LPV 3 Sided Stoves
LPV Linear Purevision Freestanding Stove Range
5kW & 8kW Nominal Outputs.
Installation and Operating Instructions
Please hand these instructions to the stove user when the installation is complete. Leave the stove
ready for operation and instruct the user in the correct use of the appliance and operation of controls.
Important: – These products must be installed by a suitably qualified
installer.
Clean Air Act Exemption
The Purevision LPV 5 5Kw & LPV8 8kW stoves only have been exempted under the Clean Air Act 1993
to burn seasoned wood logs in designated smokeless zones in the UK. This is subject to the correct
fitting of the air control plate (the part and fitting instructions are packed separately) maintaining the
air wash control at a minimum opening at all times. Instructions for wood burning MUST be followed
in order to ensure compliance at all times.
Fireline UK
– A division of: Charlton & Jenrick Ltd
Unit D Stafford Park 2, Telford, Shropshire, TF3 3AR
T: 01952 200 444
F: 01952 200480
www.charltonandjenrick.co.uk
A Charlton and Jenrick Group Company
