Summary of Contents for Hisense HRF266N6CSE1
- Page 1 Refrigerator Use & Care Guide Model: HRF266N6CSE1 For questions about features, operation/performance, parts or service, call: 1-877-465-3566...
-
Page 2: Table Of Contents
Table of Contents Brief introduction ........................1 Important safety instructions ....................2 Installing your new appliance ....................4 Description of the appliance ....................10 Display controls ........................11 Using your appliance ......................13 Cleaning and care ....................... 17 Helpful hints and tips ...................... -
Page 3: Brief Introduction
Brief Introduction Thank you for your choosing Hisense. We Kitchen areas in shops, offices and other are sure you will find your new refrigerator working environments. a pleasure to use. Before you use the Hotels, motels and other residential appliance, we recommend that you environments. -
Page 4: Important Safety Instructions
Important Safety Instructions General safety and daily use Don’t place items on top of the appliance as this could cause injury should they fall off. It is important to use your appliance safely. We recommend that you follow the Never allow children to play with the guidelines below. - Page 5 If the fitted plug is not suitable for your To avoid eye injury, do not look directly socket outlets, it should be cut off and into the LED light located in the refrigerator carefully disposed of. To avoid a compartment. If it is not functioning possible shock hazard, do not insert the correctly, consult a qualified, registered discarded plug into a socket.
-
Page 6: Installing Your New Appliance
Installing Your New Appliance Before using the appliance for the first time, you should be informed of the following tips. 2 " WARNING For proper installation, this refrigerator must be placed on a level surface of hard material that is the same height 70"... - Page 7 Leveling of appliance Door Removal For sufficient leveling and air circulating In case your home access door is too in the lower rear section of the narrow for the refrigerator to pass appliance, the bottom feet may need through, remove the refrigerator doors to be adjusted.
- Page 8 Use both hands to open the door more Disassembling the freezer door than 90°. Lift it up and take it off. Pull out the freezer door and the upper freezer drawer (G) to the final position. Take out the ice storage box (H) by lifting it up in the direction of the arrow.
- Page 9 Remove the lower freezer drawer (C) Installing the water lines by lifting it up. A water dispenser with a filter is one of the helpful features on your new appliance. To help promote better health, the water filter removes unwanted particles from your water.
- Page 10 Connecting to the Flush the tubing. Turn the main water supply on and flush out the tubing until water supply line the water is clear. Then, shut the water off at the water valve after about a quart First, shut off the main water supply. of water has flushed through the tubing.
- Page 11 6. Turn the water on and check for leakage. CAUTION! Check to see if leaks occur at the water line connections Note: Use only the new tubing supplied with the refrigerator. Old tubing should not be used. After connected to the water supply line, please open the water valve to flush the filter for 5 minutes before use.
-
Page 12: Description Of The Appliance
Description of the Appliance Door bins Vertical baffle part Water dispenser (inside) Fruit and vegetables crisper Full width pantry Freezer LED light Ice maker (inside) Ice bucket (inside) Lower freezer drawer Adjustable bottom feet Top cover Control panel Vertical baffle guide block Water filter Refrigerator LED light (inside) Air channel... -
Page 13: Display Controls
Display Controls Your product has one control panel which is installed on the top cover. Use your appliance according to the following control guidelines. Fridge Temperature Fridge When the appliance is powered on for the first time, the backlighting of the Control icons on the display panel start working. - Page 14 ” will blink, reminding you to replace the water filter. First of all, you need to purchase a new water filer. You can purchase the new filter from the retailer where you purchased your refrigerator or the Hisense after-sales service system.
-
Page 15: Using Your Appliance
Demo mode (Freezer/ Fridge Temperature Indicator moving) Demo mode is for store display, and it prevents the refrigerator from generating cool air. In this of Cooling off Mode, the refrigerator may seem like it is working but it will not make cool air. - Page 16 1- 5. If leaks leaks, keep the filter cartridge horizontal persist, discontinue use and call when pulling it. Hisense customer service.. To prevent overflow, empty the water filter tray (M) and dry around the filter Removing any residual matter inside the case.
