STEWART-AMOS Starfire S-4XL Operation And Maintenance Manual

Table of Contents

Advertisement

Quick Links

Starfire S-4XL Sweeper Body
Safety, Operations and Maintenance
Manual
Sweeper Co.
SN 6008 & UP
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Starfire S-4XL and is the answer not in the manual?

Questions and answers

Summary of Contents for STEWART-AMOS Starfire S-4XL

  • Page 1 Starfire S-4XL Sweeper Body Safety, Operations and Maintenance Manual Sweeper Co. SN 6008 & UP...
  • Page 2 Sweeper Co. Starfire S-4XL Sweeper Body Safety, Operations and Maintenance Manual Sweeper Co. SN 6008 & UP Last Update January 2015...
  • Page 3 Sweeper Co. Last Update January 2015...
  • Page 4: Table Of Contents

    Sweeper Co. Table of Contents Safety Safety Is A Shared Responsibility Recognize Safety Information Equipment Lockout Hopper Port Restrictors General Safety Precautions Before Operating Machine When Operation Machine When Servicing Machine Safety Features Follow Safety Instructions Prevent Bypass Starting Handle Fuel Safely-Avoid Fires Prepare For Emergencies Never Use Starting Fluid Wear Protective Clothing...
  • Page 5 Sweeper Co. General Specifications Serial Number Location Figure 1: Serial Number Plate Controls Engine Controls Figure 2: Engine Control Box Sweeper Controls LH Gutter Broom tilt Up/Down Beacon Lights On RH Gutter Broom Tilt Up/Down Brooms Up/Down GB Lights On/GB/MB Lights On Sweep Forward/Sweep Reverse Hopper Up/Down Water...
  • Page 6 Sweeper Co. Operation Chassis Auxiliary Engine Water Fill Up Figure 4: Water Tank Sweeping Dumping Break-In Period Engine Break-In Sweeper Break-In Winterizing Your S-4 Service Fuel, Lubricants, and Coolants Diesel Fuel Diesel Engine Oil Coolant Hydraulic Oil Grease Lubrication and Maintenance Daily Figure 5: Service Locations on Auxiliary Engine Every 40 Hours...
  • Page 7 Sweeper Co. Repair and Maintenance Maintenance Filter Cross Reference Gutter Broom Segment Replacement Main Broom Strip Replacement Figure 10: Main Broom Assembly Main Broom Bearing Replacement Figure 11: Main Broom Arm Assembly Carbide Drag Shoe Replacement Figure 12: Carbide Drag Shoe Elevator Chain Replacement Figure 13: Elevator Bottom Liner Replacement...
  • Page 8: Safety

    Sweeper Co. Safety Last Update January 2015...
  • Page 9 Sweeper Co. Last Update January 2015...
  • Page 10: Safety Is A Shared Responsibility

    Sweeper Co. Safety is always of prime importance when operating any type of machine or vehicle in the vicinity of people. All persons working with this unit are to be knowledgeable of the safety practices and features detailed in this section. Safety Is a Shared Responsibility Safety is everyone’s responsibility.
  • Page 11: Equipment Lockout

    Sweeper Co. Equipment Lockout It is strongly recommended that a commonly known Equipment Lockout procedure be enforced at your work environment. This is a series of precautions designed to protect any personnel that is inspecting, cleaning, or repairing the equipment. The Lockout Procedure should include the following.
  • Page 12: General Safety Precautions

    Sweeper Co. General Safety Precautions Before Operating Machine 1. Read the operators manual and the engine manual to familiarize yourself with safe operating practices before operating the machine. 2. Read the chassis operator’s manual thoroughly to familiarize yourself with safe operating practices before operating machine.
  • Page 13: Safety Features

    Sweeper Co. Safety Features This machine is equipped with many safety features. To operate this equipment safely, it is imperative to be aware of these functions. Please read all of the features listed, as the order they are presented does not reflect the degree of importance. Some safety features listed are options and MAY or MAY NOT be on your unit.
  • Page 14: Follow Safety Instructions

