- Page 1 8K Two-Input Dual View Follow us on Youtube and Facebook HDMI Splitter U S E R M A N U A L www.orei.com...
-
Page 2: Table Of Contents
Table of Contents Introduction Features Package Contents Specifications Operation Controls and Functions Application Example Thank you for purchasing this product Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this prod- uct. - Page 3 OREI Live Technical Support Hours US team (US/Canada/Mexico): Monday-Friday, 9 a.m. - 6 p.m. Central Time Support Email - info@orei.com |Support Number - 877-290-5530 Chat Live on www.orei.com Send us an instant message now. Our Technical Support Team will respond momentarily.
-
Page 4: Introduction
Introduction This 8K Two-Input Dual View HDMI Splitter can not only switch any of the two HDMI input signals, but also distribute it to two displays simultaneously. It supports video resolution up to 8K@60Hz 4:2:0. As able to be used either as a splitter or a switcher, this multi-functional product can be widely applied in scenarios of demonstration, video conference, multimedia teaching and other occassions requiring for big-screen demonstration. -
Page 5: Features
Features HDMI 2.1 and HDCP 2.3 compliant Support 40Gbps video bandwidth Support video resolution up to 8K@60Hz 4:2:0 Support HDMI audio formats: LPCM 7.1CH, Dolby TrueHD, and DTS-HD Master Audio Support HDR, HDR10, HDR10+, Dolby Vision, ALLM/VRR pass through 2x1 Switch with Dual Output Built-in Equalizer, Retiming and Driver Auto EDID management Compact design for easy and flexible installation... -
Page 6: Specifications
Specifications Technical HDMI Compliance HDMI 2.1 HDCP Compliance HDCP 2.3 Video Bandwidth 40Gbps Up to 8K@60Hz YCBCR 4:2:0 10bit, 8K30 RGB/ Video Resolution YCBCR 4:4:4 10bit or,4K120 RGB/YCBCR 4:4:4 10bit Color Depth 8-bit,10-bit,12-bit Color Space RGB, YCbCr 4:4:4 / 4:2:2. YCbCr 4:2:0 Support HDR, HDR10, HDR10+, Dolby Vision, ALLM/VRR pass through LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS,... - Page 7 Specifications Mechanical Housing Metal Enclosure Color Black Dimensions 115mm (W) × 68mm (D) × 18mm (H) Weight 220g Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F Relative Humidity 20~90% RH (Non-condensing) Power Consumption (Max) 2.25W (Max) Input: AC100 - 240V 50/60Hz,...
-
Page 8: Operation Controls And Functions
Operation Controls and Functions Front Panel IN 1 IN 2 OUT 1 OUT 2 SWITCH SERVICE Rear Panel IN 1I OUT 1 OUT 2 DC 5V Name Function Description POWER LED When the device is powered on, the red LED will be on. IN LED When the HDMI IN 1/2 port connects an active source device, the corresponding green LED will be on. - Page 9 Operation Controls and Functions Note: 1. When the device is powered on, it will start to work. Both OUT1 and OUT2 are defaulted to output the source signal from the IN1 port. 2. The device supports memory function in case of power-down. 3.
-
Page 10: Application Example
Application Example page 10... - Page 11 Application Example page 11...
- Page 12 8K Two-Input Dual View HDMI Splitter www.orei.com © 2021...
