Alto AU-800R Series Owner's Manual

Alto wireless microphone system owner's manual
Hide thumbs Also See for AU-800R Series:

Advertisement

Quick Links

See also: User Manual
R
LTO
OWNER'S MANUAL
AU-800R/800H/800P SERIES
WIRELESS MICROPHONE SYSTEM
www.altoproaudio.com
Version 2.0 OCT. 2007
English

Advertisement

loading
Need help?

Need help?

Do you have a question about the AU-800R Series and is the answer not in the manual?

Questions and answers

Related Manuals for Alto AU-800R Series

Summary of Contents for Alto AU-800R Series

  • Page 1 OWNER'S MANUAL AU-800R/800H/800P SERIES WIRELESS MICROPHONE SYSTEM www.altoproaudio.com Version 2.0 OCT. 2007 English...
  • Page 2 IMPORTANT SAFETY INSTRUCTION CAUTION WARNING To reduce the risk of electric shock RISK OF ELECTRIC SHOCK and fire, do not expose this equipment DO NOT OPEN to moisture or rain. TO REDUCE THE RISK OF ELECTRIC SHOCK PLEASE DO NOT REMOVE THE COVER OR Dispose of this product should THE BACK PANEL OF THIS EQUIPMENT.

  • Page 3: Table Of Contents

    AUTO-SCAN function, battery level monitoring and others. Enjoy your AU-800 and make sure to read this Manual carefully before operation! Depending on the options available your AU-800 system consists of: 1. AU-800R, PLL UHF Diversity Receiver AU-800R ANT B...
  • Page 4 1. INTRODUCTION Type: Dynamic Mic. Frequency response: 50 Hz~16 kHz( 3 dB) Impedance: 300 20% at 1kHz Sensitivity: -71 dB 3 dB Direction: Omni-directional X:1000 Hz Y:-50.9 dBv/Pa Y:-77.5 dBv/Pa Y:-48.6 dBm/Pa Y:-75.3 dBm/Pa D:0.0 dB D:0.0 dB D:-26.6 dB Microphone Frequency Response Magn dB re 1V/uBr AU-800P: A bodypack transmitter with belt clip.

  • Page 5: Features

    Weight: 52g (0.12Ib) 22g(0.049Ib) 2. FEATURES - FEATURES OF AU-800R, PLL UHF DIVERSITY RECEIVER User Friendly interface including a large blue back lighted display and an intuitive MENU system for easy operation. Auto Scan Function 2 Antennas and switching diversity circuit...

  • Page 6: Control Elements

    PLL UHF DIVERSITY WIRELESS RECEIVER ANT-A POWER ANT-B 1 Power Switch It switches your AU-800R ON and OFF . 2 UP/DOWN Keys You can adjust the right values through these two keys once the MENU is activated. 3 DISPLAY All the key functions of your AU-800 Receiver are monitored through this...
  • Page 7 3. CONTROL ELEMENTS THE REAR PANEL AF OUT 15-18V DC UNBALANCED 500mA AF OUT BALANCED 1 Audio Output XLR To connect a balanced cable with XLR connector (we forgot to tell you that although your AU-800 system is wireless, you will still need to connect receiver to your Mixing Desk and to a wall plug!) 2 Audio Output Jack...
  • Page 8 3. CONTROL ELEMENTS 4 SELECT Key Once you are in operation mode, you can access this key to edit certain parameters. Press this key for a few seconds and the unit will enter in the MUTE mode. (In this way, you can tell your Bass Player what you think about the Sound Engineer without anybody knowing that!).
  • Page 9 3. CONTROL ELEMENTS 1 LCD Display This nice blue LCD will indicate the current operation status. 2 CH/ON Key If you press this key for a few seconds, your Transmitter will be switched ON or OFF . Once you have switched the unit ON, just press this key again slightly and you can edit various parameters such as CHANNEL, GROUP , RF POWER LEVEL and LOCK/UNLOCK.

  • Page 10: Operation

    Suppose that you have more than one L TO transmitter in front of you with your AU-800R Receiver and you want to start to operate one of them with your AU-800 Receiver. First of all, you should turn your Transmitter ON, then with your AU-800R Receiver turned ON, press the MEM key at least for one second.
  • Page 11 RF bar indicator and Battery life icon will appear. Press MEM again slightly and such frequency will be stored into your AU-800R Receiver. Please note that frequencies can be scanned manually using the UP/DOWN key. See the Annex for more details.
  • Page 12 Remaining battery life Preset frequency Fig 5 And now that you know how to operate your AU-800R Receiver, let's learn how to use the AU-800 Transmitters. The following instructions apply both to the handheld version and to the bodypack version.
  • Page 13 Note: Once you have changed the operating frequency on your Transmitter, you need to activate the SCAN function in your AU-800R Receiver. In this way, the Receiver with synchronize automatically on the Transmitter frequency.
  • Page 14 4. OPERATION 3. CONTROL ELEMENTS - LOCK Function You don't want accidental change of frequency or other setting in the middle of a performance, do you? Any miss-operation during a live performance can be easily avoided thanks to the LOCK function. With the LOCK function ON no further change of setting is allowed until the Transmitter is unlocked.

