- Page 1 K2024-52PHR-S EASTWOOD POWER RECLINING SOFA USER MANUAL...
- Page 2 Components: Switch – mounted on the side of furniture and controls all motors and functions (reclining, power headrest, • etc.) via a direct connection with motors. AC power cord – connects the power transformer to the power outlet. • DC cord – connects the power transformer to the DC socket (mounted on the rear bottom of LAF arm stump). •...
- Page 3 Power Recliner PARTS...
- Page 4 Quick Trouble-Shoot for Motors Malfunctioning: Below are some possible reasons to cause motors to stop working: 1. Loose connection or wires not securely plugged in. 2. AC power cord damaged 3. Broken power transformer (especially when ALL motors stop working on one unit) 4.
- Page 5 Trouble-Shooting Guide Motor System Troubleshoot Error Analysis Troubleshoot The AC power cord is not plugged Check that the AC power cord is properly plugged into the socket The motor system connection is Check whether the connection between related parts is disconnected disconnected according to electrical connection diagram.
- Page 6 Trouble-Shooting Guide Motor System Troubleshoot Error Analysis Troubleshoot 1、Check whether the connection between related parts is disconnected according to electrical connection diagram. Seat motor can work The headrest motor is disconnected 2、Check whether the cables of headrest motor are squeezed, skined or but headrest motor not work or damaged.
- Page 7 Trouble-Shooting Guide USB Charging System Troubleshoot 1、Output : 5V / 2A CAUTION： 2、USB ports only charging mobile devices (not compatible with computers) 3、Do not use usb splitter/extenders, do not Charger multiple devices at one time, otherwise damages could occur. Error Analysis Troubleshoot The input requirements of the mobile...
- Page 8 Trouble-Shooting Guide Bluetooth Speakers System Troubleshoot Error Analysis Troubleshoot The AC power cord is not plugged Check that the AC power cord is properly plugged into the socket The bluetooth speakers system Check whether the connection between related parts is disconnected connection is disconnected according to electrical connection diagram.
- Page 9 Trouble-Shooting Guide Reading Light System Troubleshoot Error Analysis Troubleshoot The AC power cord is not plugged Check that the AC power cord is properly plugged into the socket The reading light system connection Check whether the connection between related parts is disconnected is disconnected according to electrical connection diagram.
- Page 10 Trouble-Shooting Guide Light Cupholder System Troubleshoot Error Analysis Troubleshoot The AC power cord is not plugged Check that the AC power cord is properly plugged into the socket The light cupholder system connection Check whether the connection between related parts is disconnected is disconnected according to electrical connection diagram.
- Page 11 Trouble-Shooting Guide Multi-socket System Troubleshoot 1、AC socket input/output：125V/12A/1500W MAX 2、Wireless charging : 5V/1A/5W MAX；Distance≤5mm 3、USB output : 5V/2A/10W MAX； CAUTION： 4、Meaning of wireless charging indicator：Blue=Standby mode，Green=In charging，Flash=Restart； 5、USB ports only charging mobile devices (not compatible with computers) 6、Do not use usb splitter/extenders, do not Charger multiple devices at one time, otherwise damages could occur. Error Analysis Troubleshoot...
- Page 12 Power Recliner Trouble Shooting Check if the green light on power transformer is on Check power Check connection cords integrity and connection to security and transformer. components integrity If power cords on DC socket and undamaged, and power cable. connection secured, replace power transformer.
