Alto MOD-800R Service Manual page 48

No. Part No. Description
171 MI02867 separating shade-RS-ACT
172 MJ01314 tinplate
173 MI03098 separating shade-RS-ACT
174 MJ01314 tinplate
175 AE00449 solder material without lead
176 SE00067 SMD L.E.D
177 CO00005 SMD chip inductance
178 RD00376 SMD precise resistor 1/8W
179 NE15896 lable
180 NI00014 membrane
181 NH00012 bond paper
182 NI04272 tail tube
183 AE00385 paint-RS
184 AE00382 paint-RS
185 AE00383 paint-RS
186 AE00380 paint-RS
187 AE00384 paint-RS
188 AE00381 paint-RS
189 NI04078 tail tube
Specification
UP-8H 0.2t*4.8*23.1*29.1_V1.4
0.2t*40*1M(1M/0.5KG)_V 1.0
UP-8P 0.2t*2.8*14.2*14.3_V1.5
0.2t*40*1M(1M/0.5KG)_V 1.0
9308/Sn Ag Cu
blue 12-215/BHC-AN1P2/3C
1uH(1R0K)
150 ±1% 0805
MOD-800H ALTO_V1.0
0.035*1M
0.04*1M
AU-800H 37*120_V1.0
PU2001
PU1900
PU2001
PU1900
PU2001
PU1900
AU-800H 37*120 black_V1.0
- 46 -
Remark
LED1,LED2
L5
R52
