SCHEMATIC DIAGRAMS

DIGITAL VIDEO CAMERA

YF098
2005
5
GR-X5US
CD-ROM No.SML200506
GR-X5US[M5D727]
For disassembling and assembling of MECHANISM ASSEMBLY, refer to the SERVICE MANUAL No.86700(MECHANISM ASSEMBLY).
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
No.YF098SCH
COPYRIGHT © 2005 Victor Company of Japan, Limited
2005/6

Advertisement

loading
Need help?

Need help?

Do you have a question about the GR-X5US and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for JVC GR-X5US

Summary of Contents for JVC GR-X5US

  • Page 1: Digital Video Camera

    SCHEMATIC DIAGRAMS DIGITAL VIDEO CAMERA YF098 2005 GR-X5US CD-ROM No.SML200506 GR-X5US[M5D727] For disassembling and assembling of MECHANISM ASSEMBLY, refer to the SERVICE MANUAL No.86700(MECHANISM ASSEMBLY). Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) No.YF098SCH...
  • Page 2 CHARTS AND DIAGRAMS 4. Voltage measurement NOTES OF SCHEMATIC DIAGRAM 1) Regulator (DC/DC CONV) circuits Safety precautions REC : Colour bar signal. The Components indentified by the symbol PB : Alignment tape (Colour bar). critical for safety. For continued safety, replace safety —...
  • Page 3 CIRCUIT BOARD NOTES 1. Foil and Component sides 1) Foil side (B side) : Parts on the foil side seen from foil face (pattern face) are indicated. 2) Component side (A side) : Parts on the component side seen from component face (parts face) indicated.
  • Page 4 BOARD INTERCONNECTION YTU94109-33 YTU94128A-4 YTU94129A-33 OP BLOCK INT MIC (Page2-29) CN109 CN102 CN101 REEL_VCC C_FG[+] T_REEL S_REEL C_FG[-] CAS_SW MDA_2.9V TAPE_LED C_COIL_W E_SENS C_COIL_W S_SENS C_COIL_U REC_SAFE C_COIL_U MIC1 MAIN C_COIL_V MIC2 C_COIL_V MIC3 HG_U[+] DRUM_PG HG_V[+] DRUM_FG HG_W[+] DRUM_REF HG_BS[+] L_FRB HG_BS[-]...
  • Page 5 SPEAKER PWR_LED (Page2-45) POWER ZOOM FPC EJECT/TRIG DIAL_PB DIAL_OFF DIAL_AUTO UNIT DIAL_MENU PHOTO SW (Page2-46) TRIG SW EJECT SW CN901 YTU94074-12 YTU94074-6 YTU94077-12 YTU94077-6 CN108 CN703 CN704 REG_3.1V REG_3.1V SDDAT2 SDDAT3 SDDAT0 SDDAT1 SDCD SDWP (Page2-43) SDCMD SDCLK nJRESET MOD0 ARMTDI nARMTRST ZOOM_SW...
