JVC GR-X5AA Instructions Manual

JVC GR-X5AA Instructions Manual

Digital video camera
Hide thumbs Also See for GR-X5AA:
Table of Contents

Advertisement

Quick Links

DIGITAL VIDEO CAMERA

GR-X5EK/E
Please visit our Homepage on the World Wide Web for
Digital Video Camera:
http://www.jvc.co.jp/english/cyber/
For Accessories
:
http://www.jvc.co.jp/english/accessory/
INSTRUCTIONS
Dear Customer,
Thank you for purchasing this digital
video camera. Before use, please
read the safety information and
precautions contained in the pages
3 – 4 and 10 to ensure safe use of
this product.
GETTING STARTED
VIDEO RECORDING &
PLAYBACK
DIGITAL STILL CAMERA
(D.S.C.) RECORDING &
PLAYBACK
ADVANCED FEATURES
REFERENCES
TERMS
To deactivate the demonstration,
set "DEMO MODE" to "OFF".
(
pg. 33, 36)
LYT1436-001A
ENGLISH
6
18
25
33
51
62
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GR-X5AA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JVC GR-X5AA

Summary of Contents for JVC GR-X5AA

  • Page 1: Digital Video Camera

    DIGITAL VIDEO CAMERA GR-X5EK/E Please visit our Homepage on the World Wide Web for Digital Video Camera: http://www.jvc.co.jp/english/cyber/ For Accessories http://www.jvc.co.jp/english/accessory/ INSTRUCTIONS Dear Customer, Thank you for purchasing this digital video camera. Before use, please read the safety information and precautions contained in the pages 3 –...

  • Page 2: Direct Printing

    Major Features of this Camcorder Wipe/Fader Effects You can use the wipe/fader effects to make pro-style scene transitions. ( Fade out Program AE and Special Effects For example, “SPORTS” mode allows fast- moving images to be captured one frame at a time, for vivid, stable slow-motion.

  • Page 3: Safety Precautions

    This product includes patented and other proprietary technology and will operate only with JVC Data Battery. Use the JVC BN-VF707U/VF714U/VF733U battery packs and, to recharge them or to supply power to the camcorder from an AC outlet, use the provided multi-voltage AC Adapter.
  • Page 4 When the equipment is installed in a cabinet or on a shelf, make sure that it has sufficient space on all sides to allow for ventilation (10 cm or more on both sides, on top and at the rear). Do not block the ventilation holes. (If the ventilation holes are blocked by a newspaper, or cloth etc.

  • Page 5: Table Of Contents

    GETTING STARTED Index ... 6 Provided Accessories ... 10 LCD Monitor... 12 Power... 13 Operation Mode ... 14 Language Setting ... 15 Date/Time Settings ... 15 Grip Adjustment ... 15 Brightness Adjustment of the Display ... 16 Tripod Mounting... 16 Loading/Unloading a Cassette...

  • Page 6: Getting Started

    GETTING STARTED Index j k lmno When loading or unloading a cassette, disconnect the headphone cable, etc. and close the cover. If the cover is open, it may get caught in cassette holder. tu v...

  • Page 7: Other Parts

    Controls Set Button [SET] ( pg. 33) Play/Pause Button [4/9] ( Night-Scope Button [NIGHT] ( Up Button Fast-Forward Button [ Flash Button [FLASH] ( pg. 39) Rewind Button [ pg. 20) Quick Review Button [QUICK REVIEW] pg. 20) Stop Button [8] ( pg.
  • Page 8 GETTING STARTED Indications on LCD Monitor During Video Recording Only SOUND 12BIT 15:55 Selected Wipe/Fader Effect Indicator pg. 44) Tape Running Indicator ( (Rotates while tape is running.) Selected Wide Mode Indicator ( Recording Speed Mode (SP/LP) ( Tape Remaining Time ( REC: (Appears during recording.) ( PAUSE: (Appears during record-standby mode.) (...
  • Page 9 Special Effect Indicator ( : Spot Exposure Control Indicator pg. 42) : Backlight Compensation Indicator pg. 42) ±: Exposure Adjustment Indicator ( Iris Lock Indicator ( pg. 42) Approximate Zoom Ratio ( Zoom Indicator ( pg. 19) Self-Timer Recording Indicator ( O: (Appears when taking snapshot.) pg.

