User Manual
for the following models:
Vip Line
Grace - PL81T
Victoria - PL91T
Dimensions:
22.5x27x38 cm
Net Weight:
PL81T 7.4 kg - PL91T 9.2 kg
Power supply:
230V 50Hz/ 120V 60Hz
Power output:
PL81T 1000 W - PL91T 1200 W
Pump pressure:
15 bar
Water tank capacity:
2.5 lt
Brass boiler capacity:
PL81T 250 ml - PL91T 300 ml
EN
Advertisement
Table of Contents
Related Manuals for Lelit VIP Victoria PL91T
Summary of Contents for Lelit VIP Victoria PL91T
- Page 1 User Manual for the following models: Vip Line Grace - PL81T Victoria - PL91T Dimensions: 22.5x27x38 cm Net Weight: PL81T 7.4 kg - PL91T 9.2 kg Power supply: 230V 50Hz/ 120V 60Hz Power output: PL81T 1000 W - PL91T 1200 W Pump pressure: 15 bar Water tank capacity:...
- Page 2 Write down the serial number of your product Serial number Purchased from Date of purchase For more information, please register your product on care.lelit.com...
-
Page 3: Table Of Contents
Lelit Espresso - English Index Safety notes Main specifications LCC - Lelit Control Center Product overview Instructions for use The art of Espresso coffee Cleaning and maintenance Solving the most common problems Warranty terms... -
Page 4: Safety Notes
VIP Line - Grace - PL81T · Victoria - PL91T Safety notes Warnings - Please read carefully before use. This espresso machine is suit- able for the preparation of 1 or 2 cups of coffee; it is equipped with a mul- ti-directional wand for dispensing steam and hot water. - Page 5 Lelit Espresso - English IMPORTANT or instruction concerning use of the appliance in a safe way and if they SAFEGUARDS understand the hazards involved. Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.
- Page 6 VIP Line - Grace - PL81T · Victoria - PL91T - Store the packaging material (plas- - The appliance must not be exposed tic bags, polystyrene, etc.) out of the to atmospheric agents (rain, sun, reach of children. ice). - The appliance is only designed for - If the appliance is stored in rooms making espresso coffee or hot drinks where the temperature can go be-...
- Page 7 Lelit Espresso - English - To reduce the risk of injury do not the risk of electric shock cannot be drape cord over the counter top or excluded, therefore, the following table top where it can be pulled on safety warnings should be carefully by children or tripped over uninten- observed.
- Page 8 VIP Line - Grace - PL81T · Victoria - PL91T always freely accessible so that the - Warning: hot surfaces remain hot plug can be easily removed when for a certain time also after use. necessary. - Take care to avoid contact with water - When removing the plug, always spray or jets of steam.
-
Page 9: Main Specifications
Lelit Espresso - English Main specifications We design our machines based on our customers’ needs. We are sure that the features selected for this model will meet all your wishes, so you can make perfect tasting espresso for yourself and your guests. -
Page 10: Lcc - Lelit Control Center
VIP Line - Grace - PL81T · Victoria - PL91T LCC - Lelit Control Center LCC (Lelit Control Center) is the brain of the new Lelit espresso machines. It has an elegant, graphic LED display of the latest generation. It controls all the functions of the machine and allows you to adjust the settings, as well as giving valuable tips on how to achieve the best results. -
Page 11: Product Overview
Wide cup warmer. What’s in the box Plastic tamper Coffee measuring spoon Power cord Blind filter Paper pod filter (only for PL81T) Filter holder with filter for 1 and 2 cups Support for espresso cups LELIT Resin filter, cod. MC747... -
Page 12: Instructions For Use
VIP Line - Grace - PL81T · Victoria - PL91T Instructions for use Lelit coffee machines are not automatic. To make a good cup of coffee, you must know how to use them properly and will need a bit of practice. Follow the instructions carefully. - Page 13 (plug) into the wall socket. C.2 Turn on the espresso machine by pressing the main on/off switch (2). The dis- play (12) will show the Lelit logo, the three switches and the gauge will go on for a short time.
