- Page 1 CPB-435CNH INSTALLATION INSTRUCTION 2P-0068 CONVERSION TRACK SYSTEM Case IH 8000 and 9000 Series Combines & New Holland 8000 and 9000 Series Combines (without Speed Multiplier)
-
Page 2: Important Safety Information
The specifications, torques, pressures, measurements, adjustments, illustrations, and other items can change at any time. These changes can affect the service that is given to the product. Obtain the complete and most current information before you start any job. Camso dealers have the most current information available. -
Page 3: Installation Notes
WARNING Installation of CTS systems onto any machine requires special adapters that must be obtained from Camso for proper installation. Failure to heed this warning can lead to premature failures, product damage, personal injury or death. 2.0 Special Tools Required for Installation •... - Page 4 4.1 Case IH 8000 and 9000 Series Combines Fitment Kit To properly install the CTS track system to a Case IH 7000, 8000, or 9000 Series Combine, the following component list will be necessary. These components are included in Camso Sales Kit Part Number 2K- 0070.
- Page 5 4.2 New Holland 8000 and 9000 CR Series Combines Fitment Kit To properly install the CTS track system to a New Holland CR or CX Series Combine, the following component list will be necessary. These components are included in Camso Sales Kit Part Number 2K- 0070.
- Page 6 To prevent possible machine and/or undercarriage damage and additional downtime, it is required that the oscillation limiters be installed. The oscillation limiters are there to reduce the possibility of the CTS track over oscillating. The table below lists the parts that are included in the oscillation limiter kit which is included in the fitment kit for your specific combine.
- Page 7 To prevent possible machine and/or undercarriage damage and additional downtime, it is required that the oscillation limiters be installed. The oscillation limiters are there to reduce the possibility of the CTS track over oscillating. The table below lists the parts that are included in the oscillation limiter kit which is included in the fitment kit for your specific combine.
-
Page 8: Track System Installation
If lifting the track system by placing the forks in the spokes of the drivewheel, use caution to prevent damage to the drivewheel and tensioning system (hydraulic accumulator). CPB-435CNH Case and New Holland Combines (without speed multiplier) Camso | 04-17 | 8... - Page 9 4. Remove the bolts from the locations below from the combine final drive to install the oscillation limiter. Rear View of axle Front View of axle CPB-435CNH Case and New Holland Combines (without speed multiplier) Camso | 04-17 | 9...
- Page 10 NOTE: Bracket will point to the rear of the machine. 5. Install secondary oscillation bracket. Torque the 20 mm bolts to 500 ft-lbs (675 Nm) and 16 mm bolts to 250 ft-lbs (345 Nm). CPB-435CNH Case and New Holland Combines (without speed multiplier) Camso | 04-17 | 10...
- Page 11 6. Install oscillation stop bracket onto the CTS track frame (if not already installed). Install the bracket to CTS frame to the rear of the drive wheel. Install oscillation stop bracket using 4 M20 bolts and 4 M20 lock washers.
- Page 12 • NOTE: Additional parts will need to be purchased from Camso in order to install the CTS in this manner. CPB-435CNH Case and New Holland Combines (without speed multiplier)
- Page 13 220 ft-lbs (300 Nm). Coat threads of the bolt with engine oil prior to installing. NOTE: A 32 mm socket is provided with the fitment kit. This socket is necessary for the socket to fit onto the head of the bolt and clear the CTS frame. Additional sockets are available for purchase from Camso.
- Page 14 It is important to follow the installation instructions and to use a calibrated torque wrench to ensure bolts are properly torqued. Failure to do so may result in the CTS mounting bolts coming loose and the bolts breaking resulting in downtime and possible damage to the combine and CTS.
- Page 15 Be careful: risk of injury. 20. Remove the bolts from the locations below from the combine final drive to install the oscillation limiter. CPB-435CNH Case and New Holland Combines (without speed multiplier) Camso | 04-17 | 15...
- Page 16 22. Install oscillation stop bracket onto the CTS track frame (if not already installed). Install the bracket to CTS frame to the rear of the drive wheel. Install oscillation stop bracket using 4 M20 bolts and 4 M20 lock washers.
- Page 17 Install spacer plate onto the axle hub. NOTE: The wheel studs are not used when mounting the CTS to the combine axle. Only the thru bolts from the CTS drivewheel and threading directly into the axle housing are used. These bolts are supplied with the fitment kit.
- Page 18 • NOTE: Additional parts will need to be purchased from Camso in order to install the CTS in this manner. WARNING Should a motorized lifting device be used, assistance on ground during operation of handling, coupling and assembly is needed.
- Page 19 220 ft-lbs (300 Nm). Coat threads of the bolt with engine oil prior to installing. NOTE: A 32 mm socket is provided with the fitment kit. This socket is necessary for the socket to fit onto the head of the bolt and clear the CTS frame. Additional sockets are available for purchase from Camso.
- Page 20 It is important to follow the installation instructions and to use a calibrated torque wrench to ensure bolts are properly torqued. Failure to do so may result in the CTS mounting bolts coming loose and the bolts breaking resulting in downtime and possible damage to the combine and CTS.
