ARM
-based 32-bit Cortex
ADC, 7 communication interfaces
Feature
 Core: ARM®32-bit Cortex®-M4F CPU
− 120 MHz maximum frequency, with a
Memory Protection Unit (MPU), single-cycle
multiplication and hardware division
− DSP instructions
 Memories
− 16 to 64 KBytes of internal Flash memory
− 4 Kbytes of boot code area used as a
Bootloader or as a general instruction/data
memory (one-time-configured)
− sLib: configurable part of main Flash set as a
library area with code executable but
secured, non-readable
− 8 to 16 KBytes of SRAM
 Clock, reset and power control
− 2.4 V ~ 3.6 V application suppy and I/Os
− Power-on reset (POR)/ low-voltage reset
(LVR), and power voltage monitor (PVM)
− 4 to 25 MHz crystal (HEXT)
− Internal 8 MHz factory-trimmed clock (HICK),
accuracy 1% at T
+105 °C
− Internal 40 kHz RC oscillator
− 32 kHz crystal oscillator (LEXT)
 Low power
− Sleep, Deepsleep, and Standby modes
 1 x 12-bit A/D converter (up to 15 input
channels)
− Conversion range: 0 V to 3.6 V
 1 x COMP, 5 x external input channels
and 1 x internal reference voltage
channel
 DMA: 5-channel DMA controller
− Peripherals supported: timers, ADC, I
SPI, I
2
C and USART
 Debug mode
− Serial wire debug (SWD) and JTAG
 Up to 39 fast GPIOs
− All mapable to external interrupt vectors
− Almost 5 V-tolerant
2021.11.17
®
-M4 MCU with 16 to 64 KB Flash, sLib, 10 timers,
=25 °C, 2 % at T
=-40 to
A
A
2
S,
AT32F421 Series Reference Manual
− All fast I/Os, registers accessible with f
 Up to 10 Timers (TMR)
− 1 x 16-bit 7-channel advanced timer, 6-channel
PWM outout with dead-time generator and
emergency stop
− 5 x 16-bit timers, each with 4 IC/OC/PWM or
pulse counter and encoder input
− 1 x 16-bit basic timer
− 2 x Watchdog timers (WDT and WWDT)
− SysTick timer: 24-bit downcounter
 ERTC: enhanced RTC
 Up to 7 communication interfaces
− 2 x I
2
C interfaces (SMBus/PMBus support)
− 2 x USARTs/UART (ISO7816 interface, LIN,
IrDA and modem control)
− 2 x SPIs, both with I
− Infrared transmitter
 CRC Calculation Unit
 96-bit ID (UID)
 Packaging
− LQFP48 7 x 7 mm
− LQFP32 7 x 7 mm
− QFN32 5 x 5 mm
− QFN32 4 x 4 mm
− QFN28 4 x 4 mm
− TSSOP20 6.5 x 4.4 mm
 List of Models
Internal Flash
AT32F421C8T7, AT32F421K8T7
64 KBytes
AT32F421K8U7, AT32F421K8U7-4
AT32F421F8P7, AT32F421G8U7
AT32F421C6T7, AT32F421K6T7
32 KBytes
AT32F421K6U7, AT32F421K6U7-4
AT32F421F6P7, AT32F421G6U7
AT32F421C4T7, AT32F421K4T7
16 KBytes
AT32F421K4U7, AT32F421K4U7-4
AT32F421F4P7, AT32F421G4U7
Page 1
speed
AHB
2
S interface multiplexed
Model
Ver 2.00
