INPUT CARD FOR A JVC MONITOR
BEDIENUNGSANLEITUNG:
MANUEL D'INSTRUCTIONS:
ISTRUZIONI:
MANUAL DE INSTRUCCIONES:TARJETA DE ENTRADA PARA UN MONITOR JVC
IF-CF01CMG
COMPONENT/RGB INPUT CARD
IF-CF01RBG
COMPONENT/RGB ACTIVE THROUGH CARD
IF-CF21HDG
HD/SD SDI INPUT CARD
EINGANGSKARTE FÜR JVC MONITORE
CARTE D'ENTRÉE POUR MONITEURS JVC
SCHEDA DI INGRESSO PER MONITOR JVC
МОДУЛЬ ВХОДОВ ДЛЯ МОНИТОРА JVC
INSTRUCTIONS
LCT1973-001A
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for JVC IF-CF01CMG
Summary of Contents for JVC IF-CF01CMG
- Page 1 INPUT CARD FOR A JVC MONITOR BEDIENUNGSANLEITUNG: MANUEL D’INSTRUCTIONS: ISTRUZIONI: MANUAL DE INSTRUCCIONES:TARJETA DE ENTRADA PARA UN MONITOR JVC IF-CF01CMG COMPONENT/RGB INPUT CARD IF-CF01RBG COMPONENT/RGB ACTIVE THROUGH CARD IF-CF21HDG HD/SD SDI INPUT CARD EINGANGSKARTE FÜR JVC MONITORE CARTE D’ENTRÉE POUR MONITEURS JVC SCHEDA DI INGRESSO PER MONITOR JVC МОДУЛЬ...
- Page 2 INPUT CARD FOR A JVC MONITOR IF-CF01CMG COMPONENT/RGB INPUT CARD IF-CF01RBG COMPONENT/RGB ACTIVE THROUGH CARD IF-CF21HDG HD/SD SDI INPUT CARD INSTRUCTIONS...
- Page 3 Thank you for purchasing this JVC Input Card. In order to take full advantage of the card’s capabilities, please read and follow all instructions carefully before installing and using the card. Retain this booklet for future reference. Precautions Before installing this Input Card in your monitor, please read the Safety Precautions included in your monitor’s user manual.
- Page 4 (Business users) If you wish to dispose of this product, please visit our web page www.jvc-europe.com to obtain information about the take-back of the product. [Other Countries outside the European Union] If you wish to dispose of this product, please do so in accordance with applicable national legislation or other rules in your country for the treatment of old electrical and electronic equipment.
-
Page 5: Before Installation
Before Installation Accessaries • Label (x 1): For placing to the rear panel and the remote control of the monitor after installing the Input Card. • Slot cover* (x 1): For covering the blank slot. * Not supplied for IF-CF01RBG Preparation •... - Page 6 Insert the Input Card into the slot, fitting into the guides inside the slot, so that its panel touches the bottom of the monitor. For IF-CF01CMG and IF-CF21HDG: You can install the Input Card(s) into either left or right slot. When installing, follow the procedure below.
-
Page 7: Controls And Features
Controls and Features IF-CF01CMG (Component/RGB Input Card) Front view Label Rear view 1 Audio signal input terminal Accepts analog audio signals. NOTE: • This terminal cannot be used for both RGB and component signals at the same time. 2 Component/RGB signal input terminals Accepts component (color difference) or RGB signals. - Page 8 IF-CF01RBG (Component/RGB Active Through Card) Front view Label Rear view 1 Audio signal input (INPUT)/output (ACTIVE THROUGH OUT) terminals Accepts/outputs analog audio signals. NOTE: • These terminals cannot be used for both RGB and component signals at the same time. 2 Component/RGB signal input (INPUT)/output (ACTIVE THROUGH OUT) terminals Accepts/outputs component (color difference) or RGB signals.
- Page 9 Controls and Features IF-CF21HDG (HD/SD SDI Input Card) Front view Label Rear view 1 Audio signal output terminals (SWITCHED AUDIO LINE OUT) Decodes EMBEDDED AUDIO signals and outputs them as analog signals. The audio channel output from the L CH or R CH is switched by “AUDIO SETTING” on the menu of the monitor.
- Page 10 4 E. AUDIO HD/SD SDI signal input terminals (IN 1, IN 2) Accepts an HD SDI signal and an SD SDI signal. Also accepts EMBEDDED AUDIO signals including up to 8 audio channels with the sampling frequency of 48 kHz. Select input by using the button on the monitor.
-
Page 11: Specifications
Specifications IF-CF01CMG Type: Target monitors: Inputs: Format: Component signal: RGB signal: Required slots: Weight: Dimensions (W x H x D): 133 mm x 34.5 mm x 185 mm Dimensions (see the back cover.) Component/RGB Input Card Consult your dealer. Video signal: 1 line, BNC x 3, 75 Ω termination... - Page 12 IF-CF01RBG Type: Target monitors: Inputs: Outputs (active through out): Format: Component signal: RGB signal: Required slots: Weight: Dimensions (W x H x D): 256 mm x 34.5 mm x 185 mm Dimensions (see the back cover.) Component/RGB Active Through Card Consult your dealer.
- Page 13 Specifications IF-CF21HDG Type: Target monitors: Inputs/Outputs: Compliant signal format: 480/60i, 576/50i, 720/60p, 720/50p, 1035/60i, 1080/60i, Format: Required slots: Weight: Dimensions (W x H x D): 133 mm x 34.5 mm x 185 mm Dimensions (see the back cover.) (continued) HD/SD SDI Input Card Consult your dealer.
- Page 14 Front View (Terminal Side) Vorderansicht (Anschlussleiste) Vue de face (Côté prises) Vista frontale (Lato terminali) Vista frontal (Lado del terminal) Вид спереди (сторона с разъемами) IF-CF01CMG 133 mm (5 1/4") IF-CF01RBG 256 mm (10 1/8") IF-CF21HDG 133 mm (5 1/4") ©...
