Pump Kit Parts List
PK300 Pump (1)
#10 compression stopper (1)
Approx. 2" length of 5/8" clear vinyl tubing (1)
Approx. 6" length of ½" black non-kink tubing (3)
½"x½"x½" T connector (1)
**pre-assembled with the tubing
Hose clamps (7)
Wedges (2)
4mm Allen wrench (1)
Approx. 9" length of 3/8" rebar (2)
Note – Hose clamps may be used for flow restrictor
FT-151 Valencia Fountain
(3 pieces)
COMPONENTS AND PARTS LIST
FT-151A
29"L x 11.75" W x 27.5"H
127 Lbs
FT-151B
9.5"L x 5.5" W x 7.25"H
9 Lbs
FT-151C
31"L x 17.5" W x 35"H
320 Lbs
Fountain holds
approximately 5
gallons of water.
PLEASE NOTE: COMPONENTS ARE NOT SHOWN TO SCALE.
Tools you will need
Level
4mm Allen wrench (included)
Revised May 24, 2012
This fountain uses
cover FTNCOV-SM
Advertisement
Table of Contents
Related Manuals for Yard Art FT-151
Summary of Contents for Yard Art FT-151
- Page 1 FT-151 Valencia Fountain (3 pieces) Revised May 24, 2012 COMPONENTS AND PARTS LIST uniquegardendecor.com (866) 382-8600 FT-151A 29”L x 11.75” W x 27.5”H 127 Lbs FT-151B 9.5”L x 5.5” W x 7.25”H 9 Lbs FT-151C 31”L x 17.5” W x 35”H...
- Page 2 FT-151 Valencia Fountain (3 pieces) Revised May 24, 2012 ASSEMBLY INSTRUCTIONS Three people are recommended for the installation of this fountain! 1. Make sure you are assembling your fountain on a level surface. 2. This fountain will need to be installed on a surface capable of holding a minimum of 500 pounds in approximately a 1.1 square foot area.