  • Page 6 MAIN(MAIN IF) SCHEMATIC DIAGRAM TO EJECT/TRIG CN108 CN103 TO SYSCON TALLY STRB_ENV TO NUCORE GATE_PLS TO OP DRV STRB_SNS TO P.PRCS STRB_AD STRB_CHG KEY_C FCUS_PA FCUS_PB ADP_L T_BATT CHRG_EVR TO SYSCON I_MTR V_BATT RESET AREG_SO AREG_CLK REG_CS DRUM_ERR TO CN107 TO SYSCON D_GAIN R1201...
  • Page 7 TO SD CN105 MAIN(MAIN IF) TO SYSCON MONI_SW1 TO SYSCON MONI_SW2 TO SYSCON M_RVS TO JIG CONN CVF_R CN110 CVF_G TO CN110 CVF_B HD_M VCOM_M LCD_G TO V I/O LCD_R LCD_B LCD_3.1V LCD_3.1V TO CN103 REG_8.5V REG_8.5V HDCVF TO V I/O VDCVF TO SYSCON M_CS...
  • Page 8 MAIN(SYSCON) SCHEMATIC DIAGRAM TO MAIN IF(CN103) LIT_3V TO MULTI CONN(J103) REM_OUT IC1006 R1004 L1001 TO JIG CONN(CN110) AL_3VSYS 10µ RS5C314-X L1002 AL_3.1V 10µ TO MAIN IF(CN103) RTC_CS X1002 REG_3.1V AVREFOFF AREG_CLK NAX0564-001X C1042 Q1012 DTC143XE-X R1053 AREG_SO Xout Q1009 RTC_IN 2.2K INTR R1139...
  • Page 9 IC1002 MB90099PFV134EX IC1003 VIF_CLK SN74AHC1G00K-X SCLK OSD_HD OSD_CS OSD_VD VIF_OUT X1002 DATA NAX0564-001X OSD_RST R1043 BLKA BLKA TO V I/O C1040 C1037 BLKB BLKB 0.01 TEST TST0 R1045 VSS BLKC BLKC Q1010 DTC144EE-X DOT_CLK OSD_RST EEPRM_CS EEPRM_CS EEPRM_CK EEPRM_CK EEPRM_DI EEPRM_DI EEPRM_DO EEPRM_DO...
  • Page 10 MAIN(AUDIO) SCHEMATIC DIAGRAM MAIN(AUDIO) Q2401 2SC4617/RS/-X R2401 4.7k C2401 R2408 10/6.3 OPEN R2202 Q2201 560k DTC144EE-X TO EXT MIC J101 D2652 R2231 QNS0233-001 EMZ6.8N-X L2652 NQR0269-013X R2201 220k L2651 NQR0269-013X C2651 0.001 C2201 R2203 C2203 D2651 L2653 UDZS6.8B-X OPEN L2654 NQR0269-013X C2624 BEEP1...
  • Page 11 Q2403 2SC4617/RS/-X TO REG REG_4.8V L2401 10Ω R2402 4.7k REG_3.1V C2402 /6.3 C2404 R2403 /6.3 TO P.PRCS S_SHUT R2209 C2214 RIN1 C2210 R2207 ROUT1 R2208 C2213 LIN1 C2209 R2206 LOUT1 DVSS C2406 R2407 10/6.3 DVDD IC2201 AK4660VQ C2225 LRCK2 OPEN C2226 MCLK2 OPEN...
  • Page 12 MAIN(DVMAIN) SCHEMATIC DIAGRAM MAIN C3047 (DVMAIN) R3051 TL3002 TL3003 TL3004 TL3005 TL3006 MON0 MON1 TO REG VDDE REG_2.5V VDDI REG_1.8V MON2 REG_3.1V MON3 MON4 MON5 MON6 MON7 L3002 MON8 NQR0129-002X MON9 C3003 MON10 C3042 MON11 0.01 MON12 VDDE VDDI L3005 C3043 MON13 NQL402M-100X...
  • Page 13 R3068 OPEN CPUBUSTYPE CPUDSLOGIC R3069 CPUWAITLOGIC 0Ω TO SYSCON CPUWAIT XINT XINT XCPUCS DV_CS XCPURW XCPUDSTB1 XCPUDSTB0 TO V I/O CPUALE ANA_INV ANA_INH OUTV TL3010 TL3011 OUTH BRSI3 DCO3 BRSI2 DCO2 BRSI1 DCO1 BRSI0 DCO0 YSI3 DYO3 YSI2 DYO2 YSI1 DYO1 RA3001 YSI0...
