Sauder Edge Water 414856 Instruction Booklet

Sauder Edge Water 414856 Instruction Booklet

Lift-top coffee table
Hide thumbs

Advertisement

Quick Links

Download this manual
414856
Lift-Top Coffee Table
Edge Water Collection
PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
English .................... Page 1-19
Français ...............Pages 20-22
Made in the USA
Espanol .............Páginas 23-25
Archbold, OH
Lot #: 375077
Date Purchased: ____________________
07 / 14 / 15

Advertisement

loading
Need help?

Need help?

Do you have a question about the Edge Water 414856 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sauder Edge Water 414856

Summary of Contents for Sauder Edge Water 414856

  • Page 1 PLEASE READ AND KEEP FOR FUTURE REFERENCE. BEFORE RETURNING English ....Page 1-19 YOUR UNIT TO THE STORE Français ....Pages 20-22 Made in the USA 1-800-523-3987 Espanol .....Páginas 23-25 Archbold, OH www.sauder.com Lot #: 375077 07 / 14 / 15 Date Purchased: ____________________...
  • Page 2 Part Identifi cation .......3 Hardware Identifi cation .....4 ASSEMBLY TOOLS REQUIRED Assembly Steps ....5-19 No. 2 Phillips Screwdriver Français ......20-22 Tip Shown Actual Size Espanol ....... 23-25 Safety ........26 Hammer Warranty ........27 Adjustable Wrench Page 2 www.sauder.com/services 414856...

  • Page 3: Part Identification

    Use this PART IDENTIFICATION to help identify similar parts. RIGHT END RIGHT FRONT/LEFT REAR LEG LEFT END LEFT FRONT/RIGHT REAR LEG UPRIGHT STRETCHER FOOT SPACER BOTTOM SKIRT SHELF FOOT PANEL 414856 www.sauder.com/services Page 3...

  • Page 4: Hardware Identification

    BROWN 1" FLAT HEAD SCREW - 4 BLACK 1-9/16" FLAT HEAD SCREW - 4 BLACK 3/4” MACHINE SCREW - 4 BLACK 1-1/4" MACHINE SCREW - 4 Screws are shown actual size. You may receive extra hardware with your unit. Page 4 www.sauder.com/services 414856...
  • Page 5 Look for this icon. It means a video assembly tip is available at: www.sauder.com/services/tips Do not tighten the HIDDEN CAMS in this step. Arrow Do not insert CAM DOWELS into these edges. Arrow Arrow (14 used) (36 used) Arrow Insert the metal end of the CAM DOWEL into the HIDDEN CAM.
  • Page 6 (22 used) Turn twenty-two CAM SCREWS (20F) into the LEGS (H2 and I2) and SKIRTS (L). Page 6 www.sauder.com/services 414856...
  • Page 7 (4 used in this step) hole Fasten the LEGS (H2 and I2) to the ENDS (A and B). Tighten eight HIDDEN CAMS. Fasten four FEET (M) to the LEGS (H2 and I2). Use four BLACK 1-9/16" FLAT HEAD SCREWS (30S). 414856 www.sauder.com/services Page 7...
  • Page 8 Tighten Arrow Risk of damage or injury. Hidden Cams must be completely Arrow Maximum tightened. Hidden 210 degrees Cams that are not completely tightened Minimum may loosen, and parts 190 degrees may separate. To completely tighten: Page 8 www.sauder.com/services 414856...
  • Page 9 S u r u t C i t h o f a c S u r Bottom edges should be even. Fasten the SKIRTS (L) to the BOTTOM (E). Tighten six HIDDEN CAMS. 414856 www.sauder.com/services Page 9...
  • Page 10 These holes must be here. Maximum Arrow 210 degrees Minimum 190 degrees Fasten the LEFT END (B) to the SHELF (F) and PANELS (G). Tighten four HIDDEN CAMS. Page 10 www.sauder.com/services 414856...
  • Page 11 S u r (4 used) For support, place packing foam or magazines here. Insert four METAL PINS (1R) into the SHELF (F). Then, push the UPRIGHTS (C) onto the METAL PINS (1R) in the SHELF (F). 414856 www.sauder.com/services Page 11...
  • Page 12 Fasten the BOTTOM (E) to the UPRIGHTS (C). Use four BLACK 1-7/8"FLAT HEAD SCREWS (2S). Fasten the RIGHT END (A) to the BOTTOM (E), SHELF (F), PANELS (G), and SKIRTS (L). Tighten eight HIDDEN CAMS. Page 12 www.sauder.com/services 414856...
  • Page 13 BROWN 1" FLAT HEAD SCREW (4 used in this step) Fasten the FOOT SPACERS (K) to the BOTTOM (E). Use four BROWN 1" FLAT HEAD SCREWS (12S). Push two PLASTIC FEET (23E) into the FOOT SPACERS (K). 414856 www.sauder.com/services Page 13...
  • Page 14 (18 used) To cover HIDDEN CAMS Carefully stand your unit upright. Push six BUMPERS (2M) into the PANELS (G) and LEGS (H2 and I2). Push a CAM COVER (12P) onto each visible HIDDEN CAM. Page 14 www.sauder.com/services 414856...
  • Page 15 Fasten the LIFT TABLE MECHANISMS (23M) to the TOP (D). Use six BLACK 9/16" LARGE HEAD SCREWS (1S). NOTE: Be sure to position the LIFT TABLE MECHANISMS on the TOP exactly as shown. 414856 www.sauder.com/services Page 15...
  • Page 16 BLACK 3/4” MACHINE SCREW (4 used in this step) Fasten the SUPPORT BRACKETS (37G) to the LIFT TABLE MECHANISMS (23M). Use four WASHERS (13M), NUTS (24M), and BLACK 3/4" MACHINE SCREWS (92S). Page 16 www.sauder.com/services 414856...
  • Page 17 Fasten the TOP (D) to the ENDS (A and B). Use twelve BLACK 9/16" LARGE HEAD SCREWS (1S) through the LIFT TABLE MECHANISMS (23M) and into the holes in the ENDS. NOTE: Be careful when lining up the holes in the MECHANISMS with the holes in the ENDS as to not damage any parts. 414856 www.sauder.com/services Page 17...
  • Page 18 (4 used in this step) Fasten the BRACE (J) to the SUPPORT BRACKETS (37G) on the LIFT TABLE MECHANISMS (23M). Use four WASHERS (13M), NUTS (24M), and BLACK 1-1/4" MACHINE SCREWS (93S). NOTE: Use the crescent wrench in this step. Page 18 www.sauder.com/services 414856...
  • Page 19 IMPORTANT: Do not place valuables in the storage space. NOTE: Please read the back pages of the instruction booklet for important safety information. This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry. 414856 www.sauder.com/services Page 19...

