Syntax S740MP Manual page 11

Table of Mainboard Components
Label Component
ATX1 Standard 20-pin ATX power connector
AUDIO1 Front-oriented microphone/line-out port header
AUXIN1 Extra line-in connector
BAT1 Three volt realtime clock battery
CASFAN1 Auxiliary case cooling fan
CDIN1 CD-in connector
CNR1 Communications Networking Riser slot
CPU socket/
Socket A/onboard for AMD Athlon XP/Athlon/Duron processors
CPU onboard
CPUFAN1 Cooling fan for CPU
DDR1~DDR2 Two 184-pin DIMM sockets
EZJ1 EZ-Watcher interface header
IDE 1 Primary IDE channel
IDE 2 Secondary IDE channel
JP1 Clear CMOS jumper
JP3 BIOS protect jumper
PANEL1 Connector for case front panel switches and LED indicators
PCI1 ~ PCI2 Two 32-bit add-in card slots
RF1 IR Mouse header
SPDIF1 SPDIF out header
SJ1 Single-color LED header
SMI1 System Management Interrupt
SPEAKER1 Speaker connector
USB2 Front panel USB headers
USBCR1 USB Card Reader connector
This concludes Chapter 1. The next chapter explains how to install the
mainboard.