  • Page 14 MAIN(V I/O) SCHEMATIC DIAGRAM MAIN(V I/O) TO NUCORE OUT_C0 OUT_C1 OUT_C2 OUT_C3 OUT_Y0 OUT_Y1 OUT_Y2 OUT_Y3 C3229 C3232 R3216 OPEN 0Ω 0.01 C3236 C3228 C3235 C3233 C3231 R3215 C3230 OPEN OPEN OPEN 0.01 OPEN 0Ω OPEN R3207 TO DVMAIN,NUCORE 0Ω DV2CKOUT C3237 C3227...
  • Page 15 L3701 10µ C3701 R3738 C3734 R3734 8.2k R3736 C3732 Q3733 0.001 C3739 EMZ1-W 0.01 R3733 L3731 IC3201 6.8µ R3735 JCP8075 1.8k CH # CH # C3735 C3733 Q3731 C3737 R3737 2SC5658/QRS/-X R3739 C3738 R3732 0.01 R3741 C3736 0.001 R3740 C3227 R3731 4.7k OPEN...
  • Page 16 MAIN(NUCORE) SCHEMATIC DIAGRAM R4081 R4061 TO SYSCON DSP_RSV GPIO7 R4048 GPIO26 0Ω TO P.PRCS SSGFLD GPIO28 GPIO25 GPIO27 R4076 CFWP nCFWE nCFWAIT CFRESET nCFREG CFRDY RA4005 nCFOE nCFIOWR nCFIORD CFCSEL CFD0 CFD1 CFD2 CFD3 CFD4 CFD5 CFD6 CFD7 CFD8 CFD9 CFD10 CFD11 CFD12...
  • Page 17 R4077 R4078 IC4004 MAIN R4050 SN74AHC1G04K-X R4051 (NUCORE) R4079 0Ω C4021 nMCS3 nMCS2 nMCS1 L4003 TO REG REG_2.5V L4001 NQR0129-002X REG_3.1V MVDD11 C4001 /6.3 MVDD10 C4007 MVDD9 MVDD8 MVDD7 C4008 MVDD6 MVDD5 MVDD4 C4009 MVDD3 MVDD2 L4002 MVDD1 NQR0129-002X VDD26 C4010 VDD25 C4002...
  • Page 18 MAIN(CDS) SCHEMATIC DIAGRAM MAIN(CDS) TO REG CAM_3.1V TO TG ADCLK PBLK TO P.PRCS,TG OBCPI TO TG TO CCD(CN201) CN101 QGB0507L1-40X L4201 NQR0006-001X C4205 A_GND H2_B C4204 H1_B SUB_B V2_B V4_B RG_G C4207 47/6.3 H2_G H1_G SUB_G R4206 0Ω -7.5V -7.5V V1_R C4206 V2_R...
  • Page 19 TO P.PRCS GIN0 ACHI0 GIN1 ACHI1 GIN2 ACHI2 GIN3 ACHI3 GIN4 ACHI4 GIN5 ACHI5 GIN6 ACHI6 GIN7 ACHI7 GIN8 ACHI8 GIN9 ACHI9 RIN0 BCHI0 RIN1 BCHI1 RIN2 BCHI2 RIN3 BCHI3 RIN4 BCHI4 RIN5 BCHI5 RIN6 BCHI6 RIN7 BCHI7 RIN8 BCHI8 RIN9 BCHI9 BIN0...
  • Page 20 MAIN(MEMORY) SCHEMATIC DIAGRAM MAIN(MEMORY) L4301 NQR0129-002X TO REG REG_2.5V REG_3.1V C4301 10/6.3 PMA1 PMA1 PMA2 PMA2 PMA3 PMA3 PMA4 PMA4 PMA5 PMA5 PMA6 TO NUCORE PMA6 P.PRCS PMA7 PMA7 PMA8 PMA8 PMA9 PMA9 PMA10 PMA10 PMA11 PMA11 PMA12 PMA12 PMA13 PMA13 PMA14 PMA14...
  • Page 21 TO NUCORE SDR_A0 SDR_A0 L4303 L4302 SDR_A1 NQR0129-002X SDR_A1 SDR_A2 SDR_A2 SDR_A3 SDR_A3 SDR_A4 SDR_A4 SDR_A5 C4326 SDR_A5 SDR_A6 10/6.3 SDR_A6 SDR_A7 SDR_A7 SDR_A8 SDR_A8 TL4302 SDR_A9 SDR_DQ0 SDR_DQ15 SDR_A9 DQ15 SDR_A10 SDR_A10 VDDQ VSSQ SDR_DQ0 SDR_DQ1 SDR_DQ14 SDR_DQ0 DQ14 SDR_DQ1 SDR_DQ2 SDR_DQ13...