    Sweeper Co. FOLLOW SAFETY INSTRUCTIONS Carefully read all safety messages in this manual and on your machine safety signs. Keep safety signs in good condition. Replace missing or damaged safety signs. Be sure new equipment components and repair parts include the current safety signs.
  • Page 15: Prepare For Emergencies

    Sweeper Co. PREPARE FOR EMERGENCIES Be prepared if a fire starts. Keep a first aid kit and fire extinguisher handy. Keep emergency numbers for doctors, ambulance service, hospital, and fire department near your telephone. NEVER USE STARTING FLUID Starting fluid is highly flammable and can cause serious damage to engines.
  • Page 16: Dispose Of Waste Properly

    Sweeper Co. Check the MSDS before you start any job using a hazardous chemical. That way you will know exactly what the risks are and how to do the job safely. Then follow procedures and recommended equipment. (See your dealer for MSDS on chemical products used with this equipment.) DISPOSE OF WASTE PROPERLY Improperly disposing of waste can threaten the...
  • Page 17: Work In Ventilated Area

    Sweeper Co. Securely support any machine elements that must be raised for service work. Keep all pats in good condition and properly installed. Fix damage immediately. Replace worn or broken parts. Remove any buildup of grease, oil, or debris. Disconnect battery ground cable (-) before making adjustments on electrical systems or welding on machine.
  • Page 18: Avoid Heating Near Pressurized Fluid Lines

    Sweeper Co. AVOID HEATING NEAR PRESSURIZED FLUID LINES Flammable spray can be generated by heating near pressurized fluid lines, resulting in severe burns to yourself and bystanders. Do not heat by welding, soldering, or using a torch near pressurized fluid lines or other flammable materials.
  • Page 19: Avoid Harmful Asbestos Dust

    Sweeper Co. AVOID HARMFUL ASBESTOS DUST Avoid breathing dust that may be generated when handling components containing asbestos fibers. Inhaled asbestos fibers may cause cancer. Components in products that may contain asbestos fibers are brake pads, brake band and lining assemblies, clutch plates, and some gaskets.
  • Page 20: Diesel Fuel Storage

    Sweeper Co. DIESEL FUEL STORAGE Proper fuel storage is critically important. Use clean storage and transfer tanks. Periodically drain water and sediment from bottom of tank. Store fuel in a convenient place away from buildings. IMPORTANT: DO NOT store diesel fuel in galvanized containers. Diesel fuel stored in galvanized containers reacts with zinc coating on container to form zinc flakes.
  • Page 21 Sweeper Co.
  • Page 22: Warranty

    Sweeper Co. WARRANTY...
  • Page 23 Sweeper Co.
  • Page 24: Warranty Certificate

    Stewart-Amos Sweeper Co. reserves the right to make changes in design or to make additions to or improvements on its products previously manufactured. Stewart-Amos Sweeper Co. – WARRANTY POLICY Stewart-Amos Sweeper Co.
  • Page 25 Sweeper Co. 5. All warranty repairs reimbursable must be performed by an authorized dealer using Stewart-Amos Sweeper Co. approved replacement parts. Failure to repair properly voids future warranty.
  • Page 26: Items Not Covered By Warranty

    4. Including but not limited to normal wear parts such as brooms, drag shoes, rubber deflectors, filters, oil, fuel, chains, belts, brakes or other wear parts. 5. Items that, in the opinion of Stewart-Amos Sweeper Co. have been subject to misuse, abuse, negligence, accident or improper maintenance.
  • Page 27 Sweeper Co.
  • Page 28: General Specifications

    Sweeper Co. General Specifications...
  • Page 29 Sweeper Co.
  • Page 30: Serial Number Location

