EP.V.32907.04 | 09/2022
EN
USER MANUAL
Safety storage cabinets for storage
and charging of lithium ion batteries
10 YEARS WARRANTY
Upon conclusion of an asecos service and maintenance agreement (PREMIUM
tari ), you will get a warranty extension for up to 10 years for your ION-LINE safety
storage cabinet.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ION-CHARGE-90 and is the answer not in the manual?

Questions and answers

Related Manuals for asecos ION-CHARGE-90

Summary of Contents for asecos ION-CHARGE-90

  • Page 1 Safety storage cabinets for storage and charging of lithium ion batteries 10 YEARS WARRANTY Upon conclusion of an asecos service and maintenance agreement (PREMIUM tari ), you will get a warranty extension for up to 10 years for your ION-LINE safety storage cabinet.
  • Page 2 ION-CHARGE-90 IO90.195.060.K9.WDC IO90.195.060.L8.WDC IO90.078.059.057.U9.S ION-CHARGE PRO-90 IO90.195.120.K3.WDC...
  • Page 3 YOUR PERSONAL DOCUMENTATION TO THE asecos SAFETY CABINET Dear Customer, you have made a decisive investment in safety for your company by purchasing this asecos safety storage cabinet. You now own an innovative product made of top-quality materials guaranteeing the highest quality standards.

  • Page 4: Table Of Contents

    1. NOTES • GUIDELINES • GUARANTEE ..........5 1.1.

  • Page 5: Notes • Guidelines • Guarantee

    The guarantee for this product is agreed between you (the customer) and your dealer (the seller). As the manufacturer, asecos guarantees the products listed in the operating instructions for a period of 24 months from the date of delivery. All model safety equipment are subject to a compulsory annual inspection by spe- cialised sta authorised by the manufacturer.

  • Page 6: Transport

    2. TRANSPORT CAUTION: Transport the cabinet in an upright position on a pallet truck, tied and secured against slipping, until the fi nal place of installation is reached.The transport locks in the door joints may only be removed directly at the place of installation! Inappropriate transport can lead to concealed damage to the fi re protection insulation! We can only guarantee the necessary quality if the cabinet is transported to the place of its use by our specially trained sta .

  • Page 7: Q-Mover

    ATTENTION: The doors must be locked prior to transport! The extraction unit is inside the cabinet and is only mounted after the in-plant transport to the place of use. IO90.195.120.K3.WDC IO90.195.060.K9.WDC IO90.195.060.L8.WDC 4× IO90.078.059.057.U9.S IO90.078.059.057.U9.S plinth with castors 2.4. Q MOVER •...

  • Page 8: Installation

    3. INSTALLATION 3.1. ALIGNMENT OF THE CABINETS CAUTION: Door elements must not scrape against the fi re prevention seals in the fold of the door when opening and closing! Doors with an automatic closing mechanism must close automatically from every position and the lock must be able to lock! IO90.195.120.K3.WDC IO90.195.060.K9.WDC...

  • Page 9: Locker System

    IO90.078.059.057.U9.S The drawer is not permanently self-closing. The cabinet has a cylinder lock with a locking status indicator. The drawer has a thermal release and closes automatically in the event of a fi re. ATTENTION: The owner/user must ensure that all doors are kept closed whenever the contents of the cabinet are not being accessed.

  • Page 10: Storage Levels With Power Socket Strips

    5.2. STORAGE LEVELS WITH POWER SOCKET STRIPS LOAD CAPACITY KG/ IO90.195.120.K3.WDC DRUM PLATFORM max. 75 kg max. 50 kg max. 180 kg Standard interior equipment Only special Only interior interior equipment: equipment with grids: Order No. 38520 Order No. 38776 / 38772 Order No.

  • Page 11: Ventilation

    fi re protection and CE conformity are maintained. For this purpose, the cabinet must be handed over to the main factory of asecos GmbH in Gründau, where the specialist department - depending on the degree of damage - makes an assessment of the economic e ciency and technical possibilities of a repair.

  • Page 12: Fire Inside The Cabinet (Battery Fire)

    8.1. FIRE INSIDE THE CABINET BATTERY FIRE • For fast transport the cabinets are equipped with a transport base. The cabinets are automatically disconnected from the mains supply in the case of transport. NOTE for 2-door tall cabinets Evacuation by at least 2 persons is recommended. CAUTION: The doors must be locked before transport! Depending on the door heights, it may be necessary to remove the ventilation attachment beforehand.

  • Page 13: Opening The Cabinet After The Fire

    IO90.078.059.057.U9.S plinth with castors 8.2. OPENING THE CABINET AFTER THE FIRE CAUTION: Do not open the cabinet until it has cooled down. This is 6 times the fi re duration! The cabinet may only be opened by authorised personnel (e.g. fi re brigade)! Depending on the duration of the fi...

