thank you
has been involved in every aspect of musical and film recording
and reproduction, from live performances to monitoring the
recordings you play in your home, car or office.
We're confident that the JBL system you have chosen will provide
every note of enjoyment that you expected – and that when you
think about purchasing additional audio equipment for your home,
car or office, you will once again choose JBL.
Please take a moment to complete the enclosed profile card.
It enables us to keep you posted on our latest advancements,
and helps us to better understand our customers and build
products that meet their needs and expectations.
JBL Consumer Products
for choosing JBL. For more than 50 years, JBL
TLX Movies
simple
setup guide
Advertisement
Related Manuals for JBL TLX MOVIES
Summary of Contents for JBL TLX MOVIES
-
Page 1: Setup Guide
We’re confident that the JBL system you have chosen will provide every note of enjoyment that you expected – and that when you think about purchasing additional audio equipment for your home, car or office, you will once again choose JBL. -
Page 2: Speaker Placement
included Two surround speakers. one. Speaker Placement Center 0-2 ft. Mounting Options Center On TV. One center speaker. Surrounds Surrounds On shelves. 5 – 6 ft. On wall. The customer is responsible for proper selection and use of mounting hardware, available through hardware stores, to properly and safely wall-mount the speakers. -
Page 3: Speaker Connections
two. Speaker Connections Connection Tips Separate and strip the ends of the speaker wire as shown. Speakers and electronics ter- minals have corresponding (+) and (–) terminals. It is impor- tant to connect both speakers Left Surround Surround – identically: (+) on the speaker to (+) on the amplifier and (–) on the speaker to (–) on the amplifier. -
Page 4: Troubleshooting
Troubleshooting If there is no sound from the surround speakers, check the following: • Check all wires and con- nections between receiver/ amplifier and speakers. Make sure all wires are connected. Make sure none of the speaker wires are frayed, cut or punctured. -
Page 5: Specifications
JBL continually strives to improve its products. New materials, production methods and design refinements are introduced into existing models without notice as a rou- tine expression of our design philosophy. For this reason, JBL loudspeakers may differ in some respect from their published specifications and descriptions, but will always equal or exceed the original specifications unless otherwise stated. - Page 6 250 Crossways Park Drive, Woodbury, NY 11 797 8500 Balboa Boulevard, Northridge, CA 91329 1-800-336-4JBL (4525) (USA only) © 1998 JBL, Incorporated. JBL is a registered trademark of JBL, Incorporated. *Trademark of Dolby Laboratories. Part No. TLXMOVIESOM A Harman International Company...
