Digital Loggers Ethernet Power Controller 7 User Manual page 9

the power controller. Scripts may be started manually,
automatically on power-up, by external http commands, or by
AutoPing events. Find a list of commands and examples at:
digital-loggers.com/scripts.html
AutoPing
The AutoPing page lets you set parameters to automatically
reboot attached equipment. First, specify an IP address to ping.
Next, adjust the timing settings and use the checkboxes to link the
IP to power circuits. For example, if a router is unreachable, you
may choose to automatically reboot both a router and a switch
attached to two different circuits. See page 12.
System Log
The power controller keeps an internal event log including logins,
outlet switching, power interruptions, and AutoPing events. Recent
events are stored in the log and accessible from the System Log
page. SYSLOG export is supported. For more information: digital-
loggers.com/syslog.html
Logout
Browser logout is automatic when a session is closed or after a
time-out period. Use this link to logout in advance.
Programmable Web Links
User-defined web links are provided. Set names and destination
URLs for these links on the Settings page.
Switching Outlets
The outlet control page lets you control any duplex outlet (except
the always-on pair). A master control allows those users with
access to switch all outlets on or off.
To switch an outlet, simply click to the right of the outlet name or
number. On->Off switching is immediate Off->On switching is
subject to the configurable On Sequence Delay..
Ethernet Power Controller 7
9