- Page 14 Preparing the machine for making coffee E.1 Turn on the espresso machine by pressing the main on/off switch (2). The display (12) will show the Lelit logo, the three switches and the gauge will go on for a short time.
- Page 15 Lelit Espresso - English F.2 Pour the desired amount of ground coffee into the filter. Note. We suggest 7 g for one cup and 14 g for two cups. F.3 Press the coffee with the tamper (a) and remove any coffee residues from the edge of the filter holder.
- Page 16 Adjusting the LCC settings The LCC - Lelit Control Center (12) has pre-set default settings. Here you can learn how to adjust them. Changing the factory settings J.1 Press the “-” button to enter settings mode, and scroll through the menu.
- Page 17 Lelit Espresso - English J.2 Press “+” to change the setting. The setting flashes. J.3 Change its value and/or state by using the “-” and “+” buttons. J.4 Three seconds after the last press of a button, LCC stores the data and exits from settings mode.
-
Page 18: The Art Of Espresso Coffee
Ristretto (Strong) about 20 ml – Espresso about 30 ml – Lungo (Long) about 60 ml. The “5 M’s” preserves its taste and aroma. The Lelit grinders let you adjust the grinding level to suit the coffee blend in order to es-... - Page 19 Lelit Espresso - English pressing, water temperature and pres- Robusta sure, not just to make an Espresso, but to make the one that is just right for you. It is grown between 200/600 m Spicy aroma. Caffeine between 1.8 ~ 4%...
- Page 20 The best jug, on the other hand, is one made of stainless steel, provided with a spout, such as Lelit models (codes PL101 PL102-not included). The level of milk should never exceed half the volume of the jug.
- Page 21 Lelit Espresso - English Insert the wand all the way down and tilt the jug to create a vortex. Heat the milk to the desired temperature, without ex- ceeding 65°C. Close the steam. Prepare the milk by first tapping the jug...
-
Page 22: Cleaning And Maintenance
Use a soft cloth, preferably microfiber, like the Lelit cloth (code MC972 - not included), and moisten it with plain water. Do not use abrasive detergents and do not immerse the machine in water. - Page 23 In order to backflush, follow these in- of our Lelit resin filter to soften the structions: water. Please insert the filter in the a) Insert the blind filter (d) provided tank following the instructions on the into the holder (f).
- Page 24 VIP Line - Grace - PL81T · Victoria - PL91T stribution by pressing the coffee swi- tch (3) again. h) Use the brush (code PL106 – not in- cluded) to clean the coffee group (6), the group gasket and the fixing rims of the group.
-
Page 25: Solving The Most Common Problems
Lelit Espresso - English Solving the most common problems We recommend careful reading of this guide in order to solve the most common problems before referring to an authorised service centre. The coffee is too cold when dispensed The machine has not reached its operating Follow the instructions in the “Making an... - Page 26 VIP Line - Grace - PL81T · Victoria - PL91T Alarms shown on the display. There is no water into the tank. On the display the following icon appears: Remove the water tank from its housing. Fill the tank with water at room temperature. Reposition the tank in the housing The temperature probe is in short circuit, all On the display the following icon appears:...
-
Page 27: Warranty Terms
Lelit Espresso - English Warranty terms Legal warranty This product is covered by the warran- ty laws valid in the country where the product has been sold; specific infor- mation about the warranty terms can be given by the seller or by the importer in the country where the product has been purchased. - Page 28 VIP Line - Grace - PL81T · Victoria - PL91T IMPORTANT INFORMATION For the correct disposal of the product in accordance with EU DI- RECTIVE 2002/96/EC and with Legislative Decree no. 151 of 25 July 2005. At the end of its working life, the product must not be disposed of as urban waste.
- Page 29 Instruction manual code 7800015, REV 02, dated 20/09/17 - Models PL81T - PL91T ©2015 Gemme Italian Producers Srl. All Rights Reserved...
