- Page 1 DLW5400-DLW5500 Digital Video Recorder Installation and Operations Manual Model Number: DLW5400-DLW5500 Description: Network Digital Video recorder H.264-Embedded Linux RTOS 8 and 16 Video, Audio, Looping...
- Page 2 Digital Video Recorder User Manual CAUTION Please read this user manual carefully to ensure that you can use the device correctly and safely This manual is suitable for 4-channel, 8-channel and 16-channel series DVR. In this book, we take 200FPS 8-channel DVR as a sample.
-
Page 3: Table Of Contents
Digital Video Recorder User Manual Table of Contents CHAPTER 1 Introduction ................................. 1 1.1 DVR Introduction ................................1 1.2 Main Features ..................................1 CHAPTER 2 Hardware Installation ............................4 2.1 Install Hard Drive &DVD Writer ............................4 ... - Page 4 Digital Video Recorder User Manual 4.1 Menu Navigation ................................47 4.2 Main Menu Setup................................48 4.2.1 Basic Configuration ......................................50 4.2.2 Live Configuration ......................................51 4.2.3 Record Configuration ....................................... 52 4.2.4 Schedule Configuration ....................................54 ...
- Page 5 Digital Video Recorder User Manual CHAPTER 7 Mobile Surveillance ............................93 7.1 By Phones with WinCE ..............................93 7.2 By Phones with Symbian ..............................96 7.3 The operation method for iPhone mobile clients ......................100 ...
-
Page 6: Chapter 1 Introduction
Digital Video Recorder User Manual Introduction CHAPTER 1 1.1 DVR Introduction This model DVR (Digital Video Recorder) is designed specially for CCTV system. It adopts high performance video processing chips and embedded Linux system. Meanwhile, it utilizes many most advanced technologies, such as standard H.264 with low bit rate, Dual stream, SATA interface, VGA output mouse supported, IE browser supported with full remote control, mobile view(by phones), etc., which ensure its powerful functions and high stability. - Page 7 Digital Video Recorder User Manual BACKUP • Support USB 2.0 devices to backup • Support built-in SATA DVD writer to backup • Support saving recorded files with AVI standard format to a remote computer through internet RECORD & PLAYBACK • Record modes: Manual, Schedule, Motion detection and Sensor alarm recording •...
- Page 8 Digital Video Recorder User Manual SECURITY • Two level user group management: advance and normal, rights authorized by administrator • Support 1 administrator and 15 users. • Support event log recording and checking, events unlimited NETWORK • Support TCP/IP, DHCP, PPPoE, DDNS protocol •...
- Page 9 HDD installation DLW5400-5500-5600-5700AL 1. Loosen the screws and open the top case. 2. Loosen the power and SATA cables.
-
Page 10: Main Features
3. If you have 3 or 4 HDD, please install HDD on the lower layer of the HDD stand as below first. Notice: It is not necessary to remove the top bracket. There are the related holes for screwdriver on the upper stand. 4. - Page 11 5. Then install other HDD on the upper layer as above. 6. Place the top cover back and tighten the screws. 7. Power on the unit. If it detect the HDD, it will show below information on the screen once entering the system.
- Page 12 8. Enter Menu---System---TOOLS---Disk manager. Choose the HDD one by one and click...
-
Page 13: Chapter 2 Hardware Installation
Digital Video Recorder User Manual Hardware Installation CHAPTER 2 Notice: Check the unit and the accessories after getting the DVR. Please disconnect the power before being connected to other devices. Do not hot plug in/out 2.1 Install Hard Drive &DVD Writer 2.1.1 Install Hard Drive Notice: 1. -
Page 14: Install Dvd Writer
Digital Video Recorder User Manual Fix the HDD firmly by screws, and then connect with data cables. STEP3 In addition, users can put hard-disk drive into the HDD box shown as Fig. 2.2 if they do not need install DVD writer. Fig. - Page 15 Digital Video Recorder User Manual Fig 2.3 Front Panel for 4-ch Item Name Function Digital keys Input digital number or select the number of camera Multi-screen button Change screen display like single, 4, 9 ,and 16 screens Enter button To confirm the choice or setup Direction Direction buttons.
- Page 16 Digital Video Recorder User Manual PLAY Enter play interface Rewind Fast forward To connect external USB devices like USB flash, USB HDD for backup or USB port update firmware STOP Quit playback mode Tab 2.1 Definition of Front Panel Buttons 2.
- Page 17 Digital Video Recorder User Manual INFO Check recording data AUTO/Dwell Dwell P.T.Z Enter PTZ mode BACKUP Enter backup mode MENU Enter menu Record manually SEARCH Enter search mode IR receiver For remote controller PLAY Enter play interface Rewind Fast forward To connect external USB devices like USB flash, USB HDD for backup or USB port update firmware...
