELIT Elizabeth can have shot times programmed to either of the two buttons. This allows the coffee shot to end when the programmed time has been reached. Automatic shot time Press 3 times for button 1. Press 4 times for button 2.
- Page 16 Wait till it stops flashing and return to home screen. The LELIT Elizabeth can have the pre-infusion programmed for each of the two coffee dispensing buttons. It is the act of pre-wetting the bed of ground coffee inside a filterholder before starting the brewing process.
- Page 17 Extended guide 12. LCC Technical menu The technical menu offers extra customization settings for the more expert users. Please remember that these settings require time before seeing results in the cup of coffee, however if you think that you changed your machines values too much, all the settings can be restored with the following procedure: With the machine turned OFF Hold pressed both...
- Page 18 Note. PID is an algorithm that regulates the boiler temperature according to the temperature detected by the probe (NTC) located inside the boiler. PL92T having two boilers has therefore two working PID: the letter c at the end of the parameter (e.g.
- Page 19 Extended guide 12.1.1. Functions of the PID values time The default regulation of the temperature is managed according to an algorithm called PID. The constants that determine the thermoregulation are called: • Kp: proportional constant • Ki: integrative constant • Kd: derivative constant •...
- Page 20 For more advanced user, pre-infusion can be done with the pump (bloom pre-infusion) or in combination with the boiler (steam pre-infusion). This means that LELIT Elizabeth can perform steam pressure pre-infusion by setting BLS1 and BLS2 and bloom pre-infusion by setting BLP1 and BLP2. Each setting works on a specific coffee button in order to achieve the best possible result;...
- Page 21 Extended guide SCENARIO 1 Steam pre-infusion BLS1 and BLS2 regulate the pump run time over pre-infusion time. For example, if BLS1/2 is 3 and the pre-infusion is 7 seconds long, in the remaining 4 seconds the boiler is working. In this scenario, the machine will perform a soft pre-infusion and the coffee will have more body.
-
Page 22: The Art Of Espresso Coffee
The LELIT grinders let you adjust the durability of the product you have grinding level to suit the coffee blend purchased. - Page 23 Extended guide Coffee varieties These sensations can last just a moment or can persist for a few minutes in your mouth. The taste The choice of the blend is an essential is round and well structured. The factor for making the ideal coffee for acid and bitter perceptions are well your taste.
- Page 24 The best jugs to use are made of stainless steel and have a spout, like the LELIT milk jug (code PLA301S – PLA301M – PLA301L - not included). The jug should never be more than half filled with milk.
- Page 25 Extended guide tapping the jug on the countertop to remove any air bubbles and then rotating it to keep the milk and froth well amalgamated. The result should be a smooth, creamy surface without any bubbles. Pouring the milk You should leave the milk to settle for a least half a minute, so we suggest you always prepare it before making the coffee.
-
Page 26: Daily Cleaning
(Pic 15.1). Group cleaning. After each extraction empty the coffee filter, wash the filterholder (G) and the relative filter with tap water and use a LELIT brush to eliminate the coffee residues from the group gasket (Pic 15.2). -
Page 27: Weekly Cleaning
Extended guide Steam wand cleaning. After frothing the milk, clean the nozzle of the steam wand (14) using a soft cloth and dispense a small quantity of steam to eliminate every possible milk rest in the holes (Pic 15.3). 16. Weekly cleaning Note. -
Page 28: Annual Cleaning
Elizabeth - PL92T* Re-insert the filterholder (G) in the group and repeat the previous operation, without using the detergent powder. Remove the filterholder (G) and take out the blind filter (C). Empty the drip tray (15) and rinse the filterholder (G), the filters and the tray with plenty of tap water. -
Page 29: Most Common Problems
Extended guide 18. Most common problems The LCC flashes continuously and the machine is never ready a. If the steam mode works, please run a total reset. b. Set the ECO mode and check if the machine works (only coffee services). c. - Page 30 Elizabeth - PL92T* The coffee cream is not thick a. Following the steps of a correct coffee extraction, try to select a higher temperature range through the LCC (13). b. Select a suitable coffee blend knowing that a thick cream needs a good percentage of Robusta: read more about this in Chapter 13.
- Page 31 Extended guide Alarms shown on the display Missing water into the tank. There is no water into the tank. Remove the water tank from its housing (9). Fill the tank with water at room temperature. Reposition the tank in the housing. Temperature probe of the coffee boiler in short circuit.
-
Page 32: Warranty Terms
Elizabeth - PL92T* 19. Warranty terms Legal warranty This product is covered by the warranty laws valid in the country where the product has been sold; specific information about the warranty terms can be given by the seller or by the importer in the country where the product has been purchased. - Page 33 EC DECLARATION OF CONFORMITY Gemme Italian Producers srl declares under its own responsibility that the product: Coffee machine type: PL92T to which this declaration relates conforms to the following standards: EN 60335/1 - EN 60335/2/15 - EN 61000/3/2 - EN 55014...
- Page 34 LELIT.COM REV 00, dated 20/03/21 ©2021 Gemme Italian Producers Srl. All Rights Reserved...
