Venmar AVS HRV EKO 1.5
Part no. 43901
80 to 157 CFM (0.4 in. w.g.)
66 to 132 CFM (0.4 in. w.g.)
VB0122
DISCOVER THE NEW GENERATION OF
VENMAR AIR EXCHANGERS: ULTRA-EFFICIENT
AND ENVIRONMENTALLY-FRIENDLY
The AVS HRV EKO 1.5 has been designed to be one of the
most eco-friendly HRV air exchangers on the market. Its
innovative design incorporates extremely high performance
ECM* motors, which enable EKO to significantly lower energy
costs without affecting its performance. Additional energy
efficiency is found through its advanced heat recovery core,
which can retain up to 80% of home's heating. EKO
surpasses energy-saving standards while providing effective
heat recovery, ventilation and quiet operation. All aspects
have been designed to facilitate balancing of air flow and
simplify uses and installation.
High performance ECM* motors
Faster and easier installation of insulated flexible ducts
with practical straps
Integrated balancing dampers
Integrated electronic board on motors
Homeshield™ defrosting system
Heat recovery core with superior capacity
Optimized drainage system
ENERGY STAR® qualified
REPAIRS AND MAINTENANCE
The AVS HRV EKO 1.5 high output ECM* motors are
permanently lubricated. The electronic circuit board eliminates
electromechanical parts, reducing repair time to a minimum.
WARRANTY
The AVS HRV EKO 1.5 unit is protected by a complete 5-year
warranty on all parts. The heat recovery core is covered by a
limited lifetime warranty, with the original proof of purchase.
*Electronically Commutated Motor.
Available at:
53 to 106 CFM (0.4 in. w.g.)
40 to 80 CFM (0.4 in. w.g.)
HEAT RECOVERY VENTILATOR
Controls
This unit is very simple to operate. Once it is installed,
press on its push button, located under the unit, to activate
it. Press once for low speed, once again for high speed, and
once more to stop it
The following main controls are available:
- Altitude programmable digital control
with Smart mode
- Deco-Touch digital control
Also, one to 5 of the following optional controls can be
added:
- 20/40/60-min. Push-Button Timer
- 60-min. Mechanical Timer
Options
Complete line of registers and diffusers
Electric duct heater
Homeshield™ Defrosting System
The AVS HRV EKO 1.5 uses a unique defrosting method. No
negative pressure is created by air exhausted to the outside,
as the air is recirculated into the house, helping to prevent
any backdraft.
F
S
TALE AIR
TO BUILDING
FROM BUILDING
VF0046
Heat Recovery Core
Dimensions: 10" x 10" x 14.25" (25.4 cm x 25.4 cm x 36.2 cm)
Exchange surface: 110 ft² (10.2 m²)
Weight: 7.36 lb (3.3 kg)
Material: Polypropylene
Type: Cross Flow
Warranty: Limited lifetime
Requirements and Standards
Complies with the UL 1812 requirements regulating the
installation of Heat Recovery Ventilators
Complies with the CSA C22.2 no. 113 Standard applicable
to ventilators
Complies with CSA C444 requirements regulating the
installation of Heat Recovery Ventilators
Technical data was obtained from published results of tests
relating to CSA C439 Standards
HVI certified and ENERGY STAR® qualified
no. 40440
no. 40395
no. 03364
no. 00910
ILTERED AIR
O
D
UTSIDE
T
EMPERATURE
D
EFROSTING MIN
O
PERATING MIN
ºC
ºF
W
W
ARMER
ARMER
-5
23
THAN
THAN
-5
-27 23
-17
TO
TO
-27
-17
&
&
LESS
LESS
EFROST CYCLE
./
.
N
O
DEFROST
7/25
10/22
