- Page 1 USER’S GUIDE Installation, Operation, and Maintenance for your product. Built-In Beverage Refrigerator Model - ABR241SG www.avallon.com 1-866-471-7427...
-
Page 2: Important Safety Information
Important Safety Information Improper handling can cause serious damage to the Avallon beverage refrigerator and/or injury to the user. This beverage refrigerator is designed for domestic indoor use only. Do not use the unit for industrial or commercial use. Any other use may invalidate the warranty. Please review the rating label located on the rear panel of the unit for electrical and other technical data related to this unit. -
Page 3: Table Of Contents
Table of Contents Important Safety Information ........................ 2 Introduction............................4 Parts Identification ..........................5 Installing Your Beverage Refrigerator ....................6 Installing Your Beverage Refrigerator Continued ................. 7 Installing Your Door Handle and Shelves ....................8 Operation ............................... 9 Internal Light ............................10 Defrosting ............................. -
Page 4: Introduction
Introduction Thank you for purchasing your Avallon beverage refrigerator. Avallon is dedicated to developing products that will enhance your lifestyle with superior quality and distinctive features. Please visit www.avallon.com for more information on your product and other Avallon products. This manual contains important information regarding the proper installation, use, and maintenance of your beverage refrigerator. -
Page 5: Parts Identification
Parts Identification Seamless Stainless Door Control Panel Slide-Out Shelf Door Handle Door Lock Front Vent Carbon Filter Carbon Filter A built-in carbon filter Internal Fan protects your beverage by acting as a natural barrier against harmful odors. Internal Fan This is an air-cooled unit equipped with an internal fan that maintains a consistent... -
Page 6: Installing Your Beverage Refrigerator
Installing Your Beverage Refrigerator The beverage refrigerator should be installed in accordance with local electrical code requirements. It should also be placed in a location that is strong enough to support its total weight, keeping in mind that it will weigh substantially more when fully loaded than when empty. -
Page 7: Installing Your Beverage Refrigerator Continued
Installing Your Beverage Refrigerator Continued INSTALLING: When installing the beverage refrigerator under a counter, follow the recommended spacing dimensions shown. • To ensure proper service access and ventilation, allow between 2-3 inches of clearance at the back as shown in the diagram. •... -
Page 8: Installing Your Door Handle And Shelves
Installing Your Door Handle and Shelves INSTALLING THE DOOR HANDLE: 1. Open the door and carefully pull the door gasket around the area where the handle is to be installed. 2. Insert each Phillips head screw through the gasket side of the door until the screw pass through the door. 3. -
Page 9: Operation
Operation INSTALLATION CHECK-LIST BEFORE OPERATION: 1. Have all packing materials and tape been removed from the interior and exterior of the beverage refrigerator? 2. Have the installation instructions been followed, including connecting the machine to electricity? 3. Has proper grounding been installed for the beverage refrigerator? 4. -
Page 10: Internal Light
Internal Light This refrigerator is equipped with top and side internal lights that can be either blue or white in color – whichever you choose. Additionally, because it comes with a glass door, the lights have the option to display in two different modes: Constant Mode and Automatic Mode. -
Page 11: Normal Sounds
Normal Sounds Your new beverage refrigerator may make sounds that are not familiar to you. Most of the new sounds are normal. Hard surfaces like the floor or walls can make the sounds seem louder than they actually are. The following describes the kinds of sounds that might be new to you and what may be making them. -
Page 12: Troubleshooting
Troubleshooting ISSUE POSSIBLE CAUSE SOLITION The beverage • The room temperature is higher than • Run the refrigerator at the appropriate ambient refrigerator turns on the recommended ambient environment. temperature. and off frequently. • The door is being opened often. •... -
Page 13: Specifications
Specifications DESCRIPTION OF PRODUCT Built-In Beverage Cooler MODEL ABR241SG VOLTAGE / FREQUENCY AC 115 / 60 Hz AMPERAGE 1.1A INPUT POWER 120W COLOR Black Cabinet with Stainless Steel Door STORAGE CAPACITY 152 Cans REFRIGERANT R600a, 1.4oz. TEMPERATURE RANGE 34 to 50 F°... - Page 14 Once an Avallon authorized representative has con- firmed that your product is defective and eligible for warranty service, the product must be returned to an Avallon authorized repair facility.
- Page 15 AVALLON GLOBAL, LLC 3736 Bee Cave Rd. STE 1 #188 West Lake Hills, TX 78746 Toll Free: 1-866-471-7427 Web: http://www.avallon.com E-mail: service@avallon.com Product contents and specifications may change without notice. Copyright © 2015 Avallon Gobal, LLC...