  • Page 10: Provided Accessories

    So, for important recordings, we recommend using SP mode. It is recommended that you use JVC brand cassette tapes. Your camcorder is compatible with all brands of commercially available cassette tapes complying...
  • Page 11 AC Adapter AP-V17E or AP-V14E Power Cord (only for AP-V14E) Battery Pack BN-VF707U S-Video/Audio/Video Cable USB Cable Audio Extension Cable (for optional microphone, see page 12 for connection) Audio Extension Cable (for optional headphone, see page 12 for connection) Core Filter [large] (for USB cable, see page 12 for attachment) Core Filter [large] (for power cord, only for AP-V14E, see page 12 for attachment)

  • Page 12: Lcd Monitor

    GETTING STARTED Attaching the Core Filter Attach the core filters to the cables. The core filter reduces interference. Release the stoppers on both ends of the core filter. Run the cable through the core filter, leaving approx. 3 cm of cable between the cable plug and the core filter.

  • Page 13: Power

    * Provided NOTES: This product includes patented and other proprietary technology and will operate only with JVC Data Battery. Use the JVC BN- VF707U/VF714U/VF733U battery packs. Using generic non-JVC batteries can cause damage to the internal charging circuitry. If the protective cap is attached to the battery pack, remove it first.

  • Page 14: Operation Mode

    DATA several times, there may be a problem with your battery. In such a case, consult your nearest JVC dealer. The recordable time display should only be used as a guide. It is displayed in 10 minute units.

  • Page 15: Language Setting

    VIDEO/MEMORY Switch Position VIDEO: Allows you to record on a tape or play back a tape. If “REC SELECT” is set to “ pg. 37), still images are recorded both on the tape and the memory card. MEMORY: Allows you to record in a memory card or access data stored in a memory card.

  • Page 16: Brightness Adjustment Of The Display

    GETTING STARTED Brightness Adjustment of the Display Set the power switch to “M” or “PLAY” while pressing down the lock button located on the switch. Open the LCD monitor fully. ( pg. 12) Press MENU. The menu screen appears. Press Up ( Down (8) to select “n”, and press SET.

  • Page 17: Loading/Unloading A Memory Card

    To protect valuable recordings Slide the erase protection tab on the back of the tape in the direction of “SAVE”. This prevents the tape from being recorded over. To record on this tape, slide the tab back to “REC” before loading it.

  • Page 18: Video Recording & Playback

    VIDEO RECORDING Basic Recording NOTE: Before continuing, perform the procedures listed below: Power ( pg. 13) Loading A Cassette ( pg. 16) POWER/CHARGE Lamp Power Switch Lock Button Recording Start/Stop Button Tally Lamp (Lights while recording is in progress.) Power Zoom Lever Remove the lens cap.

  • Page 19: Zooming

    Zooming Produces the zoom in/out effect, or an instantaneous change in image magnification. To zoom in Slide the power zoom lever towards “T”. To zoom out Slide the power zoom lever towards “W”. Zoom in (T: Telephoto) 1 xW 1 0 xW 20xW Zoom out (W: Wide angle) 10 x W...

  • Page 20: Quick Review

    NOTES: The time code cannot be reset. During fast-forwarding and rewinding, the time code indication does not move smoothly. The time code is displayed only when “TIME CODE” is set to “ON”. ( pg. 36) Quick Review Enables to check the end of the last recording. 1) Press QUICK REVIEW (3) during the record-standby mode.

  • Page 21: Shuttle Search

    Shuttle Search Allows high-speed search in either direction during video playback. 1) During playback, press 5 for forward search, or 3 for reverse search. 2) To resume normal playback, press 4/9. During playback, press and hold 5 or 3. The search continues as long as you hold the button.

  • Page 22: Connections To A Tv Or Vcr

    VIDEO PLAYBACK Connections to a TV or VCR Open the cover. S-Video/Audio/Video cable (provided) [Y/C] / [CVBS] Video Out Select Switch Black to S-VIDEO IN (Connect when your TV/ VCR has S-VIDEO IN and A/V input connectors. In this case, it is not necessary to connect the yellow video cable.) Yellow to VIDEO IN (Connect when your TV/ VCR has only A/V input connectors.)

  • Page 23: Playback Using The Remote Control

    Playback Using the Remote Control The full-function remote control unit can operate this camcorder from a distance as well as the basic operations (playback, stop, pause, fast- forward and rewind) of your VCR. It also makes additional playback functions possible. pg.

