Owner's Manual
Rev. 1.2
AEONS SP Series Wall-Mounted Enclosure
Models: 6U, 9U, 12U, 15U, 18U, 22U
Applied to Model Series: SPxx06, SPxx09, SPxx12, SPxx15, SPxx18, SPxx22
1644 N Maple Street, Corona, CA 92880
www.aeonstech.com/support
Copyright © 2020 Aeons LLC. All rights reserved.
aeonstech.com
support@aeonstech.com
*actual product may vary from picture
Advertisement
Related Manuals for AEONS Technologies SP Series
Summary of Contents for AEONS Technologies SP Series
- Page 1 Owner’s Manual support@aeonstech.com Rev. 1.2 AEONS SP Series Wall-Mounted Enclosure Models: 6U, 9U, 12U, 15U, 18U, 22U Applied to Model Series: SPxx06, SPxx09, SPxx12, SPxx15, SPxx18, SPxx22 *actual product may vary from picture 1644 N Maple Street, Corona, CA 92880 www.aeonstech.com/support...
-
Page 2: Important Safety Instructions
Important Safety Instructions This manual contains instructions and warnings that must be followed during the installation and operation of the product. Failure to comply may invalidate the warranty and cause property damage or personal injury. Keep the enclosure in a controlled indoor environment, away from moisture, temperature extremes, flammable liquids and gasses, conductive contaminants, dust, and direct sunlight. -
Page 3: Parts Identification
Parts Identification Top Panel Cable Access Cover Hanger Bar Back Panel L Mounting Bracket Side Panels Frames Vertical Mounting Rails Bottom Panel 10. Front Door 11. Accessories Accessories List Assembly Hardware Kits: M5 self-tapping screw - 8pcs M8*12 Inner Hexagon Screw - 16pcs Lock kit - 1pcs M8 Flange Nut - 16pcs White Plastic Washer - 1pcs... -
Page 4: Assembly Steps
Assembly Steps Step 1 : Install Bottom Panel and Frames Lay down Bottom Panel (#9) on a flat surface. Insert Left and Right Frames (#7) with large flange oriented to the inside. Ensure that the slots in the center of the frames are facing inward as shown in the detailed view. - Page 5 Step 2 : Install Top Panel and Frames Place the Top Panel (#1) on a flat surface. Turn the assembly over and insert it into the top panel. Ensure that the Top and Bottom Panels (#1 and #9) are oriented in the same direction. Secure with 8x M8 Hexagon Screws and 8x M8 Flange Nuts from bottom, and 2x M4 self-tapping screws from front.
- Page 6 Step 3 : Install Vertical Mounting Rails Install the 4 Vertical Rack Rails (#8) to the horizontal rails at the desired depth using the M5 self-tapping screws provided. When determining the appropriate depth, make sure consider the equipment that you plan to mount inside the enclosure, and the rail depth is the same on both sides of the cabinet.
- Page 7 Step 5 : Install Side Panel Install the two Side Panels (#6) into place using the Side Panel Latches. Once each Side Panel (#6) is attached, test to ensure that each Side Panel Lock locks properly. Step 6 : Install Front Door Lock Install the Front Door Lock to the Front Door (#10) as shown in the left picture.
- Page 8 Step 7 : Install Front Door To attach the Front Door (#10) to the cabinet, locate the side with two pins. Insert the bottom fixed pin with White Plastic Washer into the door hinge hole. With your thumb, pull down on the top spring pin and slide it into place over the second door hinge hole and release.
- Page 9 Step 8 : Install Back Panel Attach the Back Panel (#4) to the cabinet using 6x M4 Self-tapping Screws. Step 9 : Install Hanger Bar Attach the Hanger Bar (#3) to a wall or other suitable mounting surface using 4 appropriate anchors. NOTE: Make sure the mounting hooks are facing outwards.
- Page 10 Step 10: Mount the Enclosure Fit the cabinet’s 2 mounting notches onto the 2 mounting hooks on the hanger bar. The enclosure should slide down onto the hooks until secure. After the cabinet hung properly, secure the cabinet to the hanger bar using 2 M4 Screws from inside of cabinet to the holes on the mounting hooks as shown.
- Page 11 Step 11 : Install Casters (Optional and only available for 15U, 18U and 22U versions) Attach Casters using 16x M6 Self Tapping Screws to Bottom Panel (#9).
- Page 12 Technical Support Thank you for purchasing the Aeons product. We intends this manual to guide you through a smooth installation. Aeons assumes that you are qualified in the servicing of IT equipment and trained in recognizing any hazards that may occur in the installation of this product. Our lifetime technical support is an integral part of our commitment to provide industry-leading solutions.