  • Page 22 MAIN(P.PRCS) SCHEMATIC DIAGRAM TO REG REG_3.1V REG_1.8V VOUT C4501 L4501 C4502 /6.3 NQR0154-003X C4503 IC4503 C4504 R1160N151B-X C4505 TO AUDIO S_SHUT C4506 R4542 L4503 TO SYSCON,NUCORE AFE_RST C4575 0.01 TO TG HDTG HDTG VDTG VDTG TO CDS,TG OBCPI OBCPI R4677 0Ω...
  • Page 23 TO NUCORE PPRO0 DOUT0 PPRO1 DOUT1 PPRO2 DOUT2 PPRO3 DOUT3 PPRO4 DOUT4 PPRO5 DOUT5 PPRO6 DOUT6 PPRO7 DOUT7 PPRO8 DOUT8 PPRO9 DOUT9 PPRO10 DOUT10 L4503 PPRO11 DOUT11 V1CLK V1CLK V2CLK V2CLK VLD_PIX VPIX SSGFLD TO NUCORE ENCFLD TO V I/O OUTV2 OUTVX R4719...
  • Page 24 MAIN(OP DRV) SCHEMATIC DIAGRAM MAIN(OP DRV) REG SUB BOARD ASSY NQL38DK-100X L4801 10µ C4801 R4802 10/6.3 R4804 R4805 560k C4807 IC4851 IC4805 MM1614GN-X TAR5S31-X C4804 R4801 C4852 C4814 C4851 C4813 0.01 1µ 0.01 1µ NDHAL_LV TO P.PRCS HALL_AD ND_O/C IRIS_O/C TO NUCORE NDPWM IRIS_PWM...
  • Page 25 REG SUB BOARD ASSY R4820 100k R4804 C4814 C4815 R4805 C4812 R4822 560k C4809 R4813 R4821 R4819 C4807 C4808 C4811 0.01 R4816 100k DRIVE-ND R4807 R4817 R4818 R4808 R4809 R4823 100k C4810 DRIVE+ND R4824 TO OP BLOCK CN102 20348-033E-0 TL4903 ZOOM4 ZOOM4 ZOOM3...
  • Page 26 MAIN(TG) SCHEMATIC DIAGRAM MAIN(TG) L BOARD ASSY TO REG C5016 CAM_3.1V REG_-7.5 REG_15V C5031 C5030 C5032 C5029 10/20 47/10 L5005 10µ C5012 C5014 220/4 100/4 L5006 D5001 10 µ 1SS355-X C5017 C5027 1/35 TO CCD CN101 SHTC C5018 QGB0507L1-40X C5028 R5016 A_GND 100k...
  • Page 27 L BOARD ASSY TO CDS IC5002 OBCPI BH28FB1WHFV-W PBLK R5023 0Ω ADCLK L5002 R5024 NQR0129-002X 0Ω VOUT R5025 C5007 C5038 STBY C5006 C5037 VSS7 VDD3 C5005 VDD2 C5003 VDD1 VDD0 TO CDS,P.PRCS,OP DRV CAM_CLK CAM_OUT TG_CS HDTG XAHD TO P.PRCS IC5001 VDTG XAVD...
  • Page 28 MAIN(GYRO) SCHEMATIC DIAGRAM MAIN(GYRO) TO REG REG_3.1V L5801 10µ C5801 10/6.3 C5851 /6.3 TO MAIN IF(CN104) G_RST C5853 0.01 IC5852 NAL0031-002X NOTES: 1. For the destination of each signal and further line connections that are cut off from this diagram, refer to "BOARD INTERCONNECTIONS". 2.
  • Page 29 TO P.PRCS Y_GYAMP C5810 R5812 330p C5807 R5808 R5805 R5811 R5806 R5807 470k C5812 C5808 C5809 330p 4.7/6.3 y30320001a_rev0.1 IONS". (No.YF098)2-28...

