Owner's Manual
Rev. 2.2
www.aeonstech.com
support@aeonstech.com
Signature Series Wall-Mounted Enclosure
Applied to Model Series: SAxx06, SAxx09, SAxx12, SAxx15, SAxx18, SAxx22,
Important Safety Instructions
This manual contains instructions and warnings that must be followed during the installation and operation of the product
described in this manual. Failure to comply may invalidate the warranty and cause property damage or personal injury.
Keep the enclosure in a controlled indoor environment, away from moisture, temperature extremes, flammable liquids and gasses, conductive
contaminants, dust, and direct sunlight. Leave adequate space at the front and rear of the enclosure for proper ventilation. Do not block, cover
or insert objects into the external ventilation openings of the enclosure.
The enclosure is extremely heavy. Use caution when handling the enclosure. Do not attempt to unpack, move or install it unassisted. Use a
mechanical device such as a forklift or pallet jack to move the enclosure in the shipping container. Inspect the shipping container and the
enclosure for shipping damage. Do not use the enclosure if it is damaged. Leave the enclosure in the shipping container until it has been moved
as close to the final installation location as possible.
Use caution when cutting packing materials. The enclosure may be scratched, causing damage not covered by the warranty. Save all packing
materials for later use. Repacking and shipping the enclosure without the original packing materials may cause product damage that will void the
warranty.
Install the enclosure in a structurally sound area capable of handling the load, or on a level floor that is able to bear the weight of the enclosure,
all equipment that will be installed in the enclosure and any other enclosures and/or equipment that will be installed nearby. For permanent
wall mounting, be sure to securely fasten the enclosure to the building structure before operation. Do not place any object on the enclosure,
especially containers of liquid, and do not attempt to stack the enclosures.
Overview
Thank you for purchasing the AEONS enclosure product.
The AEONS signature series enclosures accommodate all standard 19-inch rackmount equipment. They feature premier quality, heavy-duty
cabinets in various U sizes for quick and easy deployment.
Our enclosures include quick-release doors and side panels for convenient maintenance. Front access doors are reversible for installation
flexibility. Front door and side panels are lockable. An optional rolling caster kit (optional for 15U-22U) is available for easy maneuvering of
enclosures.
Models: 6U, 9U, 12U, 15U, 18U, 22U
Advertisement
Table of Contents
Related Manuals for AEONS Technologies Signature Series
Summary of Contents for AEONS Technologies Signature Series
- Page 1 Overview Thank you for purchasing the AEONS enclosure product. The AEONS signature series enclosures accommodate all standard 19-inch rackmount equipment. They feature premier quality, heavy-duty cabinets in various U sizes for quick and easy deployment. Our enclosures include quick-release doors and side panels for convenient maintenance. Front access doors are reversible for installation flexibility.
- Page 2 Parts Identification 1. Top Panel 2. Bottom Panel 3. Frames 4. Front Door 5. Side Panels 6. Horizontal Mounting Rails 7. L Mounting Bracket 8. Back Panel 9. Hanger Bar 10. Vertical Mounting Rails 11. Cable Access Cover 12. Accessories Accessories List M8*12 Inner Hexagon Screw - 16pcs M4*8 Self-tapping Screw - 12pcs...
- Page 3 Assembly Steps Step 1: Install Bottom Panel and Frames Lay down Bottom Panel (#2) on a flat surface. insert Front and Rear Frames (#3) with large flange oriented to the inside. Ensure that the slots in the center of the frames are facing inward as shown in the detailed view.
- Page 4 Step 3: Install Vertical Mounting Rails Install the 4 Vertical Rack Rails (#10) to the horizontal rails (#6) at the desired depth using the Cage Nut Kit provided. When determining the appropriate depth, make sure to consider the equipment that you plan to mount inside the enclosure, and the rail depth is the same on both sides of the cabinet.
- Page 5 Step 5: Install Side Panel Install the two Side Panels (#5) into place using plot the Side Panel Latches. Once each Side Panel (#5) is attached, test to ensure that each Side Panel Lock locks properly. Step 6: Install Front Door Lock Install the Front Door Lock to the Front Door (#4) as shown in the left picture.
- Page 6 Step 7: Install Front Door To attach the Front Door (#4) to the cabinet, locate the side with two pins. Insert the bottom fixed pin with White Plastic Washer into the door hinge hole. With your thumb, pull down on the top spring pin and slide it into place over the second door hinge hole and release.
- Page 7 Step 9: Install Hanger Bar Attach the Hanger Bar (#9) to a wall or other suitable mounting surface using 4 appropriate anchors. NOTE: Make sure the mounting hooks are facing outwards. Step 10: Mount the Enclosure Fit the cabinet’s 2 mounting notches onto the 2 mounting hooks on the hanger bar.
- Page 8 Step 11: Install Casters (Optional and only available for 15U, 18U and 22U versions) Attach Casters using 16x M6 Self Tapping Screws to Bottom Panel (#2). Technical Support Thank you for purchasing the Aeons product. We intends this manual to guide you through a smooth installation. Aeons assumes that you are qualified in the servicing of IT equipment and trained in recognizing any hazards that may occur in the installation of this product.
