Opening - Leb Electronics TINY Manual

- Before fastening the stirrups check the dimension
support frame is not more than the value reported in the assembling
table. In the following assembling table are reported the reference
dimensions for the set up of the actuator.

OPENING

90°
120°
Warning:
- it is advisable not to choose values of
different between them, so to ensure a regular move of the wing
and a lower stress on the actuator. By increasing the dimension
the opening corner grows up and, therefore, the thrust on the wing
is reduced and the peripheral speed increased. By increasing the
"B"
dimension the opening corner is reduced and, therefore, the
thrust on the wing is increased and the peripheral speed reduced.
A (mm) B (mm)
190
167
- 11 -
ENGLISH
"C"
on the
C (mm)
190 1170
155 1170
"A" "B"
and too
"A"