-
Page 18: Rear Panel Instructions
Digital Video Recorder User Manual Item Name Function Digital keys Input digital number or select the number of camera Multi-screen button Change screen display like single, 4, 9 ,and 16 screens Enter button To confirm the choice or setup Direction Direction buttons. - Page 19 Digital Video Recorder User Manual Fig 2.6 Rear Panel for 4-channel DVR Item Name Description Connect to monitor as an AUX output channel by channel. Only video SPOT OUT display, no menu show VIDEO OUT Connect to monitor AUDIO IN Audio of channel from 1 to 4 VIDEO IN Video input channels from 1-4...
- Page 20 Digital Video Recorder User Manual Item Name Description ALARM OUT Relay output1-4. Connect to external alarm. +5V and GND +5V and grounding For cooling the device POWER INPUT Connect with power cable POWER SWITCH 220V or 110V Tab 2.4 Definition of Rear Interface 2.
- Page 21 Digital Video Recorder User Manual Item Name Description AUDIO OUT Audio output, connect to the sound box S-VIDEO S-Video output, connect to monitor PS/2 port Connect to PS/2 mouse USB MOUSE Only for USB mouse Connected to internet For debug VGA port VGA output, connect to monitor ALARM IN...
-
Page 22: Install Sensor &Alarm
Digital Video Recorder User Manual Item Name Description VIDEO OUT Connect to monitor VIDEO IN Video input channels from 1-16 E-SATA Connect to HDD for backup LOOP OUT For outputting each channel’s image independently Connect to monitor as an AUX output channel by channel. Only video SPOT OUT display, no menu show AUDIO IN... - Page 23 Digital Video Recorder User Manual For example, a sensor is connected with alarm input 1. If the sensor gives relay out (switch on/off), users need to set the sensor according to the switch status at alarm. If the switch is open at alarm, users need to set SENSOR TYPE to be NC (Normal Close).
-
Page 24: Remote Controller
Digital Video Recorder User Manual Users need connect their alarm according to the NO or NC type of the alarm. One connection example as Fig 2.11 Fig 2.11 Alarm Output Connection 2.4 Remote Controller It uses two AAA size batteries and works after loading batteries as following Open the battery cover of the Remote Controller STEP1 Place batteries. - Page 25 Digital Video Recorder User Manual The interface of remote controller is shown in Fig 2.12 Remote Controller. Fig 2.12 Remote Controller Item Name Function Power Button Soft switch off to stop firmware running. Do it before power off. INFOR Button Get information about the DVR like firmware version, HDD information REC Button To record manually...
-
Page 26: Control With Mouse
Digital Video Recorder User Manual Item Name Function +/- Button To increase or decrease the value in setup Playback Control Button To control playback, Fast forward/rewind/stop/single frame play AUDIO Button To enable audio output in live mode Auto Dwell Button To enter auto dwell mode BACKUP Button To enter backup mode... - Page 27 Digital Video Recorder User Manual Fig 2.13 Digital Numbers and Letters Input Window Users can change some value by the wheel, such as time. Move cursor onto the value, and roll the wheel when the value blinks. It supports mouse drag. I.e. Set motion detection area: click customized, hold left button and drag to set motion detection area.
-
Page 28: Chapter 3 Basic Function Instructions
Digital Video Recorder User Manual Basic Function Instructions CHAPTER 3 3.1 Power On/Off Notice: Before you power on the unit, please make sure all the connection is good. 3.1.1 Start There are two ways to start this DVR. One way is to Connect with the source power, switch on the power button near the power port in the rear panel, and the system will be loaded. - Page 29 Digital Video Recorder User Manual Fig 3.2 Preview...
- Page 30 Digital Video Recorder User Manual Symbol Meaning Symbol Meaning Enable audio in live Disable audio in live Manual record Timer record (green) (blue) Motion detection record Alarm record (yellow) (red) Current working HDD Space Size of current HDD Free Free space of current USB devices connected HDD full 3.1.2 Close...
-
Page 31: Login &User Management
Digital Video Recorder User Manual Choose OK to enter. The unit will power off automatically after a while STEP2 Disconnect the power STEP3 By front panel or mouse: Press ENTER button or click right mouse to show menu bar, referring to Fig 4.1 Control Bar. STEP1 Click Shut down button, referring to Fig 3.3 Shut down STEP2... - Page 32 Digital Video Recorder User Manual Notice: The default is admin and 123456. Change password: Every one can change his own password. In login state, click Log in/out on the control bar. A window will appear with two options. One is for logout, STEP1 another for password modification.
- Page 33 Digital Video Recorder User Manual Press right mouse to show the control bar. Enter Menu---->System. Enter USER configuration. Click Add button, please see Fig 3.6 Add User. STEP1 Fig 3.6 Add User Input user name and password. Choose the user group. STEP2 Click OK button to add a new user STEP3...