  • Page 30: Ccd Schematic Diagram

    CCD SCHEMATIC DIAGRAM IC5501 IC5502 ICX475BL ICX475BL (B ch) (R ch) C5504 C5510 RCsub RCsub C5503 1 C5509 1 C5515 Vout Vout Q5504 Q5501 R5522 R5523 Q5502 Q5505 2SC4082/P/-X 2SC4082/P/-X R5504 C5511 C5506 C5505 C5512 2200p 2200p NOTES :1. For the destination of each signal and further line connectionsthat are cut off from this diagram, refer to "BOARD INTERCONNECTIONS". 2.
  • Page 31 TO CDS(CN101) IC5503 ICX475BL CN201 QGB0507M1-40X (G ch) RG_R SUB R H1_R H2_R V4_R V3_R V2_R V1_R -7.5V -7.5V C5516 SUB_G RCsub H1_G C5517 C5518 2200p H2_G C5515 Vout RG_G V4_B V2_B SUB_B Q5507 H1_B H2_B A_GND R5524 SIG_R Q5508 2SC4082/P/-X A_GND 15V_RG...

  • Page 32: Reg Schematic Diagram

    REG SCHEMATIC DIAGRAM BATTERY TERMINAL TP601 TP602 TP603 R6013 0Ω TP604 L6001 F6001 2.5A NMFZ007-2R5X-K C6052 J301 QNA0039-001 TL6052 TL6051 C6006 C6007 C6003 C6051 R6709 R6708 110k TL6002 TL6001 D6801 L6801 RB551V-30-X 47µ C6801 C6703 R6710 120k C6802 R6711 R6106 100k IN7- IN12-...
  • Page 33 TO MAIN IF (CN103) CN301 QGB0403L1 CAP_PWR CAP_PWR D6702 DRUM_PWR R6008 RB160M-30-X CAP_PWR DRUM_PWR CAP_PWR Q6702 Q6701 L6701 R6009 RTF020P02-X R6702 SSM3J14T-X 39µ DRUM_PWR CAP_PWR 0.25W DRUM_PWR NRV142F-R20X-K REG_8.5V Q6703 RTF020P02-X DRUM_PWR C6701 C6702 REG_8.5V REG_-7.5 D6701 REG_8.5V RB160M-30-X R6703 REG_-7.5 R6704 REG_2.5V...
  • Page 34 PRE/MDA(PRE/MDA IF) SCHEMATIC DIAGRAM CN401 TO MAIN IF(CN106) QGF0528F1-40X UNDER CONTACT PRE/MDA(PRE/MDA IF) TO LOADING MOTOR CN403 QGF0543F3-06X UPPER CONTACT DEW_SENS TO CN401 P/R_GND LOAD_FWD LOAD_FWD TO MDA LOAD_REV LOAD_REV PRE/MDA(PRE/MDA IF) CN404 CN407 QGF0538F1-11X QGF0532F2-06X UNDER CONTACT UNDER CONTACT TO R.ENCODER TO DRUM NOTES: 1.
  • Page 35 CN408 TO MAIN IF(CN107) QGF0528F1-40X UNDER CONTACT CN406 QGF0517F2-16X UPPER CONTACT TO SENSER CN405 QGF0538F1-18X UNDER CONTACT y20392001a_rev0.1 TO DRUM MOTOR TO CAPSTAN MOTOR IONS". (No.YF098)2-34...
  • Page 36 PRE/MDA(MDA) SCHEMATIC DIAGRAM DRUM_PG DRUM_FG DRUM_REF R1630 TL1612 TL1618 C_FRB TO CN408 CAP_FG TL1613 CAP_REF R1631 C1607 0.047 LD_ON TL1619 L_FRB TL1617 MDA_PS R1641 TL1606 TL1609 C1606 0.0015 R1604 100k D.PCV D.PFGIN+ D.COM D.PGIN- D.PGAMP R1614 D.PGSMT 0.33 D.RNF C.HW- C.HW+ C.HV- TO CN403...