    Sweeper Co. Serial Number Location The Serial Number Identification Plate is easily found inside the cab on the driver’s side door jam. See Figure 1: below. The Serial Number must be quoted whenever ordering parts, requiring technical support, or warranty. It ensures that you are assisted as efficiently and quickly as possible. Figure 1: Serial Number Decal...
  • Page 31 Sweeper Co.
  • Page 32: Controls

    Sweeper Co. Controls...
  • Page 33 Sweeper Co.
  • Page 34: Engine Controls

    Sweeper Co. Refer to this section to quickly find out what each control does on the control panel. Do not use these controls however, until you have thoroughly read and understood the OPERATION Section. The OPERATION Section outlines how each control is to be used for safe operation. (Refer to Figure 2: Engine Control Box) The Control Box is generally located on a pedestal inside the cab.
  • Page 35 Sweeper Co. Figure 2: Engine Control Box...
  • Page 36: Sweeper Controls

    Sweeper Co. Sweeper Controls Refer to Figure 3: Sweeper Control Box 1. LH GUTTER BROOM TILT UP / DOWN – This function is used to clean out deep gutters or depressions in the sweeping surface. When the switch is pressed to the LH GUTTER BROOM TILT DOWN position, the gutter broom will pivot down on the inside of the brush plate.
  • Page 37: Hopper Up/Down

    Sweeper Co. sweep large objects out of the sweeping path that may be to large to sweep. This switch will not function unless the light in the center of the switch is on. 7. HOPPER UP / DOWN – This switch controls the hopper up and down function. To raise the hopper, press and hold the spring-loaded switch to the “HOPPER UP”...
  • Page 38: Electric Throttle

    Sweeper Co. 12. ELECTRIC THROTTLE – Available as standard equipment on SN 7980 & up. Push switch up to increase auxiliary engine rpm and down to reduce rpm.
  • Page 39 Sweeper Co. Figure 3: Sweeper Control Box to SN 4011 and up...
  • Page 40: Operation

    Sweeper Co. Operation...
  • Page 41 Sweeper Co.
  • Page 42: Chassis

    Sweeper Co. Chassis IMPORTANT: Refer to Chassis owner’s manual on all chassis related operations including regeneration instructions. Street Sweepers run at low operating speeds, therefor it is important that the regeneration procedure is understood and followed. Failure to follow these procedures may cause damage to the chassis and may affect the warranty. CAUTION: Read the chassis OWNER’S MANUAL prior to operating.
  • Page 43: Water Fill Up

    Sweeper Co. Water Fill Up (Refer to Figure 4: Water Tank) 1. The water tank can be filled with a hydrant hose at the main fill location (B). IMPORTANT: The water tank is equipped with a 3” air gap to help prevent damage to the water tank when filling from a hydrant as well as siphoning back to hydrant.
  • Page 44: Sweeping

    Sweeper Co. Sweeping 1. With the engine idling, ensure the hopper is fully lowered by depressing the HOPPER UP/DOWN switch to the “DOWN” position. 2. Run the auxiliary engine up to 2300 – 2400 rpm. This is the rpm range for normal street sweepings.
  • Page 45: Dumping

    Sweeper Co. Dumping IMPORTANT: When the hopper is full, it must be dumped before sweeping can continue. 1. Push the SWEEP switch to the centre position to stop all rotation of the gutter brooms and main broom. Then lift the brooms and elevator by depressing the BROOMS UP/DOWN switch to the “UP”...
  • Page 46 Sweeper Co. NOT A SAFE HOPPER LI FT AND/ OR DUMP ANGLE NOT A SAFE HOPPER LI FT AND/ OR DUMP ANGLE SAFE HOPPER LI FT AND/ OR DUMP ANGLE...
  • Page 47: Break-In Period

    Sweeper Co. Break-In Period Engine Break-In For engine break-in please refer to the auxiliary engine Operator’s Manual. Sweeper Break-In After the first 8 hours of operation. 1. Check and tighten: a. Suspension bolts b. Main broom coupler c. Broom bolts d.
  • Page 48: Winterizing Your