  • Page 24: Playback

    VIDEO PLAYBACK Zoom (T/W) SLOW (YI) PLAY (Left) SHIFT Slow-Motion Playback During normal video playback, press SLOW (YI or IU) more than approx. 2 seconds. After approx. 10 minutes, normal playback resumes. To pause slow-motion playback, press PAUSE (9). To stop slow-motion playback, press PLAY (U). NOTES: You can also engage slow-motion playback from Still Playback by pressing SLOW (YI or IU) more...

  • Page 25: D.s.c. Recording

    Basic Shooting (D.S.C. Snapshot) You can use your camcorder as a Digital Still Camera for taking snapshots. Still images are stored in the memory card. NOTE: Before continuing, perform the procedures listed below: Power ( pg. 13) Loading a Memory Card ( pg.

  • Page 26: Interval Shooting

    Interval Shooting During interval shooting mode, the camcorder continues to take snapshots automatically with an interval of your desired setting. Set “INT.SHOT” to “ON”. ( “INTERVAL” and “ ” appear. Set “INT.TIME” to the desired shooting interval. ( pg. 33, 37) Set the power switch to “A”...

  • Page 27: Index Playback Of Files

    Index Playback of Files You can view several different files stored in the memory card at a time. This browsing capability makes it easy to locate a particular file you want. Perform steps 1 – 3 in “Normal Playback of Images”...

  • Page 28: Additional Features For D.s.c

    ADDITIONAL FEATURES FOR D.S.C. Dubbing Still Images Recorded on a Tape to a Memory Card Still images can be dubbed from a tape to a memory card. Load a cassette. ( pg. 16) Load a memory card. ( Set the VIDEO/MEMORY switch to “VIDEO”. Set the power switch to “PLAY”...

  • Page 29: Deleting Files

    To Remove Protection Before doing the following, perform steps 1 – 3 in “Protecting Files”. To remove protection from the currently displayed file Press Up (4/9) or Down (8) to select “CURRENT”, and press SET. The PROTECT screen appears. Press 3 or 5 to select the desired file. Press Up (4/9) or Down (8) to select “EXECUTE”, and press SET.

  • Page 30: Setting Print Information (Dpof Setting)

    ADDITIONAL FEATURES FOR D.S.C. Setting Print Information (DPOF Setting) This camcorder is compatible with the DPOF (Digital Print Order Format) standard in order to support future systems such as automatic printing. You can select one of the 2 print information settings for images stored in the memory card: “To Print All Still Images (One Print For Each)”...

  • Page 31: Direct Printing With A Pictbridge Printer

    To Reset the Number of Prints Perform steps 1 – 3 in “To Print All Still Images (One Print For Each)”. Press Up (4/9) or Down (8) to select “RESET”, and press SET. The DPOF screen appears. Press Up (4/9) or Down (8) to select “EXECUTE”, and press SET.

  • Page 32: Initialising A Memory Card

    ADDITIONAL FEATURES FOR D.S.C. To print using the DPOF setting If the printer is compatible with DPOF, you can use the DPOF setting. ( pg. 30) Perform steps 1 – 3 in “Normal Playback of Images” ( pg. 26). Press MENU. The menu screen appears. Press Up (4/9) or Down (8) to select “DIRECT PRINT”, and press SET.

  • Page 33: Advanced Features

    Changing the Menu Settings This camcorder is equipped with an easy-to-use, on-screen menu system that simplifies many of the more detailed camcorder settings. pg. 34 – 38) VIDEO/MEMORY Up (4/9) Power Switch MENU Down (8) For Video and D.S.C. Recording Menus: Set the VIDEO/MEMORY switch to “VIDEO”...

  • Page 34: Recording Menus

    MENUS FOR DETAILED ADJUSTMENT Recording Menus CAMERA The “m CAMERA” settings are effective when the power switch is set to both “A” and “M”. However, the menu settings can be changed only when the power switch is set to “M”. [ ] = Factory-preset REC MODE [SP]: To record in the SP (Standard Play) mode...
  • Page 35 SELF-TIMER [OFF] / ON pg. 40, “Self-Timer” [OFF]: Disables 5-second recording. 5S: Enables 5-second recording. ( Anim.: Allows you to record a few frames only. By using an inanimate object and changing its position between shots, you can record the subject as though it is moving.

  • Page 36: Camera Display

    MENUS FOR DETAILED ADJUSTMENT DEMO MODE OFF: Automatic demonstration will not take place. [ON]: Demonstrates certain functions such as program AE or special effects, etc., and can be used to confirm how these functions operate. Demonstration starts in the following cases: When the menu screen is closed after “DEMO MODE”...

