PG&E TOOL LENDING
LIBRARY – SAN RAMON
3301 Crow Canyon Rd.
San Ramon, CA 94583
Phone: 925-866-4343
pge.com/tools
"PG&E" refers to Pacific Gas and Electric Company, a subsidiary of PG&E Corporation. ©2017 Pacific Gas and Electric Company. All rights reserved. These offerings are funded by California utility customers and
administered by PG&E under the auspices of the California Public Utilities Commission.
HOBO MX Gateway
Quick Start Guide
Overview
The HOBO MX Gateway provides near real-time data monitoring for most HOBO MX
series loggers by automatically transmitting logged data to the
easily set up the gateway with the
computer. Once configured, the gateway uses Bluetooth to regularly check for
measurements from up to 100 loggers within range. Logger measurements are then
uploaded from the gateway to HOBOlink via Ethernet or WiFi, At this web site you can
display your data in a dashboard, export data for further analysis, and set up automatic
email or text alarm notifications,
HOBOlink requires a user account and the borrower can use the Tool Lending Library's
account. If WiFi is used to transmit data to HOBOlink, the borrower must provide their own
WiFi network.
The contents of this application note are:
Setting up the Gateway
•
Setting up MX Loggers with the Gateway
•
•
Managing and Sharing Gateway Data: Exporting Data, Scheduling Data Delivery,
Downloading Data Files
Creating a New Dashboard
•
Setting up the Gateway
.
1
Download the HOBOconnect app to a phone or tablet from the App Store® or Google
Play™ or download the app to a Windows computer from
www.onsetcomp.com/products/software/hoboconnect .
a. Open the app and enable Bluetooth in the device settings if prompted. Note that
you must be connected to the internet for the app to launch.
b. Tap
and sign-in to the Tool Lending Library HOBOlink account with these
credentials:
Username: pectools
Password: TL!B0rrow3r
Tool Requests
To request tools, visit our website at pge.com/tools.
HOBOconnect app
on your phone, tablet, or Windows
HOBOlink
website. You can
Advertisement
Related Manuals for Onset HOBO MX
Summary of Contents for Onset HOBO MX
- Page 1 HOBO MX Gateway Quick Start Guide Overview The HOBO MX Gateway provides near real-time data monitoring for most HOBO MX series loggers by automatically transmitting logged data to the HOBOlink website. You can easily set up the gateway with the...
- Page 2 HOBO MX Gateway Quick Start Guide 2. Power up and connect the gateway via WiFi. a. Connect the AC adapter to the gateway and plug it in b. In the HOBOconnect app, click on and wait for the gateway to boot up and appear in the app.
-
Page 3: Exporting Data
HOBO MX Gateway Quick Start Guide 4. Select Gateway for the “Upload Data via” configuration setting. 5. Tap “Start” to save the new logger configuration settings, tap the back arrow to return to the main menu. The gateway uses Bluetooth Low Energy to communicate over the air with loggers within range. Ensure that loggers are deployed within a 100-foot range of the gateway. - Page 4 HOBO MX Gateway Quick Start Guide 6. Make sure that the “Active” checkbox is selected. If the box is not selected, then the data will not be delivered. 7. Select the "Email on delivery failure" checkbox if you want to be notified when the exported file is unable to be delivered.
- Page 5 HOBO MX Gateway Quick Start Guide 11. Click when done. The new scheduled delivery will be listed at the top of the screen. The status will show that the email delivery is pending and the next run time for the export. The email message indicates the time period included in the file. The first delivered file will contain data from the time frame selected in the export settings.
- Page 6 HOBO MX Gateway Quick Start Guide 6. Select the time zone to use for the data displayed in the dashboard. 7. Add up to 20 widgets to the dashboard. To add a widget, you can either: .Click the next to the logger name under “Devices” and click one of the preassigned sensor widgets from the list to add it to the dashboard b.