    Sweeper Co. Winterizing Your Sweeper 1. Remove dust suppression water filter, allow as much water as possible to drain from the system and replace water canister without filter. 2. Remove water line coming from the tank at the filter. 3. With water pump running, pressurize the filter housing by using compressed air. This removes water from the pump and lines preventing the water from freezing and rupturing water lines or the pump.
  • Page 49: Service

    Sweeper Co. Service Fuel, Lubricants, and Coolants Diesel Fuel (Refer to the original engine manufacturer's recommendations). Use ASTM No. 2-D grade fuel when outside air temperature is above 50 C (40º F). Use ASTM No. 1-D grade diesel fuel when outside air temperature is below 5º C (40º F). IMPORTANT: Do NOT use fuel that is contaminated by water and dirt! WARNING: Be careful when handling fuel! Never fill the tank when the engine is hot or running! Do not smoke while filling the fuel tank!
  • Page 50: Grease

    Sweeper Co. CAUTION: The entire hydraulic oil system must be of the same viscosity grade. Grease The recommended grease for this sweeper is EP 2 multipurpose grease. Lubrication and Maintenance IMPORTANT: Maintenance includes inspection and replacement of worn parts as required. WARNING: Before servicing the sweeper follow a proper Equipment Lockout procedure as described in the Safety section.
  • Page 51: Every 40 Hours

    Sweeper Co. 1. Air Filter 5. Engine Oil Dipstick 2. Fuel Filter 6. Engine Oil Fill Cap 3. Fuel Primer Pump 7. Coolant Fill Cap 4. Engine Oil Filter 8. Engine Oil Fill Cap Figure 5: Service Locations on Auxiliary Engine Every 40 Hours 1.
  • Page 52: Every 500 Hours

    Sweeper Co. Every 500 Hours 1. Replace the hydraulic oil filter. 2. Replace the hydraulic oil breather filter. NOTE: It is advised to use only factory replacement oil filters. All replacement filters must meet or exceed 10 micron absolute rating. Failure to meet or exceed these specifications will void the warranty.
  • Page 53: Adjustments

    Sweeper Co. Adjustments Gutter Broom Angle Adjustments (Refer to Figure 6: Gutter Broom Assembly) also (Refer to Figure 7: Gutter Broom Pattern) The proper tilt angle must be maintained for effective sweeping. If the broom is set too flat, it will tend to throw debris back to the curb.
  • Page 54: Gutter Broom Pressure

    Sweeper Co. Gutter Broom Pressure Proper broom pressure is very important. Low broom pressure will cause poor sweeping. High broom pressure will cause excessive broom wear. IMPORTANT: Be sure gutter broom angle is correct before setting gutter broom pressure. Correct Gutter Broom Pressure 1.
  • Page 55: Gutter Broom Impact Protection Spring

    Sweeper Co. Gutter Broom Impact Protection Spring (Refer to Figure 6: Gutter Broom Assembly) also (Refer to Figure 7: Gutter Broom Pattern) Each gutter broom is equipped with an impact protection spring (A) to protect it from side impact damage. There is no adjustment for this spring. NOTE: The wider the sweeping path the greater the possibility of damaging the broom linkages from impacts.
  • Page 56 Sweeper Co. Figure 6: Gutter Broom Assembly...
  • Page 57 Sweeper Co. Figure 7: Correct Broom Pattern...
  • Page 58: Main Broom Pressure

    Sweeper Co. Main Broom Pressure (Refer to Figure 8: Main Broom Assembly) The main broom pressure is controlled by the tension on the suspension spring (F) while the shock absorber (E) applies down pressure. To adjust the down pressure: 1. Loosen the lock nut on turnbuckle (D). 2.
  • Page 59: Elevator Chain Adjustment

