C-18" small drawer kit

Advertisement

C-18" Small Drawer Kit
416619
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Call us at 1-855-854-7465
or vist us at
www.woodtrac.com
Lot #: 359393
02 / 07 / 14
Purchased: ____________________

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WoodTrac 416619 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Sauder WoodTrac 416619

  • Page 1 C-18" Small Drawer Kit 416619 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Call us at 1-855-854-7465 or vist us at www.woodtrac.com Lot #: 359393 02 / 07 / 14 Purchased: ____________________...
