- Page 1 69 Lincoln Blvd. Ste A-311 Lincoln, CA 95648...
- Page 2 Table of Contents 1. Intro, User Responsibility 2. Reservation, Transportation, and Storage 3. Getting Started: Work Area Safety, Common Sense, PPE 4. Warranty 5. Maintenance 6. Maintenance (Continued) 7. Recommended Lubricant 8. Troubleshooting...
- Page 3 Dear Customer, User Responsibility Welcome to the Rattle Stick Concrete Tools family, our It is the owner’s / employer’s responsibility to ensure that intent to deliver the best products as possible. Delivering the operator is trained and has sufficient knowledge innovative, well-built, ergonomic, cost-effective products about how to use this machine safely.
- Page 4 Transportation and Storage All the information and data in this Operator’s Manual was After work is completed, remove the Rattle Stick from the up to date at the time the Operator’s Manual was sent to float and thoroughly wipe down before the concrete has print.
- Page 5 Stop and seek expert of people or animals that can encounter the machine advice by contacting Rattle Stick Concrete Tools, a service while in operation. dealer, or an experienced user. Do not attempt any task Do not use machine in bad weather, such as heavy that you are unsure of.
- Page 6 Rattle Stick is under warranty for 1 Year, from date of purchase. (proof of purchase required) Rattle Stick warrants that its product is free from defects in material andworkmanship for 1 year from the day of purchase and provided that the product upon examination by Rattle Stick discloses that it is defective.
- Page 7 Rattle Stick Tool Maintenance Use the sleeve with thin wall Never tighten the 2 motor Twist style speed chain or EZ tilt style float bolts they are factory control. Turn heads. Remove for heavy wall torqued. Additional torque completely left to adapters like Kraft Knuckle will cause failure.
- Page 8 Be careful it comes out fast. Too much oil can damage electrical parts Never torque or change the factory torque on the motor screws, this will void the warranty. Only use the recommended lubricant for your Rattle Stick. (See page 7)
- Page 9 Recommended Lubricant DON’T EVER USE motor oil or any thick lubricant this will void your warranty and will burn up the motor. NO GREASE, MOTOR OIL OR AIR TOOL OIL (do not use the 3 in 1 for ¼ HP Motors) Just the two listed below 3 in 1 PTFE lubricant for the bearing.
- Page 10 Troubleshooting Problem Causes Lack of vibration Dry bearing Oil bearing Over heating Dry bearing Oil bearing No power/loss of variable Water damage switch or ECU Send in for repair speed Missing sleeve adapter Put sleeve adapter on Fits Loose into float adapter Float pitch too flat, moving Roll float on the edge and Not bringing up the cream...
- Page 11 Rattle Stick Concrete Tools 69 Lincoln Blvd., Ste A-311 Lincoln, CA 95648 916.472.6250 www.rattlestick.net...