  • Page 15: Annex

    5. ANNEX Frequency Band Selection Most countries closely regulate the radio frequencies used in the transmission of wireless information. These regulations state which devices can use which frequencies, and help to limit the amount of RF(radio frequency)interference in all wireless communications. To be flexible enough to operate worldwide, MOD-800R Wireless receivers are available in a number of models, each with a unique frequency range.
  • Page 16 5. ANNEX F3: 572.000-596.000(572-598)MHz Group1 Group2 Group3 Group4 Group5 Group6 572.125 572.325 572.525 572.725 572.925 573.125 573.325 573.525 573.725 573.925 574.125 574.325 574.525 574.725 574.925 575.125 575.325 575.525 575.725 575.925 576.125 576.325 576.525 576.725 576.925 577.125 577.325 577.525 577.725 577.925 578.125 578.325 578.525...
  • Page 17 5. ANNEX F5: 702.000-726.000(702-731)MHz Group1 Group2 Group3 Group4 Group5 Group6 Group7 Group8 Group9 Group10 Group11 Group12 702.125 702.325 702.525 702.725 702.925 703.125 703.325 703.525 703.725 703.925 704.125 704.325 704.525 704.725 704.925 705.125 705.325 705.525 705.725 705.925 706.125 706.325 706.525 706.725 706.925 707.125 707.325 707.525 707.725 707.925 708.125 708.325 708.525 708.725 708.925 709.125 709.325 709.525 709.725 709.925 710.125 710.325 710.525 710.725 710.925 711.125 711.325 711.525 711.725 711.925 712.125 712.325 712.525 712.725 712.925 713.125 713.325 713.525 713.725 713.925...
  • Page 18 5. ANNEX F7: 798.000-822.000(798-827)MHz Group1 Group2 Group3 Group4 Group5 Group6 Group7 Group8 Group9 Group10 Group11 Group12 798.125 798.325 798.525 798.725 798.925 799.125 799.325 799.525 799.725 799.925 800.125 800.325 800.525 800.725 800.925 801.125 801.325 801.525 801.725 801.925 802.125 802.325 802.525 802.725 802.925 803.125 803.325 803.525 803.725 803.925 804.125 804.325 804.525 804.725 804.925 805.125 805.325 805.525 805.725 805.925...
  • Page 19 5. ANNEX F8: 850.000-874.000(850-879)MHz Group1 Group2 Group3 Group4 Group5 Group6 Group7 Group8 Group9 Group10 Group11 Group12 850.125 850.325 850.525 850.725 850.925 851.125 851.325 851.525 851.725 851.925 852.125 852.325 852.525 852.725 852.925 853.125 853.325 853.525 853.725 853.925 854.125 854.325 854.525 854.725 854.925 855.125 855.325 855.525 855.725 855.925 856.125 856.325 856.525 856.725 856.925 857.125 857.325 857.525 857.725 857.925 858.125 858.325 858.525 858.725 858.925 859.125...

  • Page 20: Technical Specification

    6. TECHNICAL SPECIFICATION Model AU-800R Channel Multi-channels, up to 144 frequency presets for each frequency band UHF 470-900 MHz (Dependent on applicable country regulations) Frequency band PLL UHF SYNTHESIZED Receiver type 50 Hz-15 ( 3 dB) Frequency response 0.005% (-10 -50 ) Frequency stability 1 kHz 0.8%...

  • Page 21: Warranty

    7. WARRANTY 1. WARRANTY REGISTRATION CARD To obtain Warranty Service, the buyer should first fill out and return the enclosed Warranty Registration Card within 10 days of the Purchase Date. All the information presented in this Warranty Registration Card gives the manufacturer a better understanding of the sales status, so as to provide a more effective and efficient after-sales warranty service.
  • Page 22 NO. 1, Lane 17, Sec. 2, Han Shi West Road, Taichung 40151, Taiwan http://www.altoproaudio.com Tel: 886-4-22313737 email: alto@altoproaudio.com Fax: 886-4-22346757 All rights reserved to ALTO. All features and content might be changed without prior notice. Any photocopy, translation, or reproduction of part of this manual without written permission is forbidden. Copyright 2007 Seikaku Group NF02566-1.3...