    Sweeper Co. Elevator Chain Adjustment Upper Drive Shaft (Refer to Figure 13: Elevator) 1. Loosen bolts (C). 2. Loosen lock nut (E). 3. Tighten adjustment bolt (D). NOTE: Bottom shaft and bearings (P) should never require adjusting. This shaft is preset at the factory.
  • Page 60 Sweeper Co. Refer to Figure 9: Elevator Chain Adjustment...
  • Page 61 Sweeper Co.
  • Page 62: Repair And Maintenance

    Sweeper Co. REPAIR MAINTENANCE...
  • Page 63 Sweeper Co.
  • Page 64: Maintenance Filter Cross Reference

    Sweeper Co. Maintenance Filter Cross Reference ZING Filter Manufacturer KUBOTA DONALDSON FRAM CARQUEST BALDWIN small hyd. oil filter P551551 P1653A 85259 BT839-10 AE-10 V2403 engine oil HH164-32430 P550939 PH7328 85307 B7152 outer air filter P822768 CA9246 88489 RS3988 inner air filter P822769 CA9246SY 88490...
  • Page 65: Main Broom Bearing Replacement

    Sweeper Co. Figure 10: Main Broom Assembly Main Broom Bearing Replacement (Refer to Figure 11: Main Broom Arm Assembly) 1. Lower the main broom fully to the shop floor. 2. If the bearing has an Eccentric Locking Collar, loosen the set screws (C) and tap the collar in the reverse direction of the shaft rotation, using a punch and hammer to unlock the Collar and bearing assembly (B) from the shaft (F).
  • Page 66 Sweeper Co. Figure 11: Main Broom Arm Assembly...
  • Page 67: Carbide Drag Shoe Replacement

    Sweeper Co. Carbide Drag Shoe Replacement (Refer to Figure 12: Carbide Drag Shoe) 1. Raise the main broom. 2. Remove bolts (B) and worn drag shoe (C). 3. Install new carbide drag shoe and bolts (B). Figure 12: Carbide Drag Shoe Elevator Chain, Sprocket/Shaft Replacement (Refer to Figure 13: Elevator) 1.
  • Page 68 Sweeper Co. 5. Loosen lock nut (E). 6. By adjusting bolt (D), move the top shaft slide (A) down closer to the middle of elevator housing until bearing bolts are at the bottom of the travel. 7. Loosen the bolts on bearing (H). 8.
  • Page 69 Sweeper Co. Figure 13: Elevator...
  • Page 70: Bottom Liner Replacement

    Sweeper Co. Bottom Liner Replacement 1. Drive machine up on blocks ensuring machine is secure before going under machine. 2. Remove bolts that hold liner in place. 3. Remove liner. 4. Remove bottom rubber and install on new liner. 5. Reinstall liner. Top Liner Replacement 1.
  • Page 71: Gutter Broom Hydraulic Motor Replacement

    Sweeper Co. Gutter Broom Hydraulic Motor Replacement 1. Lower gutter broom to floor. 2. Remove one segment from the gutter broom plate. 3. From underneath remove center mount retaining bolt. 4. Remove bolts from taper lock bushing. 5. Put bolts that are removed from the bushing into the threaded holes in bushing. 6.
  • Page 72: Hydraulic Pressure Adjustment

    Sweeper Co. Hydraulic Pressure Adjustment (for RH VALVE STACK (Passengers Side)) (set pressure to 2,850 psi @ 2 000 rpm) 1. Install a 0-5000 psi pressure gauge in test port A on top of valve. 2. Remove cap from the relief valve. 3.
  • Page 73 Sweeper Co. (for LH VALVE STACK (Driver Side)) (set pressure to 2,350 psi @ 2 000 rpm) 1. Install a 0-5000 psi pressure gauge in test port A on top of valve. 2. Remove cap from the relief valve. 3. Take engine to 2,000 rpm. 4.
  • Page 74: Electrical Activation Sequences At Valve Connectors

    Sweeper Co. Electrical Activation Sequences At Valve Connectors...
  • Page 75 Sweeper Co.
  • Page 76: Lubrication And Maintenance Check List

