Alto MOD-800R Owner's Manual

Hide thumbs Also See for MOD-800R:
Table of Contents

Advertisement

Quick Links

See also: User Manual
Enlarged version
R R
LTO
OWNER'S MANUAL
MOD-800R
MOD-800H/MOD-800P/MOD-800LV/MOD-800HS/MOD-800G
WIRELESS MICROPHONE SYSTEM
SEIKAKU TECHNICAL GROUP LIMITED
NO. 1, Lane 17, Sec. 2, Han Shi West Road, Taichung 40151, Taiwan
http://www.altoproaudio.com Tel: 886-4-22313737
email: alto@altoproaudio.com Fax: 886-4-22346757
All rights reserved to ALTO. All features and content might be changed
www.altoproaudio.com
without prior notice. Any photocopy, translation, or reproduction of part of this
Version 1.3 DEC. 2007
manual without written permission is forbidden. Copyright
2007 Seikaku Group
c
NF02682-1.3