-
Page 34: Recording
Digital Video Recorder User Manual Click OK button to delete the user STEP6 Notice: illumination of users’ rights Administrator: have all rights to do every thing. Advance: do others except entering USER to manage users Normal: do others except entering SYSTEM to change the settings. The user name and password are the combination of digitals, letters, or symbols. -
Page 35: Manual Recording
Digital Video Recorder User Manual Fig 3.7 Record Setup Set Video quality, Frame rate, and Resolution. STEP2 Have Audio checked if you input audio and want to record. Check Time stamp to record STEP3 Enable recording function for cameras in Record option. STEP4 Notice: If having camera unchecked here, it will not record in any recording mode. -
Page 36: Timer Recording
Digital Video Recorder User Manual Or click REC button on the control bar with mouse, click again to stop. 3.3.3 Timer Recording Users can set different schedule time for every day in one week. If you want a special schedule for one day, you can use Holiday function. -
Page 37: Motion Detection Recording
Digital Video Recorder User Manual Fig 3.9 Calendar Select the date and set the schedule time. If want to delete this special schedule, click Delete button STEP4 Click OK button to finish STEP5 Then the DVR will auto record once it goes to the time you set. 3.3.4 Motion Detection Recording This unit supports recording channels and PTZ linking. - Page 38 Digital Video Recorder User Manual Fig 3.10 Motion Detection Setup Enable Detection first. Enter Area to set Sensitivity and detection Area. In detection area, red means unchecked, STEP2 transparence means available, see Fig 3.10 Motion Detection Area Setup. Due to the sensitivity is influenced by the color and time (day or night), users can adjust its value according to the practical condition.
- Page 39 Digital Video Recorder User Manual Fig 3.10 Motion Detection Area Setup Enter Trigger configuration, see Fig 3.11 Alarm Out Setup STEP3 Fig 3.11 Alarm Out Setup...
-
Page 40: Alarm Recording
Digital Video Recorder User Manual Select alarm out and recording channels. It can trigger any alarm out and cameras to record once motion STEP4 detected. Enable or disable Buzzer on board. Select speed dome and enable preset or auto cruise. Press OK to save STEP5 Set Hold time. -
Page 41: Playback
Digital Video Recorder User Manual Enable Detection first. Set Device type. STEP2 Enter Trigger configuration. Set alarm out, recording cameras and linked PTZ, referring to 3.3.4 Motion STEP3 Detection Recording STEP4-5 Set Alarm in hold time. It is the interval time between the two adjacent efficient alarms. This is similar with Hold STEP4 time in MOTION configuration. - Page 42 Digital Video Recorder User Manual Time search: Enter Search configuration, select Time search. A window will appear as Fig 3.14 Calendar Search. If it STEP1 recorded in a day, the date will show highlight. Fig 3.14 Calendar Search Choose a day to time search interface, as Fig 3.15 Time Search. STEP2...
- Page 43 Digital Video Recorder User Manual Fig 3.15 Time Search This unit has full and 4 screen playback. Select the screen display mode and the channels. STEP3 If want to change the date, press Date button. Set hour and minutes of start time. If it recorded at that time, the STEP4 boxes will show green.
- Page 44 Digital Video Recorder User Manual Fig 3.16 Playback Event search: Enter Search---->Event search. The calendar window will appear as that of time search STEP1...
-
Page 45: Backup &View
Digital Video Recorder User Manual Choose a day in event search interface, as Fig 3.17 Event Search STEP2 Fig 3.17 Event Search Choose camera and event type, motion or sensor. STEP3 Double click one video file to play. STEP4 3.5 Backup &View This unit supports backup by built-in SATA DVD Writer with USB Flash, through the USB port on the front panel. - Page 46 Digital Video Recorder User Manual Fig 3.18 Backup Setup Choose the channel, and set the start and end time. Click Date button to change the date. STEP2 Enable “Attach record player,” it will save a special player simultaneously when backup. With this player, users STEP3 can make time search and event search when checking the backup.
- Page 47 Digital Video Recorder User Manual Fig 3.19 Backup Information Notice: If users install built-in DVD writer and USB device, it will show USB device in previous. It will show CD-ROM even though users install DVD writer Press OK button. It will begin to write video from HDD inside DVR to backup device, and show the process as STEP5 below.
- Page 48 Digital Video Recorder User Manual Check &View: The steps to view the backup with the special software are as following: Remove the backup device to a computer. Enter the backup folder and open the viewer. STEP1...
- Page 49 Digital Video Recorder User Manual Fig 3.20 Backup Player ① Search area ② video display area ③ Video data area ④ Control area ⑤ AVI converting Click Browse to choose the folder which contains the video backup, as Fig 3.21 Choose Backup Folder. STEP2...
- Page 50 Digital Video Recorder User Manual Fig 3.21 Choose Backup Folder Set the date and channels. It will show the recorded video in area ③ with green light at the bottom as shown in STEP3 Fig 3.22 Backup Data Search. Fig 3.22 Backup Data Search If using event search, it will list event files at the bottom of area①...