    Sweeper Co. Lubrication Maintenance Check List...
  • Page 77 Sweeper Co.
  • Page 78: Every 10 Hours

    Sweeper Co. EVERY 10 HOURS STARFIRE SWEEPER DAILY MAINTENANCE CHECKLIST Perform this routine BEFORE every shift or after 10 hours of operation (whichever is sooner) Sweeper S/N: Date: Hours: Miles: This CHECKLIST PERFORMED BY: Done: The OPERATOR has READ and THOROUGHLY UNDERSTANDS the "Safety, Operations and Maintenance Manual"...
  • Page 79 Inspect for any damage and any loose items such as wires,  fittings, pins, nuts and bolts. Correct problem and/or NOTE below.  NOTES and REMARKS:      Thank you for choosing Stewart-Amos Sweepers! HAPPY SWEEPING!!! ...
  • Page 80: Every 40 Hours

    Service truck chassis - refer to Owners Manual. Inspect for any damage and any loose items such as wires,  fittings, pins, nuts and bolts. Correct problem and/or NOTE below.  NOTES and REMARKS:     Thank you for choosing Stewart-Amos Sweepers! HAPPY SWEEPING!!! ...
  • Page 81: Every 250 Hours

    Clean hydraulic oil tank breather filter. Inspect for any damage and any loose items such as wires,  fittings, pins, nuts and bolts. Correct problem and/or NOTE below.  NOTES and REMARKS:     Thank you for choosing Stewart-Amos Sweepers! HAPPY SWEEPING!!! ...
  • Page 82: Every 1000 Hours