  • Page 37: Playback Menus

    IMAGE SIZE 640 x 480 / 1280 x 960 / 1600 x 1200 / 2048 x 1536 / [2560 x 1920] The image size mode can be selected to best match your needs. ( pg. 61) NOTE: The setting can be changed only when the VIDEO/ MEMORY switch is set to “MEMORY”.

  • Page 38: Video Display

    MENUS FOR DETAILED ADJUSTMENT REC MODE [SP] / LP Allows you to set the video recording mode (SP or LP) depending on your preference. It is recommended you use “REC MODE” in VIDEO menu when using this camcorder as a recorder during dubbing.

  • Page 39: Features For Recording

    Snapshot Flash The flash can be used when a snapshot is taken in Record- Standby mode. ( pg. 25, 39) You can select the flash setting. Press FLASH ( repeatedly to select the desired mode. ]: Fires automatically if it ±0A is dark.

  • Page 40: Night-Scope

    FEATURES FOR RECORDING Night-Scope Makes dark subjects or areas even brighter than they would be under good natural lighting. Although the recorded image is not grainy, it may look as if it is strobing due to the slow shutter speed. Set the power switch to “M”.

  • Page 41: Manual Focus

    Manual Focus The camcorder’s full range AF system offers continuous shooting ability from close-up (as close as approx. 5 cm to the subject) to infinity. However, correct focus may not be obtained depending on the shooting condition. In this case, use the manual focus mode. Set the power switch to “M”.

  • Page 42: Iris Lock

    FEATURES FOR RECORDING Iris Lock Like the pupil of the human eye, the iris contracts in well-lit environments to keep too much light from entering, and dilates in dim environments to allow in more light. Use this function in the following situations: When shooting a moving subject.

  • Page 43: White Balance Adjustment

    White Balance Adjustment The white balance refers to the correctness of colour reproduction under various lighting. If the white balance is correct, all other colours will be accurately reproduced. The white balance is usually adjusted automatically. However, more advanced camcorder operators control this function manually to achieve a more professional colour/ tint reproduction.

  • Page 44: Wipe Or Fader Effects

    FEATURES FOR RECORDING Wipe or Fader Effects These effects let you make pro-style scene transitions. Use them to spice up the transition from one scene to the next. Wipe or fader works when video recording is started or stopped. Set the VIDEO/MEMORY switch to “VIDEO”. Set the power switch to “M”.

  • Page 45: Special Effects

    A PRIORITY (F1.8 – F8.0): After selecting “A PRIORITY” (Aperture Priority) in step 3, rotate the manual focus dial to select the desired value, and press SET. You can set the aperture value (F-number) manually. The larger the aperture value (lower F-number), the more blurred the background will become.

  • Page 46: Editing

    EDITING Dubbing to or from a VCR Open the cover. S-Video/Audio/Video cable (provided) [Y/C] / [CVBS] Video Out Select Switch To S-VIDEO IN or OUT** Yellow to VIDEO IN or OUT Red to AUDIO R IN or OUT White to AUDIO L IN or OUT If your VCR has a SCART connector, use the provided cable adapter.

  • Page 47: Dubbing To Or From A Video Unit Equipped With A Dv Connector (Digital Dubbing)

    DV IN/OUT connector. When using a DV cable, be sure to use the optional JVC VC-VDV204U DV cable. To use this camcorder as a recorder Make sure all units are turned off.

  • Page 48: Connection To A Personal Computer

    EDITING Connection to a Personal Computer [A] Using USB cable [B] Using DV cable To USB USB cable (provided) To USB connector PC with DV connector When connecting the camcorder to a PC using a DV cable, make sure to follow the procedure below.

  • Page 49: Insert Editing

    Connect only the cable you wish to use to the camcorder. When using a DV cable, be sure to use the optional JVC VC-VDV206U or VC-VDV204U DV cable depending on the type of DV connector (4 or 6 pins) on the PC.

  • Page 50: Audio Dubbing

    EDITING Audio Dubbing The audio track can be customized only when recorded in the 12-BIT and SP modes. pg. 34) Use the provided remote control. Stereo Microphone Microphone connector Speaker Headphone connector Play back the tape to locate the point where editing will start, then press PAUSE (9).

