Parts List - Merax MS199736 User Manual

Index
Qty.
No.
1 1 Front main frame
2 1 Front post
3 1 Seat backrest group
4 1 Console
5 1 Rear main frame
6 1 Back cushion
7 1 Heart rate line of seat handlebar
8 1 Saddle
9 1 Track pipe
10 1 Seat handlebar
11 2 Sticker
12 1 Magnetic resistance group
13 1 Handlebar
14 1 Seat knob
15 2 Seat gloves
16 2 Sliding tube bundle
17 2 Glove
18 2 Crank cover
19 4 Pipe plug 30*30
20 2 Pipe plug 30*60
Pipe plugΦ22
21 2
22 1 Flywheel spindle
23 1 Belt
24 2 Bearing (6000)

Parts List

Description
35
Index
Qty.
No.
47 1 Sensor seat
48 1 Flywheel
49 2 Hexagon socket head cap screw M8 x
45mm
50 1 Pressing rod
51 2 Pipe plugΦ25
52 1 Fine tuning
Sensor line
53 1
54 4 Carriage screw M8 x 65mm
55 4 high cap nuts M8
56 6 Umbrella head hexagon M8 x 40mm
57 7 Tapping screw M4 x 20mm
58 2 Umbrella head cross screw M5 x 12mm
59 12 Plain washer M8
60 4 Nylon nut M8
61 1 Welded nut M8
62 1 Wave washer M10
Hexagon nut 7/8"-26
63 2
64 2 Star washer M10
65 2 Circlip
Hexagon nut 3/8"-26
66 4
67 1 Hexagon socket head cap M6 x 50mm
68 1 hexagon socket head cap M6 x45mm
69 1 Hexagon head screw M8 x 16mm
70 5 Umbrella tapping screw M4 x 20mm
1:1
Description
EN