  • Page 37 TL1601 TO CN408 DRUM_ERR DRUM_PWR R1639 D1604 DAP222-X C1632 TL1602 0.47 TO CN408 CAP_ERR NMFZ007-R20X-K CAP_PWR F1601 L1602 R1640 UNREG M_REG3V L1601 F1602 NQL382M-100X NMFZ007-R50X-K C1631 10/6.3 TL1606 TL1609 M_REG4.8 TO CN408 TL1620 C1606 0.0015 C1603 µ /6.3 R1604 100k TO CN405,406 MDA_2.9V C_FG[+]...
  • Page 38 PRE/MDA(PRE/REC) SCHEMATIC DIAGRAM PRE/MDA (PRE/REC) TO CN401 HID3 HID1 RECH MONI_CHG TL3501 C3531 R3513 TO CN401 Q3501 2SA1774/QRS/-X R3515 ENV_OUT ATFI C3532 C3533 0.01 C3517 C3527 OPEN OPEN C3518 0.01 C3519 0.001 TO CN401 DUMP_CTL C3520 ATF_GAIN 0.01 NOSIG_LV C3521 RECCADJ C3522 C3523...
  • Page 39 Q3501 SA1774/QRS/-X IC3501 JCY0132 R3507 TO HEAD CN402 GND[P/R_GND] R3506 GND[P/R_GND] GND[P/R_GND] R3505 GND[P/R_GND] R3504 y20382001a_rev0.1 IONS". (No.YF098)2-38...
  • Page 40 REAR(DECK OPE, GYRO) SCHEMATIC DIAGRAM REAR TO MAIN IF(CN104) <DECK OPE> CN501 MONI_SW1 QGF0309F1-53W MONI_SW2 SET_SW R501 R502 R503 3.3k 6.8k M_RVS KEY_A CVF_R CVF_G CVF_B HD_M VCOM_M LCD_G LCD_R S501 S502 S503 NSW0198-001X NSW0198-001X NSW0198-001X NSW0198 LCD_B LCD_3.1V TO CN501 REG_8.5V MENU D501...
  • Page 41 TO MONITOR(CN601) CN502 R503 QGA0503F1-20X VCOM_M TL501 M_RVS CVF_G HD_M S511 D503 NSW0150-001X LCD_G OPEN LCD_R LCD_B MONI_SW1 LCD_3.1V C501 S504 S505 REG_8.5V NSW0198-001X NSW0198-001X HDCVF TL502 VDCVF R508 M_CS 0Ω D502 UDZS4.3B-X AULCD_DO AULCD_CK CN503 D501 QGF0538F1-05X LCD_CTL ZS4.3B-X REG_4.8V TO U/D SW MONI_SW2...

  • Page 42: Monitor Schematic Diagram

    MONITOR SCHEMATIC DIAGRAM MONITOR R7607 R7608 L7601 C7608 100µ IC7603 C7609 JP7601 DN8797MS-X C7614 JP7602 PSIG PSIG JP7603 COM-M COMDC R7605 100k TL7604 COM_OUT C7610 COMREF TO REAR(CN502) C7611 CN601 QGA0503F1-20X TL7605 DA_OUT C7617 M_RVS CVF_G VCC1( 3V) C7616 HD_M LCD_G C7625 LCD_R...
  • Page 43 TO LCD(MONITOR) MODULE COM-M VCOM-M VST-M VST-M VCK-M VCK-M EN-M EN-M DWN-M DWN-M VDD_8.5V C7622 R7606 C7621 VST-M VSSG XSTB-M TL7606 D7601 XSTB-M UDZS5.6B-X VCK-M HST-M HST-M EN-M TEST DWN-M WIDE WIDE HCK2-M HCK2-M XSTB-M HCK1-M XSTB HCK1-M PSIG PSIG G_OUT-M G_OUT-M IC7601...