  • Page 14: Safety Checks

    This annual check can be carried out with the necessary care, and for securing your warranty claims in the case of fi re, only by an authorised asecos employ- ee (refer also to our service brochure regarding this).

  • Page 15: Technical Data

    10. TECHNICAL DATA IO90.195.060.K9.WDC IO90.195.120.K3.WDC Type External dimensions W x D x H 599 x 615 x 1953 1193 x 615 x 2224 Internal dimensions W x D x H 450 x 522 x 1647 1050 x 522 x 1647 Weight without interior equipment Distributed load kg/m²...

  • Page 16: Io90.195.120.K3.Wdc

    12. IO90.195.120.K3.WDC 12.1. INSTALLATION OF THE EXTRACTION UNIT The extraction unit is for the avoidance of a heat accumulation in the interior during the charging process inside the cabinet. The exhaust air from the cabinet is exhausted directly into the room. Connection to an exhaust duct is not necessary.

  • Page 17: Self-Test

    Retrofi tting is easy due to the plug-in connection, so that no intervention in the electrical components is necessary. 12.3. SELF TEST Starts 5 seconds after connection to the mains supply 12.4. ERROR DURING SELF TEST ATTENTION: After pressing the reset button, the self-test begins again. If the error persists, please contact the asecos Service department.

  • Page 18: Error And Alarm Overview

    12.5. ERROR AND ALARM OVERVIEW EVENT LED GREEN LED RED ACOUSTIC ALARM ACTIONS Error during self-test turned on 5 signal tones 1.) Restart with RESET button if error persists: 2.) Contact Service Service interval reached fl ashing Contact Service Power failure Flashes 3 short signal tones every 60 Check power supply...

  • Page 19: Warning/Fire Suppression System

    12.7. WARNING/FIRE SUPPRESSION SYSTEM • The warning/fi re suppression system o ers the option of connection to a constantly manned building man- agement system or fi re alarm centre. • Make use of this option so that trained rescue personnel can be quickly alerted and be on-site in a very short time and, following an initial assessment of the situation, immediately initiate further measures (for example, transporting the cabinet out of the building).

  • Page 20: Alarm Stage 2

    fi re protection and CE conformity are maintained. For this purpose, the cabinet must be handed over to the main factory of asecos GmbH in Gründau, where the specialist department - depending on the degree of damage - will make an assessment of the economic e ciency and technical possibilities of a repair.

  • Page 22: Io90.195.060.K9.Wdc

    13. IO90.195.060.K9.WDC 13.1. CONNECTION TO THE POWER SUPPLY Connections on the headpiece: Mains plug connector Potential-free switch contact Connection to the power supply 230 V Connection to the power supply with 400 V (optional with item 38038) 400 V NOTE: Retrofi...

  • Page 23: False Alarm Of The Smoke Detector

    Connector (AC) / (DC) (AC) / (DC) Internal alarm contact (AC) / (DC) Connection instructions • Use only the supplied mating part (colour-coded brown) to the plug for the connection. • The connection must be done by a qualifi ed electrician. •...

  • Page 24: Io90.195.060.L8.Wdc

    14. IO90.195.060.L8.WDC 14.1. CONNECTION TO THE POWER SUPPLY Connections on the headpiece: Mains plug connector Potential-free switch contact Connection to the power supply 230 V 14.2. ERROR AND ALARM OVERVIEW EVENT LED GREEN LED RED ACOUSTIC LED ON THE ACTIONS ALARM COMPARTMENT GREEN/RED...

  • Page 25: Potential-Free Alarm Contact

    14.3. POTENTIAL FREE ALARM CONTACT NOTE: The potential-free alarm contact is used to connect a signal to a control centre/control room. Direct integration into a fi re alarm control panel (FACP) is not recommended or may only be carried out in consul- tation with the person responsible for the system.

  • Page 26: Io90.078.059.057.U9.S

    15. IO90.078.059.057.U9.S 15.1. CONNECTION TO THE POWER SUPPLY Mains plug connector Potential-free switch contact NOTE: Retrofi tting is easy due to the plug-in connection, so that no intervention in the electrical components is necessary. Connection to the power supply 230 V Connection to the power supply with 400 V (optional with item 38038)

  • Page 27: False Alarm Of The Smoke Detector

    Connector (AC) / (DC) (AC) / (DC) Internal alarm contact (AC) / (DC) Connection instructions • Use only the supplied mating part (colour-coded brown) to the plug for the connection. • The connection must be done by a qualifi ed electrician. •...
  • Page 28 +34 935 745911 +34 935 745912 info@asecos.es asecos Ltd. asecos asecos Schweiz AG Safety and Environmental Protection Safety and Environmental Protection Inc. Sicherheit und Umweltschutz Profile House 19109 West Catawba Avenue, Suite 200 Gewerbe Brunnmatt 5 Stores Road...