- Page 17 Note: CAUTION! Be sure to flush the dispenser thoroughly, otherwise water may drip from the Never close the refrigerator dispenser. This means that there is still air door while the shelves, crisper in the line. and/or telescopic slides are Do not dispense the entire 2.5 gallon extended.
- Page 18 To re-install the glass shelves, tilt the front of Using the freezer compartment the shelf up and guide the shelf hooks into the slots at a desired height (1). Then lower The freezer compartment is provided with the front of the shelf so that the hooks can an upper drawer, a lower drawer and an drop into the slots (2).
-
Page 19: Cleaning And Care
Cleaning and Care Interior cleaning For hygienic reasons the appliance (including exterior and interior accessories) should be cleaned at least You should clean the appliance interior every two months. regularly. It will be easier to clean when food stocks are low. Wipe the inside of WARNING! the fridge and freezer with a weak solution of backing soda and water, and... - Page 20 Replacing the LED light WARNING! Do not use sharp objects to WARNING! remove frost from the freezer compartment. Only after the The LED light must be replaced interior is completely dry should by a competent person. If the the appliance be switched back LED light is damaged, follow the on and plugged back into the steps below：...
-
Page 21: Helpful Hints And Tips
Helpful Hints and Tips Energy Saving Tips Hints for refrigeration We recommend that you follow the tips For Meat: (all types) wrap in cling wrap below to save energy. and place on the glass shelf above the vegetable drawer. Always follow food Try to avoid keeping the door open for storage times and use by dates long periods in order to conserve energy. - Page 22 Iced products (ice cubes, popsicles): if consumed immediately after removal from the freezer compartment, will probably cause frost burns to the skin. It is recommended to label and date each frozen package in order to keep track of the storage time. Hints for the storage of frozen food Ensure that frozen food has been stored...
-
Page 23: Troubleshooting
Troubleshooting If you experience a problem with your appliance or are concerned that the appliance is not functioing correctly, you can carry out some easy checks before calling for service, please see below. WARNING 1.Don’t try to repair the appliance yourself. If the problem persists after you have made the checks mentioned below, contact a qualified electrician, authorized service technician or the shop where you purchased the product. - Page 24 It is normal to frequently hear the sound of the motor, it will need to run more when in following circumstances: • Temperature setting is set colder than necessary. Large quantity of warm food has recently been stored • The motor runs within the appliance.
- Page 25 • Did you wait for 12 hours after installation of the water supply line before making ice? If it is not sufficiently cool, it may take longer to make ice, such as when first installed. • Is the water line connected and the water valve open? •...
-
Page 26: Disposal Of The Appliance
Disposal of the Appliance DANGER It is prohibited to dispose of this appliance as household waste. Packaging materials Packaging materials with the recycle symbol are recyclable. Dispose of the packaging into a suitable waste collection container to recycle it. Before disposal of the appliance 1. - Page 27 Copyright Statement © 2019 Hisense Company Ltd. All Rights Reserved. All material in this User Manual is the property of Hisense Company Ltd. and its subsidiaries, and is protected under US, CANADA, MEXICO and International copyright and/or other intellectual property laws.
Need help?
Do you have a question about the HRF266N6CSE1 and is the answer not in the manual?
Questions and answers
Ice maker is not making ice. I do not hear the system kick on to fill with water. There is a new water filter installed, no ice is built up on the tray.
The ice maker in the Hisense HRF266N6CSE1 refrigerator may not be making ice due to the following reasons:
1. The water supply line was not given 12 hours after installation to start working.
2. The water line is not connected or the water valve is closed.
3. The ice making function was manually turned off or set to "Ice Off" mode.
4. Ice is blocked within the ice maker bucket.
5. Water pressure is below 30 psi; a booster pump may be needed.
6. The freezer temperature is too warm; it should be set lower.
7. The refrigerator was recently installed; allow at least 90 minutes or more for ice production.
8. The first batches of ice were not discarded, or the container is full/clogged.