  • Page 44: Sd Schematic Diagram

    SD SCHEMATIC DIAGRAM TO SPEAKER CN704 QGA1001F1-02X SPK- TO CN701 SPK+ R721 0Ω TL701 TO MAIN CN701 QGF0309F1-25X TL702 R722 SPK- 0Ω TO CN704 SPK+ PHOTO_F TO CN703 PHOTO_H ZOOM_SW REG_3.1V SDDAT2 SDDAT3 SDCLK SDCMD SDCLK TO CN701 SDDAT0 SDCMD SDDAT1 SDWP SDCD...
  • Page 45 TO ZOOM CN703 QGF0543F1-06X ZOOM_SW TO CN701 PHOTO_F REG_3.1V TO CN701 PHOTO_H TO SD SOCKET R708 CN702 SD0DAT2 R709 SD0DAT3 R712 0Ω SD0CMD C703 VDD( DSC_3V) R713 0Ω SDCLK C702 OPEN VSS2/CD R710 SD0DAT0 R711 SD0DAT1 SD0CD SW_COM SD0WP D701 OPEN y30323001a_rev0.1 IONS".
  • Page 46 EJECT/TRIG SCHEMATIC DIAGRAM EJECT/TRIG TO POWER TO MAIN IF(CN106) OPE UNIT CN901 CN902 QGF0517F2-12X QGF0532F2-08X DIAL_MANU DIAL_MANU DIAL_AUTO DIAL_AUTO DIAL_OFF DIAL_OFF DIAL_PB DIAL_PB P_MEDIA TRIG_SW EJT_SW PWR_LED PWR_LED S901 S902 NSW0198-001X NSW0217-001X TRIG SW EJECT SW EJT_SW TRIG_SW S903 NSW0099-001X P_MEDIA R901 R902...
  • Page 47 POWER OPE UNIT, FOCUS UNIT, STROBE UNIT SCHEMATIC DIAGRAMS POWER OPE UNIT FOCUS UNIT TO REG(CN303) TO EJECT/TRIG (CN902) PWR_LED (EXPOSURE) KEYC_4 (PROGRAM AE) KEYC_3 (FOCUS) KEYC_2 DIAL_PB (SET) KEYC_1 DIAL_OFF FCUS_PA DIAL_AUTO FCUS_PB DIAL_MANU A PHASE B PHASE y21354001a_rev0.1 y20357001a_rev0.1 STROBE UNIT REG4.8V...

  • Page 48: Main Circuit Board

    MAIN CIRCUIT BOARD Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) <01>MAIN LYB10046-001B FOIL SIDE(B) C5037 R2401 R2408 L2402 C2403 IC5002 R1045 R1047 R2618 R2602 R2601 C2401 X5001 R2609 R2619 C2602 C2601 C2229 L5002 C2623 R2607...
  • Page 49 CAUTION : FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH SAME TYPE AND RATED FUSE(S). ATTENTION : POUR UNE PROTECTION PERMANENTE CONTRE LES RISQUE D'INCENDE, REMPLACER LES FUSIBLES PAR UNAAUTRE DE MEME TYPE ET DE MEME TENSION. COMPONENT SIDE(A) TL4503 TL4527 TL4520...
  • Page 50 CCD,REG,PRE/MDA,REAR CIRCUIT BOARDS Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) <02>CCD LYB10048-001B FOIL SIDE(B) COMPONENT SIDE( R5514 R5512 R5511 C5509 C5508 R5513 Q5504 C5510 CN201 <03>REG R6002 TL6051 LYB10049-001B R6010 IC6002 TL6005 R6305 R6009 R6304...
  • Page 51 CAUTION : FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH SAME TYPE AND RATED FUSE(S). ATTENTION : POUR UNE PROTECTION PERMANENTE CONTRE LES RISQUE D'INCENDE, REMPLACER LES FUSIBLES PAR UNAAUTRE DE MEME TYPE ET DE MEME TENSION. <04>PRE/MDA LYB10050-001B COMPONENT SIDE(A) R1636 D1603...
  • Page 52 MONITOR,SD,EJECT/TRIG CIRCUIT BOARDS Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade) <06>MONITOR LYB10050-001B COMPONENT SIDE(A) IC7604 CN601 C7608 C7609 R7608 TL7603 TL7602 C7614 C7607 TL7601 R7605 TL7604 C7610 L7604 C7611 TL7605 C7621 C7622 C7617 C7616 C7625...
  • Page 53 CAUTION : FOR CONTINUED PROTECTION AGAINST FIRE HAZARD, REPLACE ONLY WITH SAME TYPE AND RATED FUSE(S). ATTENTION : POUR UNE PROTECTION PERMANENTE CONTRE LES RISQUE D'INCENDE, REMPLACER LES FUSIBLES PAR UNAAUTRE DE MEME TYPE ET DE MEME TENSION. <07>SD LYB10050-001B COMPONENT SIDE(A) TL702 CN702...

