- Page 1 Installation Manual IRIS Lite & IRIS Basic Outdoor Self Powered Sirens...
-
Page 3: General Specifications
Description Self-powered and self-protective electronic siren with built-in FLASH, in two shades (red and blue), for easy detection of the area from which the alarm comes. It is an ideal combination of stylish design and quality construction and is manufactured under the strictest safety standards. The outer casing is made of high-strength polycarbonate, suitable for outdoor use. -
Page 4: Technical Specifications
Technical Specifications IRIS LITE IRIS BASIC Power Supply 13.2-14.5 V DC Operational Voltage 13.8 V DC 8mA (when powered for the first time only by the battery Consumption (Standby MODE) and is not fed by the control panel) Consumption (Standby MODE) 13.0mA when the LEDs turn on at standby mode... -
Page 5: Terminals Description
Terminals Description TAMPER FREE TAMPER SWITCH CONTACTS COM | ZONE POWER SUPPLY INPUT (12V) FOR SIREN ΑΝD FOR BATTERY CHARGING TRIGGER NEGATIVE OR POSITIVE ALARM ACTIVATION INPUT (PANEL CONTROLABLE) Connecting the siren’s TAMPER to the Control Panel At the “TAMPER” terminals, the Tamper contacts of the siren end up. When the siren is screwed to the wall and its lid is closed, this output is NC and becomes NO when the lid is opened or the siren detaches from the wall. -
Page 6: Installation
Installation To install the siren, please follow the steps, as described below: 1. Select the point where you will mount the siren, which should be as high as possible so that the siren is easily visible and safe. 2. Align the siren mount to the wall,with the built-in spirit level, mark the fixing holes and open them with a drill. - Page 7 Programming the Siren The siren functions are programmed using the “MENU” and “SELECT” buttons, which are placed on the siren board. Entering the programming process To enter the siren programming process, turn on the siren by connecting the battery to the cor- responding terminals, making sure to use the correct polarity.
-
Page 8: Maintenance
Maintenance You will need to check the proper functioning of the siren at regular intervals to make sure that the siren is not damaged and that it will work normally when needed. The following functions should be checked in every maintenance: 1.