    Check elevator chain for adjustment. Inspect for any damage and any loose items such as  wires, fittings, pins, nuts and bolts. Correct problem and/or NOTE below.  NOTES and REMARKS:     Thank you for choosing Stewart-Amos Sweepers! HAPPY SWEEPING!!! ...
  • Page 83 Sweeper Co.
  • Page 124 Sweeper Co.
  • Page 131 H GUTTER BROOM UP LH GUTTER H GUTTER BROOM BROOM ELEVATOR STALL WARNING...
  • Page 133 H SWEEP H GB RETRACT H GB H GB H GB EXTEND RH SWEEP H SWEEP...
  • Page 137 Decals S-4 DECAL CHARTS To Order: CALL toll free: 800-482-2302 Call Direct: 717 901-5600 [7am to 5pm eastern] Send Fax: 717-901-2326 [24/7/365] Email: parts@stewart-amos.com...
  • Page 138 PT # 43201 8/UNIT PT # 43205 4/UNIT...
  • Page 139 PT # 43207 4/UNIT PT # 43211 4/UNIT PT # 43213 1/UNIT...
  • Page 140 PT # 43215 4/UNIT PT # 43217 2/UNIT...
  • Page 141 PT # 43219 1/UNIT PT # 43221 1/UNIT...
  • Page 142 PT # 43223 4/UNIT PT # 43225 1/UNIT PT # 43227 2/UNIT...
  • Page 143 PT # 43229 7/UNIT PT # 43231 2/UNIT PT # 43233 2/UNIT...
  • Page 144 PT # 43235 1/UNIT PT # 43237 1/UNIT PT # 43239 1/UNIT...
  • Page 145 PT # 43244 1/UNIT PT # 43245 1/UNIT...
  • Page 146 PT # 43247 2/UNIT PT # 43264 2/UNIT...
  • Page 147 PT # 43248 2/UNIT PT # 43249 1/UNIT PT # 43246 1/UNIT...
  • Page 153 STARFIRE LOGO DECAL REAR CANOPY LH STARFIRE LOGO REAR CANOPY 43247 DOORS RH STARFIRE LOGO REAR CANOPY 43264 DOORS LH S-4 STARFIRE DECAL REAR CANOPY 43248 DOOR RH S-4 STARFIRE DECAL REAR CANOPY 43249 DOOR 43243 STEWART-AMOS SWEEPER CO. 43254 Lg STEWART-AMOS DECAL...
  • Page 154 INDEX 1075 200 GAL. PLASTIC WATER TANK 1843 BOLT 1116 HYDRANT HOSE 1861 DOOR STOP SPRING 1143 FENDER 1916 STROBE 1502 1955 HYD. COOLER & FAN 1503 41503 DOOR 1505 41504 SPACER 1534 BOLT 42107 LIMB GUARD 1535 BOLT 91501 FRONT CANOPY 1537 BOLT...
  • Page 155 1520 WASHER 1173 CHAIN 2-6" 1522 WASHER 1185 BUSHING 1579 BOLT 1501 1750 INSERT 1520 WASHER 1530 BOLT 1505 1558 BOLT 1506 1560 BOLT 1507 1579 BOLT 1508 1583 1526 WASHER 1934 BIN VIB. 1537 BOLT 32910 DRAIPER MOUNT 1540 BOLT 32911 DRAIPER RUBBER...
  • Page 156 1022 TURN BUCKLE 1670 WASHER 1023 TURN BUCKLE 1683 OFFSET KEY 1042 QUICK LINK 1822 WASHER 1185 BUSHING 3229 OPTIONAL GB BRUSH (SET FOR 61307) 1379 CYLINDER 3243 MOTOR 1503 3248 BUSHING 41207 MOTOR BRACKET (LEFT) 1501 41209 DRIVER HUB 1502 41227 32"...
  • Page 157 41437 DRAG SHOE LIFT CHAIN 1440 HOSE-HOPPER TILT VALVE TO CROSS 62813 WASHER 1440 HOSE-HOPPER TILT VALVE TO CROSS 80129 MAIN BROOM COUPLER 1441 HOSE-HOPPER TILT ROD TO CROSS 91405 LIFT BELL CRANK (RIGHT) 1442 HOSE-HOPPER TILT HEAD TO CROSS 91406 LIFT BELL CRANK (LEFT) 1443...
  • Page 158 1156 EXHAUST PIPE 1571 WASHER 1175 RAIN CAP 1577 BOLT 1176 MUFFLER 3243 HYDRAULIC MOTOR 1260 CLAMP 43107 SEPARATOR 1299 THROTTLE GUIDE 43113 TOP SHAFT 1387 THROTTLE ACTUATOR 43115 SPACER 1388 THROTTLE ACTUATOR CABLE 43123 GUIDE 1390 ENGINE OUTER AIR FILTER 43125 SLIDE 1391...
