FT-290 Avignon Fountain
(6 Pieces)
Components and Parts List
FT-290F
52"x52"x12.25"
602 lb
FT-290D
13.25"x13.25x10.5"
55 lb
FT-290B
11"x11"x11"
180 lb
FT-290C
7"x7"x1.25"
4 lb
800 GPH Pump
Metal Hose Clamps (3)
#10 Compression Stopper
FT-290A
4mm Allen Wrench
11"x11"x10"
12" 5/8" non-kink hose (1)
83 lb
2" length 5/8" clear tubing (2)
Wedges (3)
2.8 oz Silicone (1)
Spiller Spouts (3)
FT-290E
6.75"x1.5"x6.5"
4 lb
Pump Kit and Parts List
Tools needed
Level
4mm Allen Wrench
This Fountain Uses
FTNCOV-Med
Advertisement
Table of Contents
Related Manuals for Yard Art Avignon Fountain FT-290
Summary of Contents for Yard Art Avignon Fountain FT-290
- Page 1 FT-290 Avignon Fountain (6 Pieces) uniquegardendecor.com Components and Parts List (866) 866) 382-8600 FT-290F 52”x52”x12.25” 602 lb FT-290D 13.25”x13.25x10.5” 55 lb FT-290B 11”x11”x11” 180 lb FT-290C 7”x7”x1.25” 4 lb Pump Kit and Parts List Tools needed 800 GPH Pump Level Metal Hose Clamps (3) 4mm Allen Wrench #10 Compression Stopper...
- Page 2 FT-290 Avignon Fountain (6 Pieces) Revised July 12, 2016 Assembly Instructions 1. Make sure you are assembling your fountain on a level surface capable of holding a minimum of 900 pounds with approximately a 8 square foot footprint. 2. Place the base (FT-290F) into position where the fountain will be installed, ensuring that it is level..
- Page 3 be completely underwater to function properly. Test all pumps and adjust to full output prior to assembly. It is not recommended that fountains be placed directly on grass or dirt. Position the channel opening at the base of each fountain toward the electrical outlet to be used since the pump cord will be threaded through this opening.
