    THANK YOU FOR BUYING A RYOBI ROTARY HAMMER DRILL Your new rotary hammer drill has been engineered and manufactured to Ryobi’s high standard of dependability, ease of operation and operator safety. Properly cared for, it will give you years of rugged, trouble free performance. If you use your rotary hammer drill properly and only for what it is intended, you will enjoy years of safe, reliable service.

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS The purpose of safety rules is to attract your WARNING attention to possible dangers. The safety symbols Do not attempt to operate this tool and the explanations with them, require your until you have read thoroughly and careful attention and understanding.

  • Page 4: Vibration And Noise Reduction

    IMPORTANT SAFETY INSTRUCTIONS DO NOT let children come into contact with the ALWAYS ensure that the auxiliary handle is firmly tool. Supervision is required when inexperienced affixed and secured. operators use this tool. The auxiliary and main handle must be firmly held This product is not intended for use by persons to resist any movement of the product when the (including children) suffering from diminished...

  • Page 5: Electrical Safety

    IMPORTANT SAFETY INSTRUCTIONS Switch off and disconnect from the power supply if cables measuring up to 25m must be at least 1.5 there are malfunctions. Have the product checked , and 2.5 mm for cables longer than 25m. by a qualified professional and repaired, if Always roll the whole cable off the reel before use.

  • Page 6: Personal Safety

    IMPORTANT SAFETY INSTRUCTIONS b) Avoid body contact with earthed or grounded g) If devices are provided for the connection of surfaces such as pipes, radiators, ranges and dust extraction and collection facilities, ensure refrigerators. There is an increased risk of these are connected and properly used.
  • Page 7 DESCRIPTION 1. Locking collar 9. Hammer/Drill function selector 2. Depth stop 10. Variable speed dial 3. Depth stop fastening wing screw 11. Power cable 4. Function selector 12. SDS point chisel bit 5. Function selector safety lock 13. SDS flat chisel bit 6.

  • Page 8: Packing Contents

    UNPACKING CAUTION. This packaging contains If any parts are found to be missing, the machine sharp objects. Take care when and its accessories should be returned together in unpacking. Remove the machine, their original packaging to the retailer. Do not throw together with the accessories supplied, from the the packaging away, keep it safe throughout the packaging.

  • Page 9: Auxiliary Handle

    ASSEMBLY USING A CHUCK ADAPTOR (NOT INCLUDED) FOR WOOD AND METAL DRILL BITS WARNING. Do not use a keyed drill chuck for hammer drilling or chiselling applications! It is intended exclusively for drilling with drill bits for wood and metal. INSERTING Note: A keyed drill chuck adaptor allows normal bits (non SDS type) to be used with the product.

  • Page 10: Operation

    OPERATION WARNING. Do not allow familiarity with products to make you careless. Remember that a careless fraction of a second is sufficient to inflict injury. WARNING. Always wear eye protection with side shields marked to comply with ANSI Z87.1. Failure to do so could result in objects being thrown into your eyes, resulting in possible serious injury.

  • Page 11: General Operation

    OPERATION NOTE: Hammer drilling mode will damage the tool’s mechanism when used for fastening or drilling by non-SDS Plus bits. Select the rotary mode only on such purpose. When hammer drilling, use only bits with hard metal and SDS shaft only. The use of commercially available masonry bits with cylindrical shaft by means of the drill adaptor is impossible.

  • Page 12: Masonry Drilling

    OPERATION WARNING. Be prepared for binding at • Bend or burn bits; and bit breakthrough. When these situations • Produce off-center or irregular-shaped holes. occur, drill has a tendency to grab and kick opposite to the direction of rotation When drilling large holes in metal, start with a small and could cause loss of control when bit, then finish with a larger bit.

  • Page 13: Maintenance

    Now that you have purchased your tool, should a need ever exist of repair or service, simply contact your nearest Ryobi Authorised Service Centre or other qualified service organisation. Be sure to provide all pertinent facts when you call or visit.
  • Page 14 SYMBOLS SYMBOL SIGNAL MEANING DANGER: Indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury. WARNING Indicates a potentially hazardous situation, which, if not avoided, could result in death or serious injury. CAUTION Indicates a potentially hazardous situation, which, if not avoided, may result in minor or moderate injury.