  • Page 54: Power Block Diagram

    POWER BLOCK DIAGRAM NOTES: There are circuits or functions that are not used according to the models. Plea MAIN BATT_TERM CN301 CN103 T_BATT TP603 (T) ADP_L TP604 (-) V_BATT TP601 (+) SYSCON Q6703 LIT_3V F6001 IC1006 4.8V 77~81 REG_4.8V 77~81 Q6701 J301 DC JACK...
  • Page 55 models. Please check with the Parts List. CN101 CN201 REG-7.5 -7.5V REG_15V 15V_B IC5501 15V_RG 17 18 17 18 OP BLOCK IC5502 IC5001 IC5503 CAM_3.1V C1006 Q5502 2, Q1001 OP DRV 2, Q1003 7, Q1011 IC4801, IC4802 Q5505 REG_4.8V Q5508 IC4803, IC4804 IC4901 C1001...

  • Page 56: Video Block Diagram

    VIDEO BLOCK DIAGRAM NOTES: There are circuits or functions that are not used according to the models. Plea MAIN CN201 CN101 SIG_B SIG_B SIG_R SIG_R IC4201 SIG_G IC4241 SIG_G IC5501 IC4281 23,22 23,22 IC5502 H1_B, H2_B 38,37 38,37 ( RGB_ch IC5503 H1_R, H2_R OP BLOCK...
  • Page 57 models. Please check with the Parts List. REAR MONITOR CN104 CN501 CN502 CN601 CN602 LCD_R LCD_R R_OUT-M IC7601 Q3704,Q3705 LCD_G LCD_G G_OUT-M GREEN ( RGB SIGNAL ( BUF ) LCD_B LCD_B B_OUT-M BLUE PROCESS ) LCD MODULE (MONITOR) IC3201 J103 ( V I/O ) V_OUT IC3701...

  • Page 58: Voltage Charts

    VOLTAGE CHARTS <MAIN> <CCD> <REG> MODE MODE MODE MODE MODE MODE MODE MODE MODE PLAY PLAY PLAY PLAY PLAY PLAY PLAY PLAY PIN NO. PIN NO. PIN NO. PIN NO. PIN NO. PIN NO. PIN NO. PIN NO. PIN NO. IC1001 IC4302 IC5501...
  • Page 59 <PRE/MDA> <REAR> <MONITOR> MODE MODE MODE MODE PLAY PLAY PLAY PLAY PLAY N NO. PIN NO. PIN NO. PIN NO. PIN NO. 11.0 IC1601 IC511 IC7601 11.0 10.9 IC512 6501 11.0 11.0 6502 -15.2 IC513 -7.5 -7.6 -7.0 -7.2 -14.6 -14.9 -7.6 -7.7...
  • Page 60 Victor Company of Japan, Limited AV & MULTIMEDIA COMPANY CAMCORDER CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan (No.YF098) Printed in Japan...