- Page 51 Digital Video Recorder User Manual Fig 3.23 Play Backup Files Index Definition Index Definition Index Definition Index Definition Play Pause Stop Next frame ① ② ③ ④ Forward/Rewind Snap Volume Screen mode ⑤ ⑥ ⑦ ⑧ Tab 3.1 Backup View Control It supports AVI converter.
- Page 52 Digital Video Recorder User Manual Click Browse to choose the folder which contains the video backup first. Set the start/end time, select the STEP6 channels, and then Click search button. It will show backup files in the file display area as Fig 3.24 AVI Converter Fig 3.24 AVI Converter Select the files.
-
Page 53: Ptz Control
Digital Video Recorder User Manual 3.6 PTZ Control Please connect speed domes to the DVR via RS485 first, referring to 2.3.1 Rear Panel Interface. In addition, make sure the speed dome has the protocols this DVR supports and set the parameters according to its manual. Press right mouse to show the control bar. - Page 54 Digital Video Recorder User Manual Fig 3.26 Set Presets Click Set button at right of Cruise. Here users can set cruise track, as Fig 3.27 Set Cruise. Choose the preset, STEP4 set stay time of every preset. Click + button to add the preset to the left preset for cruise track. Fig 3.27 Set Cruise...
- Page 55 Digital Video Recorder User Manual Select a preset in left preset list, click – button to delete the preset. Click ↑,↓,↑,↓ to adjust the sequence of STEP5 the presets in the auto cruise. Click Save to save and return to the previous interface. Click button to save and exit.
-
Page 56: Menu Setup Guide
Digital Video Recorder User Manual Menu Setup Guide CHAPTER 4 4.1 Menu Navigation Menu Option Menu Option Device name &ID Camera name Video format Camera mask Language Basic Live Name &time switch Date &time setup SPOT out switch Live audio switch Color adjustment Authorization check switch Video quality... -
Page 57: Main Menu Setup
Digital Video Recorder User Manual Recorded cameras and PTZ linking Recorded cameras and PTZ linking HTTP &server ports Protocol, baud rate and address IP address setup Speed setup Network PPPoE Presets setup Network video setup Cruise setup DDNS Add users Disk manager User Delete users... - Page 58 Digital Video Recorder User Manual Fig 4.2 Up-listed Menu Select System. A graphic user interface will show as Fig 4.3 System Setup. Fig 4.3 System Setup...
-
Page 59: Basic Configuration
Digital Video Recorder User Manual Press MENU button on the front panel or remote controller. The interface above will also appear. Notice: Only administrator and advance user can enter system setup and do setup. It need reboot after some parameters changed, like video format. 4.2.1 Basic Configuration Click BASIC to enter basic configuration as Fig. -
Page 60: Live Configuration
Digital Video Recorder User Manual this. Audio: enable audio in live. Users can choose a random channel. Date format: three formats, YY-MM-DD, DD-MM-YY, MM-DD-YY. System time: set the time. If the unit is recording, users cannot change the time. When recording, click Adjust button, a security window will appear. -
Page 61: Record Configuration
Digital Video Recorder User Manual auto dwell and spot out. SPOT enable: enable spot output. Color: Click Set button, a window will appear as Fig 4.6 Color Adjustment. Fig 4.6 Color Adjustment Adjust Brightness, Hue, Saturation, and Contrast in live here. Default: set the color to the default value. - Page 62 Digital Video Recorder User Manual Fig 4.7 Record Configuration Here users can set record quality, frame rate, resolution, and recycle. The following are the definitions of every option. Video quality: it has five options from lowest to highest. The higher the value is, the clearer the recorded picture is. Frame rate: set recorded frame rate.
-
Page 63: Schedule Configuration
Digital Video Recorder User Manual 4.2.4 Schedule Configuration Click SCHEDULE to enter schedule configuration as Fig 4.8 Schedule Configuration. Fig 4.8 Schedule Configuration Here users can set schedule for timer, motion detection, and sensor alarm respectively. The following are the definitions of every option Always, Motion and Sensor: refer to record schedule, motion schedule and alarm schedule respectively. - Page 64 Digital Video Recorder User Manual Fig 4.9 Alarm Configuration Here users can set sensor type, alarm trigger and alarm time. The following are the definitions of every option. Device type: NC and NO (Normal Close and Normal Open). Set the value according to the alarm signal level of the sensors.
-
Page 65: Motion Configuration
Digital Video Recorder User Manual Fig 4.10 Alarm Out Configuration Alarm out: set relay alarm out channel. You can select any alarm channels. To record: set recording channels. You can select any record channels. It will record the cameras you choose here when alarm triggered. - Page 66 Digital Video Recorder User Manual Fig 4.11 Motion Configuration Here users can set motion sensitivity, detection area, and alarm out. The following are the definitions of every option. Enable: enable motion detection. Trigger: setup similar with that of sensor alarm. Nevertheless, linked speed domes must be different front current channel. I.e.
