Non kink
Tubing
Pump
Compression
Stopper
PK140 Pump (1)
Approx. 15" length of ½" black non-kink tubing (1)
#10 compression stopper (1)
Wedges (4)
Hose clamps (3)
4mm Allen wrench
Note – Hose clamps may be used as flow restrictor
FT-34 Platia Fountain
(6 pieces)
COMPONENTS AND PARTS LIST
Pump Kit Parts List
FT-34A
15 ¼ "W x 4.5"H
34 lbs
FT-34B
22 ¼'W x 6"H
83 lbs
FT-34D
30 ¼ "W x 7 ¾ "H
165 lbs
FT-34C
11"W x 5"H
16 lbs
FT-34E
14" W x 4" H
28 lbs
Fountain holds
approximately 8
gallons of water
NOTE: Component drawings are not to scale
Tools you will need
Level
4mm Allen wrench (included)
This fountain uses cover FTNCOV-SM
Revised May 24, 2012
FT-34CC
5"L x 2" W x 3 ½" H
1 lbs
Advertisement
Table of Contents
Related Manuals for Yard Art Platia FT-34
Summary of Contents for Yard Art Platia FT-34
- Page 1 FT-34 Platia Fountain (6 pieces) Revised May 24, 2012 COMPONENTS AND PARTS LIST uniquegardendecor.com (866) 382-8600 FT-34A 15 ¼ “W x 4.5”H 34 lbs FT-34B 22 ¼’W x 6”H 83 lbs Non kink Tubing FT-34D 30 ¼ ”W x 7 ¾ ”H 165 lbs Pump Compression...
