- Page 1 Hand Winch USER MANUAL SKU: HAND-WINCH-R / HAND-WINCH-B Please read this manual carefully before use V1.0...
- Page 2 Fieryred, founded in March, 2016 and born of the passion to fulfill four-wheel drive lovers' demand for affordable, yet high quality 4x4 equipment, takes prides in designing, engineering and providing rock solid 4x4 products to let you rediscover the fun of off-roading.
- Page 3 WARNINGS AND SAFETY INSTRUCTIONS Purchaser / owner must ensure this product is installed according to these instructions. Purchaser / owner must not alter or modify this product. Make sure the winch is positioned so handle can rotate a full 360 degrees freely. Do not weld any part of the winch.
- Page 4 KNOW YOUR WINCH Drum Handle Ratchet Handle Ratchet Pawl Base Rope / Strap Clevis Hook SPECIFICATIONS HAND-WINCH-R HAND-WINCH-B Product Weight: 5.4kg 5.5kg Frame Material: Carbon Steel Frame Surface Finish: Dacromet Coating Rope / Strap Color: Blue Black Rope / Strap Material:...
- Page 5 INSTALLATION Install the hand winch in a location where the load and the rope / strap can be observed during the operation, and inspection and maintenance can be conducted easily. Set the winch height to easy-work-height. Fix the winch to the installation base with bolts and nuts. OPERATION Let Rope / Strap Out: Disengage the ratchet pawl (roll the ratchet handle down) and slowly pull out the rope / strap.
- Page 6 REPAIR AND REPLACEMENT: If a Fieryred product is suspected of being defective, you'll need to provide proof of purchase (e. g. a screenshot of the order) and a picture and a video of the damaged goods in their entirety to sales@Fieryred.com.