-
Page 67: Network Configuration
Digital Video Recorder User Manual Fig 4.12 Detection Area Configuration Sensitivity: set detection sensitivity from 1-8. The default is 4. Exit: quit without saving Holding time(S): the interval time between the two adjacent efficient motions, similar with that of sensor alarm. 4.2.7 Network Configuration Click NETWORK to enter network configuration as Fig 4.13 Network Configuration. - Page 68 Digital Video Recorder User Manual Fig 4.13 Network Configuration This unit supports DHCP, PPPoE, and DDNS. Users enable network function, and configure IP address, DDNS, transmission video parameters here. The following are the definitions of every option. HTTP port: the default is 80. If users change the value, they need add the port number when typing IP address in IE address blank.
- Page 69 Digital Video Recorder User Manual User name, Password: account information of PPPoE. Input what you get from your ISP. Click DDNS, a window will appear as Fig 4.14 DDNS Configuration. Now it supports DNS2P and 88IP. Users need register at www.dns2p.com or www.88IP.net.
-
Page 70: Configuration
Digital Video Recorder User Manual Fig 4.15 Network Video Configuration Video quality: network picture quality. Frame rate: it has 3 options, 1, 2 and 3 fps. Resolution: now it only has CIF. Time stamp: Time displayed in the image. 4.2.8 P.T.Z Configuration Click P.T.Z to enter PTZ configuration as Fig 4.16 PTZ Configuration. - Page 71 Digital Video Recorder User Manual Fig 4.16 PTZ Configuration Here users can set protocol, baud rate, address, presets, and auto cruise track here. The following are the definitions of every option. Protocol, Baud rate, Address: please set the value according to the settings of the speed dome. Speed: set the speed of speed domes.
-
Page 72: User Configuration
Digital Video Recorder User Manual Fig 4.17 Set Presets Cruise, Name: select a cruise track and rename it. Click Set in Cruise row. A window will appear as 3.6 PTZ Control. Notice: It has 128 presets and 32 cruise tracks totally 4.2.9 User Configuration Click USER to enter user management interface as Fig 4.18 User Configuration. -
Page 73: Tools Configuration
Digital Video Recorder User Manual Fig 4.18 User Configuration Administrator can add, delete users, and change their authorization. Please refer to 3.2 Login &User Management. Notice: It supports one administrator and max 15 users. 4.2.10 Tools Configuration Click TOOLS to enter tools configuration as Fig 4.19 Tools Manager. - Page 74 Digital Video Recorder User Manual Fig 4.19 Tools Manager Disk manager: please refer to 5.1 Format Hard Disk. Update: please refer to 5.2 Update Firmware. Load default: please refer to 5.3 Load Default Setup.
-
Page 75: Chapter 5 Manage Dvr
Digital Video Recorder User Manual CHAPTER 5 Manage DVR 5.1 Format Hard Disk If wanting to record, it is necessary to format the hard disk at first. If not being formatted, it will show the position of the disk, free space, and total space show 0M at the bottom of screen. Enter TOOLS configuration, referring to 4.2.10 Tools Configuration. -
Page 76: Update Firmware
Digital Video Recorder User Manual If a disk has never been formatted, Status will show “new”. Select hard disks, press Format button to begin. STEP2 A security window will remind user that this will delete all data on HDD. Press OK to continue. A process will STEP3 display on the screen as below. -
Page 77: Check System Information
Digital Video Recorder User Manual Fig 5.2 Reset Blocks Enter TOOLS configuration, referring to 4.2.10 Tools Configuration. STEP1 Click Load default. Select setup blocks; please refer to Fig 5.2 Reset Blocks. STEP2 Press OK to do default. It will return to TOOLS interface after finished. STEP3 5.4 Check System Information Users can check system information like firmware version, IP address, etc. - Page 78 Digital Video Recorder User Manual Fig 5.3 Status Interface Click System, the window below will display. Check firmware version, recording parameters here. STEP3 Fig 5.4 System Information. Return to the previous interface, and click Network. The window below will display. Check IP address, DVR Mac STEP4...
-
Page 79: Check System Log
Digital Video Recorder User Manual address, network video quality. Fig 5.5 Network Information. 5.5 Check System Log This unit supports system log. It records its working state and operation automatically. Moreover, it divides the record into two groups: events and operation. The form below is the details of the two groups. Group Details Events... - Page 80 Digital Video Recorder User Manual Fig 5.6 Events LOG Click Date to change date by a calendar. Click Type to select the event type. Then click Search button. It will STEP2 refresh the event list. Click ←, ←, →, → to do pgdn or pgup STEP3 Click right mouse to return to the previous interface.
-
Page 81: Check On-Line Network Users
Digital Video Recorder User Manual The operating is similar with searching events log. STEP5 Notice: The log files are saved to the HDD inside. If HDD not installed, it will not record any thing. The number of log files is unlimited. 5.6 Check On-line Network Users Press right mouse to show the control bar. - Page 82 Digital Video Recorder User Manual Fig 5.9 File Manager Click Date to change date by a calendar, click Search to refresh the list. The files found will be listed in the file STEP3 area of file manager at bottom. It show the details of every file, like start/end time, lock state. Select the files and click Lock, it will lock the selected files.
