IP Setup
If your network settings won't access the default IP, use a direct
cable connection (temporarily bypass any switch or router)
and follow these steps to add a compatible static IP, such as
192.168.0.50 Before adding an IP, close all programs and
browsers. After the link is established, you can enable DHCP.
Windows Step 1
In Windows, the first step is locating the network adapter TCP/IP
properties. The procedure differs for each Windows version:
Windows XP, 2000, 2003: Open Start / Control Panel / Network
Connections. In "classic view", select Start / Settings / Control
Panel /Network Connections. Right-click on Local Area
Network Connection and select Properties. Proceed to step 2.
Windows Vista: Open Start, right click on Network, then on
Properties. Double click Network and Sharing Center, click
Manage Newtork Connections. A Network Connections window
appears. Right click on the network connection to the switch, ie.
Local Area Network. Proceed to step 2.
Windows 7: Open the Start orb, click on Control Panel. Click
View Network Status and Tasks, then Change Adapter
Settings. Proceed to step 2
Windows 8-10:
Mouse or swipe to the bottom right corner and
select Settings. Select Control Panel. Select Network and
Sharing Center or Network->Network Settings. Click change
Adapter Settings or Adapter Options. Right click on your
connected network and select Properties. Proceed to step 2
Windows Step 2
The second step is adding an IP such as 192.168.0.50
Temporarily disable DHCP while configuring the switch.
