- Page 1 CAD Re-assembly instructions for our neutral CAD file formats Product: Microfilter, Series NL4-FLC Parts assembled: 2 (5) Consists of following parts: 5 pcs Parts assembled: 2 (5) 1(3) Emerson Automation Solutions | AVENTICS cad_re-ass_nl4-flc-5_v02.docx...
- Page 2 Constraint 1(1) : Insert Constraint 1(3) : Insert Constraint 2(3) : Align Constraint 3(3) : Mate Insert Constraint 2(3) : Mate Constraint 3(3) : ”Apply the same to assemble ” 2nd Cap” with Filter body” 2(3) Emerson Automation Solutions | AVENTICS cad_re-ass_nl4-flc-5_v02.docx...
- Page 3 Mate instructions, step by step for easy handling 3 – Assemble Filter Body & Protective Guard Parts assembled: 5(5) Constraint 1(1) : Insert Constraint 1(2) : Insert Constraint 2(2) : Mate Insert Constraint 2(3) : 3(3) Emerson Automation Solutions | AVENTICS cad_re-ass_nl4-flc-5_v02.docx...