  • Page 51: References

    If, after following the steps in the chart below, the problem still exists, please consult your nearest JVC dealer. The camcorder is a microcomputer-controlled device. External noise and interference (from a TV, a radio, etc.) might prevent it from functioning properly. In such cases, first disconnect its power supply unit (battery pack, AC adapter, etc.) and wait a few minutes;...
  • Page 52 TROUBLESHOOTING Advanced features The focus does not adjust automatically. Focus is set to the manual mode. HSet focus to the auto mode. ( The lens is dirty or covered with condensation. HClean the lens and check the focus again. pg. 56) In the 5-second mode, recording ends before 5 seconds have elapsed.
  • Page 53 15) The built-in clock battery has run out and the previously set date/time has been erased. HConsult your nearest JVC dealer for replacement. Files stored in the memory card cannot be deleted. Files stored in the memory card are protected.
  • Page 54 Appears when the date/time is not set. pg. 15) The built-in clock battery has run out and the previously set date/time has been erased. Consult your nearest JVC dealer for replacement. Exhausted LENS CAP Appears for 5 seconds after power is turned on if the lens cap is attached or when it is dark.
  • Page 55 INSERT ERROR! Appears if insert editing is attempted on a blank portion of a tape. ( pg. 49) INSERT ERROR! <CANNOT EDIT ON A BLANK PORTION> <CANNOT EDIT ON A LP RECORDED TAPE> <CHECK TAPE’S ERASE PROTECTION TAB> Appears if insert editing is attempted on a blank portion of a tape.

  • Page 56: User Maintenance

    (battery, etc.) and wait a few minutes for the indication to clear. When it does, you can resume using the camcorder. If the indication remains, consult your nearest JVC dealer. UNIT IN SAFEGUARD MODE EJECT AND REINSERT TAPE The error indications (03 or 04) show what type of malfunction has occured.

  • Page 57: Cautions

    Battery Packs The supplied battery pack is a lithium-ion battery. Before using the supplied battery pack or an optional battery pack, be sure to read the following cautions: To avoid hazards ... do not burn..do not short-circuit the terminals. When transporting, make sure the provided battery cap is attached to the battery.
  • Page 58 CAUTIONS Memory Cards To properly use and store your memory cards, be sure to read the following cautions: During use ... make sure the memory card bears the SD or MultiMediaCard mark..make sure the memory card is positioned properly when inserting.
  • Page 59 20 seconds, it stops automatically. Also refer to the cleaning cassette’s instructions. If, after using the cleaning cassette, the problems still exist, consult your nearest JVC dealer. Mechanical moving parts used to move the video heads and video tape tend to become dirty and worn out over time.

  • Page 60: Specifications

    SPECIFICATIONS Camcorder For General Power supply DC 11 V (Using AC adapter) DC 7.2 V (Using battery pack) Power consumption Approx. 4.8 W (LCD backlight off) Approx. 5.8 W (LCD backlight on) Approx. 6.5 W (Maximum; when charging the battery pack) Dimensions (W x H x D) 88 mm x 89 mm x 93 mm (with the LCD monitor closed)
  • Page 61 Approximate Number of Storable Images The number increases or decreases depending on the picture quality/image size, etc. Image Size/Picture Quality 640 x 480/ FINE 640 x 480/ STANDARD 1280 x 960/ FINE 1280 x 960/ STANDARD 1600 x 1200/ FINE 1600 x 1200/ STANDARD 2048 x 1536/...

  • Page 62: Terms

    TERMS AC Adapter ... 14 Animation ... 35 Audio Dubbing ... 50 Backlight Compensation ... 42 Battery Pack ... 13, 14, 57 Beep ... 35 Blank Search ... 21 Bracket Shooting ... 25 Changing the Menu Settings ... 33 – 38 Charging the Battery Pack ...
  • Page 63 TERMS Self-Timer ... 40 Slow-Motion Playback ... 24 Snapshot Mode ... 34 Sound Mode ... 34, 37 Speaker Volume ... 20 Special Effects ... 45 Specifications ... 60 Spot Exposure Control ... 42 Tape Speed (REC MODE) ... 34, 38 Telephoto Setting (TELE MACRO) ...
  • Page 64 COPYRIGHT; OWNERSHIP You acknowledge that all copyrights and other intellectual property rights in the Program are owned by JVC and its licensor, and remain vested in JVC and such licensor. The Program is protected under the copyright law of Japan and other countries, and related Conventions.
  • Page 65 CONTRACT, TORT OR OTHERWISE ARISING OUT OF OR IN CONNECTION WITH THE USE OF OR INABILITY TO USE THE PROGRAM, EVEN IF JVC HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. YOU WILL INDEMNIFY AND HOLD HARMLESS JVC FROM...

