Summary of Contents for LG RZ-13LA60
- Page 1 LCD TV SERVICE MANUAL CHASSIS : ML-024C MODEL : RZ-13LA60 CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. Jul., 2003 P/NO : 3828VD0131W Printed in Korea...
-
Page 2: Table Of Contents
CONTENTS CONTENTS ....................2 PRODUCT SAFETY ..................3 DESCRIPTION OF CONTROLS .............. 4 ADJUSTMENT INSTRUCTION ..............7 TROUBLE SHOOTING ................12 BLOCK DIAGRAM...................13 PRINTED CIRCUIT BOARD ..............14 EXPLODED VIEW .................. 18 EXPLODED VIEW PARTS LIST ..............19 REPLACEMENT PARTS LIST ............... 20 SVC. Sheet ....................- 2 -... -
Page 3: Product Safety
No deviations are 6. Do not remove a replacement ES device from its protective package until allowed without prior approval by LG Electronis Inc. Service work should be immediately before you are ready to install it. (Most replacement ES devices... -
Page 4: Description Of Controls
DESCRIPTION OF CONTROLS All the functions can be controlled with the remote control handset. Some functions can also be adjusted with the buttons on the side panel of the set. Remote control handset Before you use the remote control handset, please install the bat- MUTE POWER teries. - Page 5 9. POWER switches the set on from standby or off to standby. 10. I/II selects the language during dual language broadcast. selects the sound output (option). 11. MENU MUTE POWER selects a menu. 12. PSM (Picture Status Memory) TV/AV I/II recalls your preferred picture setting.
- Page 6 Side panel S-VIDEO VIDEO (MONO) AUDIO Back panel 7. POWER/STANDBY INDICATOR (r r ) 1. ON/OFF ( illuminates red in standby mode. switches the set on from standby or off to illuminates green when the set is switched on. standby. Note : Power line lives even when the power 8.
-
Page 7: Adjustment Instruction
ADJUSTMENT INSTRUCTION (3) The set must be operated for 15 minutes preliminarily 1. Application Object before adjustment if there is no specific designation. This instruction is for the application to the LCD TV. [ ‘Heat Run’ must be performed with the full white signal or TV noise signal in the internal part of the set. - Page 8 OPTION OPTION TEXT I/II SV SCART A2 ST TEXT I/II SV SCART A2 ST 200PR 200PR Data Data - 8 -...
- Page 9 OPTION OPTION TEXT I/II SV SCART A2 ST TEXT I/II SV SCART A2 ST 200PR 200PR Data Data - 9 -...
- Page 10 OPTION TEXT I/II SV SCART A2 ST 200PR Data 4. Option2 data(ACMS~BBACK:1bit,LANG:3bit) OPTION OPTION ACMS BBACK LANG ACMS BBACK LANG Data Data - 10 -...
- Page 11 5. Option3 data(IIC AFT~CH+AU:1bit) OPTION HiDEV IIC T MONO CH+AUS Data - 11 -...
-
Page 12: Trouble Shooting
TROUBLE SHOOTING 1. General Features Symptom Cause Check Point No screen P1 and Pin 40 connector 1) Check and fix P1 connector being slipped out 2) Check and repair IC710 Cracked components and 1)Check and repair tuner and main board soldering at tuner board 2)Solder Q403 Dark screen... -
Page 13: Block Diagram
BLOCK DIAGRAM - 13 -... -
Page 14: Printed Circuit Board
PRINTED CIRCUIT BOARD MAIN(TOP) - 14 -... - Page 15 MAIN(BOTTOM) - 15 -...
- Page 16 CONTROL POWER - 16 -...
- Page 17 MEMO - 17 -...
-
Page 18: Exploded View
EXPLODED VIEW - 18 -... -
Page 19: Exploded View Parts List
EXPLODED VIEW PARTS LIST PART NO. DESCRIPTION 6306V13001A LCD MODULE,LC130V01-A2 LG PHILPS TFT COLOR VG 6400VA0017A SPEAKER,GENERAL T401SX-095K14 8 OHM 1.0/1.5W 81DB 40X28.5X13.1MM 4950V00170A METAL,HOLDER SECC(EGI) . 3091V00493D CABINET ASSEMBLY,RZ-13LA60.APBLKX STEREO ML024C NON 5020V00778B BUTTON,CONTROL RU-13LA60 ABS, HF-380 8KEY . -
Page 20: Replacement Parts List
REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION Q407 0TR387500AA TR, CHIP 2SC3875S(ALY) KEC TR, CHIP 2SC3875S(ALY) KEC Q501 0TR387500AA IC100 0ISM555000B IC, SDA555XFL 52DIP ST FLASH MEMORY Q502 0TR150400BA TR, CHIP 2SA1504S(ASY) KEC IC101 0IAL241610B IC, AT24C16A-10PI-2.7 8PIN DIP ST EEPROM NON TR, KTC5103D KEC R/TP D-PAK 60V 5A... - Page 21 For Capacitor & Resistors, the CC, CX, CK, CN : Ceramic RD : Carbon Film charactors at 2nd and 3rd digit CQ : Polyestor RS : Metal Oxide Film in the P/No. means as follows; CE : Electrolytic RN : Metal Film RF : Fusible LOCA.
- Page 22 SWITCH, TACT 2LEAD 100G(TA) 5V 0.001A 3828VA0435R MANUAL,OWNERS RUS/BZ03 LG RU/EN 091G SW1102 140-313A SWITCH, TACT 2LEAD 100G(TA) 5V 0.001A 3828VD0131W MANUAL,SERVICE ML024C RZ-13LA60 LG EN SW1103 140-313A SWITCH, TACT 2LEAD 100G(TA) 5V 0.001A 6710V00091G REMOTE CONTROLLER ML012B FULL SW1104 140-313A SWITCH, TACT 2LEAD 100G(TA) 5V 0.001A...
- Page 23 JACK ASSY,PMJ014F E/P(ST)+S-VHS+3P H6.5 SC204 381-091B JACK,SCARTS-091B UGCOM SCART 21P W/O BOSS TH701 163-048D THERMISTOR,KL15L2R5 +/- 15% 125V TU401 6700PF0002A TUNER,TAFH-S321D LG PAL FS 4SYS VA701 164-003K VARISTORSVC621D-14A ILJIN 620V 0% Z100 156-A01L RESONATOR,CRYSTAL 6.000MHZ 30PPM 16PF BK Z500 156-A02X RESONATOR,CRYSTAL 27.000MHZ 25PPM 20PF BK...
- Page 24 P/NO:3854VA0127A-S1 2003.06.29...
-
Page 25: Svc. Sheet
SVC. SHEET : 3854V A0127A-S1...
