- Page 1 MONO POWER AMPLIFIER DI550.4-DI600.1 DI550.4-DI600.1 mono power amplifier and 4 channel power amplifier User Manual...
- Page 2 MONO POWER AMPLIFIER DI550.4-DI600.1 FRONT PANEL DI550.4 DI600.1 AIN CONTROL INPUT LEVEL (PRE IN/SPK IN) HPF CONTROL FULL/HPF/LPF SELECTOR SWITCH FREQ CONTROL BASS BOOST FREQ CONTROL BASS BOOST CONTROL INPUT The amplifier supports Highl Low level signal input. If your audio source device does not have RCA output interface, you can use Soundmagus HTL series signal adaptor.
- Page 3 MONO POWER AMPLIFIER DI550.4-DI600.1 REAR PANEL Used to connect power amplifier grounding cable. The power supply ground- ing cable need to be firmly connected to the frame of the vehicle or other places with good conductivity. Please use the cable with same specifications as the power supply cable and connect to frame of the vehicle near the installation position of the power amplifier.
- Page 4 MONO POWER AMPLIFIER DI550.4-DI600.1 +12V Used to connect the positive terminal 12V car battery. In order to ensure ade- quate power supply for the amplifier, special cable should be used to connect directly to the positive pole of the battery, and the fuse should be connected in series within 20 centimeters from the positive pole of the battery.
- Page 5 MONO POWER AMPLIFIER DI550.4-DI600.1 SPEAKERS CONNECTIONS DI550.4...
- Page 6 MONO POWER AMPLIFIER DI550.4-DI600.1 MONO AMPL IFIER WIRING DI6000.1...
- Page 7 2 Ohm Bass Boost L evel 0dB-6dB-1 2dB Supply Voltage 7. 5V~16V DC Optional Remote Dimensions (mm) 165X150X46 DI550.4 4-Channel power amplifier Input Sensitivity PRE INPUT: 0.35~3.5V / SPK INPUT : 0.7~7V100W X 2 Freq. Response 10Hz~30KHz Distortion <0.3% S/N Ratio >...
- Page 8 MONO POWER AMPLIFIER DI550.4-DI600.1 Poor Sound Quality ( Distortions ): The speakers are overloaded, therefore turn down the volume level and check the volume control positions. No Stereo Sound And A Weak Bass: Speaker cables (+) and (-) are mixed up, unit wired out of phase.