-
Page 83: Chapter 6 Remote Surveillance
Digital Video Recorder User Manual CHAPTER 6 Remote Surveillance 6.1 Accessing DVR If making remote view, the DVR must connect with LAN or internet. Then enable network server in the unit. Please refer to 4.2.7 Network Configuration. This unit supports IE browser, not any client software installed. In addition, it supports XP and Vista. 6.1.1 On LAN Input IP address, Subnet, Gateway. -
Page 84: On Wan
Digital Video Recorder User Manual Fig 6.1 View with IE browser Notice: If HTTP port is not 80, other number instead, need add the port number after IP address. For example, set HTTP port as 82, need input IP address like 192.168.0.25:82. User name and password here are the same with that used on the DVR. -
Page 85: Remote Preview
Digital Video Recorder User Manual Enter Video to set network video parameters like resolution, frame rate etc. STEP2 Forward IP address and port number in Virtual Server setup of the router or virtual server. Close firewall. STEP3 Notice: Forwarding block may be different in different routers and server, please check your router manual. If users want to utilize dynamic domain name, need apply for a domain name in a DNS server supported by the STEP4 DVR or router. - Page 86 Digital Video Recorder User Manual Fig 6.2 Remote Preview Interface ① Full screen, 1/4/8 screens display mode. ② Camera indicators: ③ Picture snapshot...
- Page 87 Digital Video Recorder User Manual ④ Remote preview: adjust the color of cameras and control PTZ. ⑤ Remote playback and backup: make remote playback and backup, check system log and journal. Please refer to 6.3 Remote Playback &Backup. ⑥ Remote menu setup: set the parameters remotely. Please refer to 6.4 Remote Menu Configuration. ④, ⑤, and ⑥...
- Page 88 Digital Video Recorder User Manual window will pop up. Click Exit to return to live preview interface. STEP5 Color adjustment: Click on a channel to choose. Drag the slide bar to adjust Brightness, Contrast, Hue, and Saturation. Click Default to reset them to original value.
- Page 89 Digital Video Recorder User Manual Fig 6.4 Remote PTZ control ① Move the speed dome. ② Stop adjustment. ③ Adjust zoom, focus, Iris, Speed. ④ Go to the preset. Click to rename the preset. ⑤ Select and do auto cruise.
- Page 90 Digital Video Recorder User Manual Click right mouse, a pull-down menu will appear as below. Fig 6.5 Preview Control Menu Full screen: the picture will fill the screen, without tools bar display. Double click or click right mouse to return to the previous interface.
-
Page 91: Remote Playback &Backup
Digital Video Recorder User Manual simultaneously. Therefore, users can select the stream according to their bandwidth. Refresh: update the picture on the channel. Sometimes the picture on one channel will freeze due to network block. At this time, users can refresh the pictures. 6.3 Remote Playback &Backup 6.3.1 Remote Playback Click Search to enter the playback and backup block as below, where users can make remote playback, remote backup... - Page 92 Digital Video Recorder User Manual Fig 6.7Remote Playback &Backup Interface This DVR supports remote time search, event search and one channel playback. The above is the default interface after entering Playback &Backup block. By time search: Select the date in calendar area①, select the channel in channel area②. STEP1 Click Search button to update the search result.
- Page 93 Digital Video Recorder User Manual to a time point. Click right mouse on of the slide bar. It will zoom in 10 times, which is helpful for users to point the start time of playback accurately. Click Play button to do remote playback, referring to Fig 6.8 Remote Playback. STEP4 Fig 6.8 Remote Playback Users can make fast forward/backward, pause, stop playback and snap pictures.
-
Page 94: Remote Backup
Digital Video Recorder User Manual By event search: Click Event search, the window will display as below. STEP1 Fig 6.9 Remote Event Search Select the date, channel and event type. Then click Search. All the files found will be listed in left area. STEP2 Select a event, and click Play button to do remote playback. - Page 95 Digital Video Recorder User Manual Fig 6.10 Remote Backup Interface Select the date, channel. Then click Search button. It will list all the files recorded in the day in left area. STEP1 Click Browse button. Set the saving path. STEP2 Select files in left file area.
-
Page 96: Remote Menu Configuration
Digital Video Recorder User Manual Notice: the backup file is AVI format. Users can play with the third player directly. 6.4 Remote Menu Configuration Except network parameters, users can set all the parameters like resolution, schedule remotely through network, not going to the DVR. - Page 97 Digital Video Recorder User Manual Fig 6.11 Remote Menu Setup The sub menu lists and the options in every sub menu are similar with those on the DVR. Please refer to 4.2 Main Menu Setup to do setup. Click Save to save the change. Some changes may pop up a dialog box as below and need restart.