  • Page 20: Liste De Pièces

    30S VIS TÊTE PLATE 40 mm NOIRE ..4 pour future référence. 92S VIS À MÉTAUX 19 mm NOIRE ..4 Pour contacter Sauder en ce qui concerne cet 93S VIS À MÉTAUX 32 mm NOIRE ..4 élément, faire référence au numéro de lot et...
  • Page 21 14 mm NOIRES (1S). Fixer l'EXTRÉMITÉ GAUCHE (B) à la TABLETTE (F) et aux PANNEAUX (G). Serrer quatre REMARQUE : S’assurer de positionner les EXCENTRIQUES ESCAMOTABLES. MÉCANISMES DE LEVAGE DE TABLE sur le DESSUS exactement comme il l’est indiqué. 414856 www.sauder.com/services Page 21...
  • Page 22 REMARQUE : Faire attention en alignant les trous dans d’instructions. les MÉCANISMES sur les trous des EXTRÉMITÉS de Ceci complète l'assemblage. Nettoyer à l’aide d’une manière à ne pas endommager les pièces. encaustique pour meubles ou d’un chiffon humide. Essuyer. Page 22 www.sauder.com/services 414856...

  • Page 23: Lista De Partes

    12S TORNILLO MARRÓN DE CABEZA Si necesita ponerse PERDIDA de 25 mm ......4 en contacto con 30S TORNILLO NEGRO DE CABEZA Sauder en cuanto a PERDIDA de 40 mm ......4 esta unidad, refi érase 92S TORNILLO NEGRO PARA METAL al número de lote y de 19 mm .........4...
  • Page 24 Fije el EXTREMO IZQUIERDO (B) al ESTANTE (F) y a de 14 mm (1S). los PANELES (G). Apriete cuatro NOTA: Asegúrese de colocar los MECANISMOS DE EXCÉNTRICOS ESCONDIDOS. ELEVACIÓN DE LA MESA al PANEL SUPERIOR exactamente como se muestra. Page 24 www.sauder.com/services 414856...
  • Page 25 NOTA: Tenga cuidado al alinear los agujeros de los Esto completa el ensamblaje. Limpie con su pulimento MECANISMOS con los agujeros en los EXTREMOS para muebles preferido o un paño húmedo. Seque con para no dañar ninguna pieza. un paño. 414856 www.sauder.com/services Page 25...
  • Page 26 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y son propensos a inclinarse hacia adelante. Page 26 www.sauder.com/services 414856...

  • Page 27: Year Limited Warranty

    4. La présente garantie ne s’applique qu’aux défauts garantis qui se produisent des composantes de mobilier Sauder. Le mot « défaut », tel qu’il est utilisé sous pour la première fois et qui sont signalés à Sauder dans les limites de ouverture les termes de la présente garantie, comprend les imperfections des pièces qui...
  • Page 28 Archbold, Ohio, where it all began. Certifi cate of Conformity The Sauder name on the box ensures that 1. This certifi cate applies to the Sauder Woodworking Product identifi ed by this Instruction Book. the item you have purchased is made with 2.