  • Page 66: Notice For Users

    CD-ROM to run this software. Do not attempt to modify this software. Changes or modifications not approved by JVC could void user’s authority to operate the equipment. How to handle a CD-ROM Take care not to soil or scratch the mirror surface (opposite to the printed surface).

  • Page 67: System Requirements

    PC card adapter CU-VPSD60 or the floppy disk adapter CU-VFSD50 to load the files in the memory card to the hard disk on your PC. (Refer to “JVC Accessories” on our world web site at: http://www.jvc-victor.co.jp/ english/accessory/) ● Microsoft...

  • Page 68: Software Installation

    Software Installation ® (Windows Follow the procedure described below to install the software. From the [SETUP] screen in step 2, you can install the following drivers or software. Quit any other software you are using. (Check that there are no other application icons on the status bar.) USB Mass Storage Class driver This driver allows your PC to read and write...
  • Page 69 Following steps are the example of CyberLink DVD Solution on ® Windows [Choose Setup Language] screen appears. Select the desired language and click [OK]. Then, [CyberLink DVD Solution Setup] screen appears. Click [Next]. [License Agreement] screen appears. Click [Yes]. [Customer Information] screen appears.
  • Page 70 Updating [Device Manager] ® (Windows 98SE only) If the camcorder is connected to the PC with the USB cable before installing [USB Mass Storage Class driver], the installation might not be performed properly. In this case, follow the procedure described below to update the [Device Manager] and install [USB Mass Storage Class driver] properly.
  • Page 71 Connections (Windows Connecting the USB cable Connect the USB cable to copy still image and video clip files in a memory card to the PC. To USB connector Camcorder To DV connector To assure safety, make sure all units are turned off before making any connections.
  • Page 72 Viewing the Contents of a Memory Card (Windows Install [USB Mass Storage Class driver]. (Windows pg. 5) Make sure that there is a memory card in the camcorder. Set the camcorder’s VIDEO/ MEMORY Switch to “MEMORY”. Set the camcorder’s Power Switch to “PLAY”...

  • Page 73: Copying Files To The Pc

    [NAVI]: Contains folders with navigation data The [NAVI] folder is displayed only when the camcorder is equipped with NAVIGATION function. NOTES: Saving the wrong kinds of files in a memory card or deleting files or folders from a memory card can cause problems with the operation of the camcorder.

  • Page 74: Playing Back Files On The Pc

    Playing Back Files on the PC ® (Windows Still images Use an application that can handle the JPEG file format. To view a still image, double-click the still image file (extension “.jpg”). Video clips (Only for the camcorder equipped with E-Mail Clip Recording function) Use the Windows Media™...
  • Page 75 ® When using Windows 2000/Me/XP Confirm that “ currently displayed on the LCD monitor of the camcorder. ● If “ ” is currently displayed, wait until it disappears before proceeding. Double- click the [Safely Remove Hardware] or [Unplug or Eject Hardware] icon in the status bar.
  • Page 76 Connections (Macintosh) Connect the USB cable to copy still image or video clip files in a memory card to the PC. Camcorder To assure safety, make sure all units are turned off before making any connections. Use the USB cable to connect the camcorder to the PC.
  • Page 77 The folders in the memory card appear. Navigation data Still images DPOF Setting data Different file types are stored in different folders. [DCIM]: Contains folders with still images (extension “.jpg”) [DCVI]: Contains folders with video clips (extension “.asf”) The [DCVI] folder is displayed only when the camcorder is equipped with E-Mail Clip Recording function.
  • Page 78 Playing Back Files on the PC (Macintosh) Still images Use an application that can handle the JPEG file format. To view a still image, either double-click the still image file (extension “.jpg”), or drag and drop the file on the application icon. Video clips (Only for the camcorder equipped with E-Mail Clip Recording function)
  • Page 79 Overview of Enjoying the Moving or Still Images on the PC Moving images SHOOT the moving images Cassette TRANSFER the moving images via the DV cable with PowerDirector 3 EDIT moving images with PowerDirector 3 CREATE the DVD or VCD with PowerProducer 2 Gold PLAYBACK the DVD or VCD...
  • Page 80 Printed in Japan EK/EX 0405MKH-AL-VP © 2005 Victor Company of Japan, Limited...