-
Page 98: Remote Dvr Management
Digital Video Recorder User Manual 6.5 Remote DVR Management 6.5.1 Check System Log Remotely Users can check system log remotely. About the details of system log, please refer to Tab 5.1 Details of System Log. Click Search---->Log, the window below will appear. Event log search is the default interface. STEP1... - Page 99 Digital Video Recorder User Manual Fig 6.12 Remote System LOG Search Select the date, channel and event type. Then click Search. STEP2 The entire log found will be listed in left area. STEP3 Click Operation to enter operation Log search interface STEP4...
-
Page 100: Lock &Delete Files Remotely
Digital Video Recorder User Manual Fig 6.13 Remote Operation Log Search Select the date and click Search. It will list all the log files in the day in left area. STEP5 6.5.2 Lock &Delete Files Remotely Users can lock and delete video files through network. About the details of this feature please refer to 5.7 Lock &Delete Files. - Page 101 Digital Video Recorder User Manual Fig 6.14 Remote File manager Select date and channels, and then click Search. All the files found will be listed in the day in left area. STEP2 The relative status will show “Lock” if the file is locked. “Writing” means the file is still in being written. STEP3 Select the files which is unlocked, click Delete.
-
Page 102: Chapter 7 Mobile Surveillance
Digital Video Recorder User Manual Mobile Surveillance CHAPTER 7 This DVR supports mobile surveillance by PDA or smart phones with WinCE and symbian OS. At the same time, it supports 3G network. We tested Dopod D600 (WM5) and Dopod S1(WM6), which work fine with the DVR. It wants to make mobile surveillance, need first enable network service on the DVR, referring to 4.2.7 Network Configuration. - Page 103 Digital Video Recorder User Manual Click on the software name. A dialog box pops up. STEP3 Click “Yes” to download and install. STEP4...
- Page 104 Digital Video Recorder User Manual PCam will be opened after installed. STEP5 Input the server’s address, ID, and password respectively in the columns of “Server”, “User” and “Password”. STEP6 And click “Go” to login the DVR. It will show the picture if accessing successfully.
-
Page 105: By Phones With Symbian
Digital Video Recorder User Manual Camera 1 is the default display after login. Change the camera in rolling-down menu of “Channel”. STEP7 Notice: User name and password here are the same with that used on the DVR. The default is admin and 123456. 7.2 By Phones with Symbian Please use the smart phones with symbian version supported by this unit. - Page 106 Digital Video Recorder User Manual Firstly, enable the network access on mobile phone, and then run Web browser. STEP1 Input the DVR server’s IP address in a new-built bookmark. Click this bookmark to connect to the DVR. STEP2 A welcome window will pop up and requires a package. Click “install package” to download. STEP3 The security windows will pop up after downloading and ask if installing the package.
- Page 107 Digital Video Recorder User Manual A Scam shortcut icon appears on the system menu after finish. STEP5 Run Scam program. STEP6...
- Page 108 Digital Video Recorder User Manual Click Options--->Settings to enter login interface. STEP7 Input the server’s address, ID and password respectively. And click OK to login the DVR. STEP8...
-
Page 109: The Operation Method For Iphone Mobile Clients
Digital Video Recorder User Manual It will show the camera after access successfully. STEP9 Notice: User name and password here are the same with that used on the DVR. The default is admin and 123456. 7.3 The operation method for iPhone mobile clients At present, the software only supports version of iPhone os2.2 and above, if phone firmware lower than this version please upgrade it. - Page 110 Digital Video Recorder User Manual Step 2: Enable “search” function to search “SuperCam”, the required programs will be displayed on the top of search box Step 3: Click SuperCam, enter into “introduce” interface and click FREE”, it will change into “INSTALL”...
- Page 111 Digital Video Recorder User Manual Step 4: Enter into iTunes Store password, click “OK”will display below interface Note: if it was the first time for user to operate please enter into user ID; if there is no Store account, user need to apply one.
- Page 112 Digital Video Recorder User Manual Step 5: Just be patient to download and install. After installed, SuperCam icon will display. Click this icon, a function interface will appear...
- Page 113 Digital Video Recorder User Manual Step 6: Click “System setting”, enter into login interface. Enter into server’s IP address (or domain name), user’s ID and password. Click Back to save. Step 7: Click Live View, the default Cam1 picture will be displayed. Click to capture picture.
- Page 114 Digital Video Recorder User Manual Step 8: On function interface, click Image View to view the captured picture. Click to switch to next or previous picture. Click to delete the current picture. Iphone help...
- Page 115 Digital Video Recorder User Manual Pic1 Pic2 Pic3 Pic4 Live View After successfully installed SuperCam software, Click on System Setting (Pic 1), and then input Server IP address or Domain, User name and password to log in (Pic 2). If connected successfully, it will go to Live View of CH1 as default (Pic 3), please choose other desired channels from channel button underneath.
- Page 116 Digital Video Recorder User Manual : Zoom Zoom in Zoom out : Focus. Long Focus Short Focus : IRIS Lighter Darker : return to live Image View Pic 5 Pic 6 : Previous picture : Next Picture : The first Picture : The last picture : Delete : Search Pictures, search page as Pic 6...
