DIGITAL VIDEO RECORDER
SR-VDA300U
VCR TV CABLE/DBS
A.MONITOR
POWER
A/B
TV/VCR
DISPLAY
ENTER/OSD
1
2
3
. , ?
ABC
DEF
2
4
5
6
GHI
JKL
MNO
DBS
DAILY(M-F)
WEEKLY
7
8
9
PQRS
TUV
WXYZ
C. RESET
AUX
0
4
CANCEL
TIMER
START
STOP
DATE
CH
EXPRESS PROGRAMMING
1
PROG.
HS/STD/LS3
PROG.
SKIP SEARCH
SP/EP
CHECK
TIMER
PLAY
POWER
STOP
TV CH +
PULL-OPEN
TV
TV
VOL
VOL
–
+
TV CH –
JOG/
SHUTTLE
ASI-IN
REC LINK
ASI-REC
INSTRUCTIONS
STOP/EJECT
PL
A
Y
POWER
For Customer Use:
Enter below the Model No. and
Serial No. which are located on the
rear of cabinet. Retain this
information for future reference.
Model No.
Serial No.
LPT0788-001B
