The backplane of the mainboard has the following I/O ports:
The mainboard provides a standard PS/2 mouse/keyboard mini
PS/2 Mouse and
DIN connector for attaching a PS/2 mouse/keyboard. You can
Keyboard
plug a PS/2 mouse/keyboard directly into this connector.
Connect your VGA monitor to this port.
VGA Port
You can plug any USB device into one of the USB ports.
USB Ports
Connect an RJ-45 jack to the LAN port to connect your
LAN Port
computer to the Network.
(optional)
The Line-in jack can be connected to devices such as a
cassette or minidisk player to playback or record. The Line-out
jack is used to connect speakers or headphones for audio
Audio Ports
output. The Microphone-in jack can be connected to a
microphone for voice input.
D
e
v
i
c
e
s
D
e
v
i
c
e
s