-
Page 117: Appendix Afaq
Digital Video Recorder User Manual Appendix A Q1. Why the DVR cannot start after connected to the power? a. The adapter has been damaged. Please change an adapter b. The power of the adapter is not enough. Please remove the HDD to check c. - Page 118 Digital Video Recorder User Manual Q5. Cannot record a. Don't format HDD. Please format it manually first. b. Don't enable record function or incorrect setup. Please refer to 3.3 Recording. c. HDD is full and not enables recycle function. Please refer to 4.2.3 Record Configuration. Chang a new HDD or enable recycle.
- Page 119 Digital Video Recorder User Manual ② select Security------Custom Level….Refer to Fig 7-1 ③ Enable all the sub options under “ActiveX controls and plug-ins”. Refer to Fig 7-2 Fig7-1 Fig7-2 ④ Then click ok to finish setup. b. Other plug-ins or anti-virus block activeX. Please uninstall or close them. Q8: How to deal with when DVR starts, it displays “please wait…”all the time First possible reason: hard-disk cable and data cable are not well connected.
- Page 120 Digital Video Recorder User Manual disk cannot skip Solution: Change another new hard disk or reformat the broken one Q9: The mouse inserting into the front USB jack does not work Hereby the front USB jack is only for backup of U disk, USB DVD writer etc., and not support USB mouse. Please use the USB jack in the rear panel if using mouse to operate.
- Page 121 Digital Video Recorder User Manual same type, they will be identified to be two or more new hard disks, and all of them need to format. In general, please do not try using more disks removed from different DVRs into another one DVR in case the data lose. Q13: What is the minimum configuration of PC for clients connecting? PC Module Parameters...
-
Page 122: Appendix B Calculation Of Recording Capacity
Digital Video Recorder User Manual Appendix B Calculation of Recording Capacity Users can calculate the size of hard disk according to the saving time and DVR recording settings. The DVR uses fixed video bit rate. The below are the details at different settings for 200 fps 8-channel DVR. Farm Rate Totally Bit Rate Used Space... - Page 123 Digital Video Recorder User Manual = 648(GB) Therefore, customers just install two SATA HDDs with 320GB, it can almost record for one month. For 4-channel DVR: Total Recoding capacity =112.5(mb/h) X 24(hours/day) X30(days) X4(channels) = 324000(MB) = 324(GB) If users install one 320GB SATA HDD, it can almost record one month. For 16-channel DVR: Total Recoding capacity =112.5(mb/h) X 24(hours/day) X30(days) X16(channels) = 1296000(MB)
-
Page 124: Appendix C Compatible Devices
Digital Video Recorder User Manual Appendix C Compatible Devices Compatible USB drive after test Brand Capacity 512MB, 1G, 2GB Netac Kingston Aigo Smatter vider SanDisk Tab C.1 Compatible USB drive Compatible SATA CD/DVD writers after test Brand Model TECLAST GH22NP20/TL-22XD BENQ DW220S-0K4 LITEON... -
Page 125: Appendix Ddvr Specifications For 8-Channel Dvr
Digital Video Recorder User Manual Appendix D DVR Specifications for 8-channel DVR Compression format Standard H.264 Baseline Video output Composite：1.0V p-p/75Ω，BNC×2 S-VIDEOX1, VGAX1 Video input Composite：1.0V p-p/75Ω，BNC×8 Display Resolution 720*576 (PAL), 720*480 (NTSC) Record Resolution 352*288 , 704*576 (PAL), 352*240 , 704*480 (NTSC) Display Frame Rate 200FPS (PAL), 240FPS (NTSC) -
Page 126: Appendix Edvr Specifications For 4-Channel Dvr
Digital Video Recorder User Manual Appendix E DVR Specifications for 4-channel DVR Compression format Standard H.264 Baseline Video output Composite：1.0V p-p/75Ω，BNC×2 S-VIDEOX1, VGAX1 Video input Composite：1.0V p-p/75Ω，BNC×4 Display Resolution 720*576 (PAL), 720*480 (NTSC) Record Resolution 352*288 , 704*576 (PAL), 352*240 , 704*480 (NTSC) Display Frame Rate 100FPS (PAL), 120FPS (NTSC) -
Page 127: Appendix Fdvr Specifications For 16-Channel Dvr
Digital Video Recorder User Manual Appendix F DVR Specifications for 16-channel DVR Compression format Standard H.264 Baseline Video output Composite：1.0V p-p/75Ω，BNC×2 S-VIDEOX1, VGAX1 Video input Composite：1.0V p-p/75Ω，BNC×16 Display Resolution 720*576 (PAL), 720*480 (NTSC) Record Resolution 352*288 , 704*576 (PAL), 352*240 , 704*480 (NTSC) Display Frame Rate 400FPS (PAL), 480FPS (NTSC)
