User Manual
for the following models:
Pro Line - Mara
PL62S
PL62
PL62T
Dimensions:
22x40x35,6 cm
Weight:
18,8 kg
Power supply:
230V 50Hz/ 120V 60Hz
Power:
1400W + 50W
Pump:
15 bar
Boiler pressure:
1,2 bar
Water tank capacity:
2,5 lt
Copper boiler capacity:
1,4 lt
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO Line - Mara PL62S and is the answer not in the manual?

Questions and answers

Related Manuals for Lelit PRO Line - Mara PL62S

Summary of Contents for Lelit PRO Line - Mara PL62S

  • Page 1 User Manual for the following models: Pro Line - Mara PL62S PL62 PL62T Dimensions: 22x40x35,6 cm Weight: 18,8 kg Power supply: 230V 50Hz/ 120V 60Hz Power: 1400W + 50W Pump: 15 bar Boiler pressure: 1,2 bar Water tank capacity: 2,5 lt Copper boiler capacity: 1,4 lt...
  • Page 2 PRO Line - Mara - PL62S · PL62 · PL62T THANK YOU FOR CHOOSING US Careful design and choice of components are the secret of the excellent performance of all of our models. We develop our products with technology applied only to the best professional machines.

  • Page 3: Table Of Contents

    Lelit Espresso - English Index Safety notes Main specifications E61 type group Product overview Instructions for use The art of espresso coffee Cleaning and maintenance Solving the most common problems Warranty terms...

  • Page 4: Safety Notes

    PRO Line - Mara - PL62S · PL62 · PL62T Safety notes Please read this manual carefully before using the machine. This coffee machine is reccomended for making 1 or 2 cups of coffee and has multi-directional tube for steam and one for hot water. The controls on the front panel have easily understandable symbols.
  • Page 5 Lelit Espresso - English IMPORTANT if they have been given supervision or instruction concerning use of the SAFEGUARDS appliance in a safe way and if they understand the hazards involved. Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.
  • Page 6 PRO Line - Mara - PL62S · PL62 · PL62T - Any use other than that described - All the packing material (plastic above is improper and could be haz- bags, polystyrene, etc.) should be ardous; the manufacturer accepts no keep out of the reach of children.
  • Page 7 Lelit Espresso - English outlet. - The use of accessory attachments not recommended by the appliance - To disconnect the appliance, turn manufacturer may result in fire, elec- any control to “off”, then remove tric shock or injury to persons.
  • Page 8 PRO Line - Mara - PL62S · PL62 · PL62T merse cord, plugs in water or other - The parts marked with “CAUTION liquid. HOT” are very hot, therefore, the utmost care should be taken when - Do not use adapters, multiple sock- operating near them.

  • Page 9: Main Specifications

    Lelit Espresso - English Main specifications We design our machines based on our customers’ needs. We are sure that the features selected for this model will meet all your wishes, so you can make perfect tasting coffee for yourself and your guests.

  • Page 10: E61 Type Group

    PRO Line - Mara - PL62S · PL62 · PL62T E61 type group The E61 type group is a mechanical distribution unit that we use in high quality espresso coffee machines to enhance the organoleptic properties, the flavour and aroma of authentic Italian Espresso. The mechanism combines a thermal siphon system and a pre-infusion process to extract the most flavour and aroma from the coffee.

  • Page 11: Product Overview

    Lelit Espresso - English Product overview Take your new espresso coffee machine out of the box and have a look at the various components and accessories designed for you. Water tank cover. Cup warmer. LED machine on. LED heating element.

  • Page 12: Instructions For Use

    PRO Line - Mara - PL62S · PL62 · PL62T Instructions for use Lelit coffee machines are not automatic. To make a good cup of coffee, you must know how to use them properly and will need a bit of practice. Follow the instructions carefully.
  • Page 13 Lelit Espresso - English Switch on the coffee machine Caution. Ensure the power supply voltage is the same as that indicated on the information plate and that the supply system has an adequate circuit breaker. C.1 Connect the power cord (c) to the socket on the back of the machine.
  • Page 14 PRO Line - Mara - PL62S · PL62 · PL62T to start Making an Espresso Thanks to the default settings, the machine is immediately ready to make an Espresso. Note. The machine comes with a cup warmer (9). Using warm cups enhances the organoleptic qualities, the flavour and aroma of an Espresso.
  • Page 15 Lelit Espresso - English F.4 Insert the filter holder (e) in the distribution unit (13) and fasten it firmly, at least up to align the handle with the padlock symbol indicated on the group. F.5 Place one or two coffee cups on the cup rack (8), under the filter holder (e).
  • Page 16 PRO Line - Mara - PL62S · PL62 · PL62T Point the steam wand at the cup rack and release some steam at least once. Clean the wand (4) carefully with a sponge or a clean cloth. The chapter on “Cleaning and maintenance”...

  • Page 17: The Art Of Espresso Coffee

    (Espresso machine) of coffee into an Espresso for connois- Lelit coffee machines are designed seurs! These are the “5 M’s”; in Italian: and built to let you adjust the water miscela (blend), macinatura (grinding), pressure and temperature to your re- macchina (machine), manualità...
  • Page 18 PRO Line - Mara - PL62S · PL62 · PL62T 5- Manutenzione (Maintenance) Espresso on its own. Daily maintenance, scheduled mainte- The perfect Espresso has a top layer nance and care of the machine will en- of cream 2-3 mm thick, a nut brown sure the quality of the beverage and to dark brown colour, with reddish the durability of the product you have...
  • Page 19 The best jugs to use are made of stainless steel and have a spout, like the Lelit jug (code PL101-PL102 - not included). The jug should never be more than half filled with milk.
  • Page 20 PRO Line - Mara - PL62S · PL62 · PL62T Insert the wand all the way down and tilt the jug to create a vortex. Heat the milk to the desired temperature, with- out exceeding 65°C. Close the steam. Prepare the milk by first tapping the jug on the countertop to remove any air bubbles and then rotating it to keep the milk and froth well amalga-...

  • Page 21: Cleaning And Maintenance

    Use a soft cloth, preferably microfiber, like the Lelit cloth (code MC972 - not in- cluded), and moisten it with plain water. Do not use abrasive detergents and do not immerse the machine in water.
  • Page 22 To avoid the formation of limescale, which can also deposit in the inter- nal circuits, we recommend the use of our Lelit resin filter (code MC747 - MC747PLUS) to soften the water. Please insert the filter in the tank following the This is done very easily, simply by fol- instructions on the packaging.

  • Page 23: Solving The Most Common Problems

    Lelit Espresso - English Solving the most common problems We recommend careful reading of this guide in order to solve the most common problems before referring to an authorised service centre. The coffee comes out too cold The machine has not reached the right Follow the instructions in the paragraph on temperature.

  • Page 24: Warranty Terms

    PRO Line - Mara - PL62S · PL62 · PL62T Warranty terms Legal warranty This product is covered by the warran- ty laws valid in the country where the product has been sold; specific infor- mation about the warranty terms can be given by the seller or by the importer in the country where the product has been purchased.
  • Page 25 Lelit Espresso - English IMPORTANT INFORMATION For the correct disposal of the product in accordance with EU DI- RECTIVE 2002/96/EC and with Legislative Decree no. 151 of 25 July 2005. At the end of its working life, the product must not be disposed of as urban waste.
  • Page 26 User manual code 7800016, rev. 04, dated 20/09/18 Art. PL62S - PL62 - PL62T ©2018 Gemme Italian Producers Srl. All Rights Reserved...