  • Page 159 1505 121 12 2041 FUSE HOLDER 1545 BOLT 121 12 2042 FUSE 15 AMP F1-5/7/8 1782 BOLT 2043 CIRCUIT BRAKER 41441 62507 AUX. BOX MOUNTING PLATE 41764 SWIVEL SHAFT 62508 REAR LIGHT HARNESS 41764 PIVOT SHAFT MOUNT 62511 SWITCH BOX 62813 WASHER 62506...
  • Page 160 1005 DOOR LATCH 1005 DOOR LATCH 1005 DOOR LATCH 1014 MAIN BROOM MANDREL 1016 MAINBROOM STRIP SET 1018 SUSPENSSION SPRING 1019 RETRACT SPRING 1020 BUSHING 1022 TURN BUCKLE 1023 TURN BUCKLE 1024 BACKUP ALARM 1030 BEARING 1030 BEARING 1031 HINGE 1031 HINGE 1031...
  • Page 161 1137 HOSE 1138 HOSE 1139 GREASE FITTING 1140 FITTING 1141 BULKHEAD FITTING 1142 1143 FENDER 1147 BOLT 1148 GB BUSH SET FOR 32" PLATE 1149 SHAFT KEY 1154 EXHAUST CLAMP 1155 HOSE CLAMP 1156 EXHAUST PIPE 1158 HOSE BARB FITTING 1159 BALL VALVE 1160...
  • Page 162 1295 GUTTER BROOM MOTOR & DUMP VALVE 104 1299 THROTTLE GUIDE 1371 HOSE BARB FITTING 1372 ADAPTER 1373 HOSE BARB FITTING 1374 HOSE BARB FITTING 1375 CLEAR TUBEING 123 48" 1376 CLAMP 1377 FLOAT 1379 CYLINDER 1379 GB CYLINDER 1387 THROTTLE ACTUATOR 1388 THROTTLE ACTUATOR CABLE...
  • Page 163 1501 1501 1501 1501 119 84 1501 1502 1502 1502 117 50 1503 1503 1503 1503 1503 101 10 1503 115 12 1503 119 70 1505 1505 1505 1505 1505 113 32 1505 1505 121 12 1505 1506 1506 1506 115 24 1507 1508...
  • Page 164 1534 BOLT 1534 BOLT 1535 BOLT 1535 BOLT 117 24 1537 BOLT 1537 BOLT 1537 BOLT 1537 BOLT 1537 BOLT 1537 BOLT 119 28 1540 BOLT 1540 BOLT 1540 BOLT 115 12 1541 BOLT 119 42 1545 BOLT 1545 BOLT 1545 BOLT 1545...
  • Page 165 1640 1642 1669 WASHER 1670 WASHER 1670 WASHER 1670 WASHER 1670 WASHER 1670 WASHER 1671 WASHER 1680 1683 OFFSET KEY 1683 1684 SWITCH (S-0-S) 1685 SWITCH (S-O-M) 1686 SWITCH (M-O-M) 1689 HOLE PLUG 1691 COURTESY LIGHT 1711 BOLT 117 14 1713 BOLT 1750...
  • Page 166 1911 BACKUP LIGHT 1912 GROMMET 1915 WORK LIGHT 1915 WORK LIGHT 1916 STROBE 1916 STROBE 1934 BIN VIB. 1946 RELAY 1947 RELAY 1955 HYD. COOLER & FAN 1955 ELECTRIC HYD. OIL COOLER 1985 CYLINDER 1985 HOPPER TILT CYLINDER 1986 ELEV/DRAG SHOE CYL. 1987 HYDRAULIC OIL FILTER 1987...
  • Page 167 3243 HYDRAULIC MOTOR 3243 HYDRAULIC MOTOR 3243 HYDRAULIC MOTOR 3248 BUSHING 3251 HYDRAULIC PUMP 9137 LANYARD 9138 DISCONNECT SWITCH 9185 130 GAL. PLASTIC WATER TANK 32910 DRAIPER MOUNT 32911 DRAIPER RUBBER 34501 MB LIFT ARM (LEFT) 34502 MB LIFT ARM (RIGHT) 41205 LINKAGE MOUNT (LEFT) 41207...
  • Page 168 41771 REST TUBE 41772 BOTTOM RUBBBER 41776 RUBBER SEAL 42060 REAR SKIRT 42065 WATER VALVE 42067 DIRT DEFLECTOR RUBBER 42073 SKIRT 42075 BASE STRIP 42077 BEARING INSPECTION COVER 42081 WATER VALVE LEVER 42083 WATER VALVE ROD 42085 SAFETY PROP 42101 CENTER DRAG RUBBER 42103 CENTER DRAG SUPPORT...
  • Page 169 43125 SLIDE 43127 ADJUSTMENT ANGLE 43129 ELEVATOR CENTERING BUSHING 43131 CANOPY EXTENTION 43134 CHAIN GUARD 43135 COVER 52303 HYDRAULIC TANK 61201 GB MOUNT (LEFT) 61203 GB PIVOT (LEFT) 61213 61235 RETRACT PLATE (LEFT) 61301 GB MOUNT (RIGHT) 61303 GB PIVOT (RIGHT) 61307 OPTIONAL 42"...
  • Page 170 92402 AUX. BOX MOUNT 92403 WATER PUMP PLATE 92801 UPPER SCISSOR ROLLER 92806 LOWER SCISSOR ROLLER 92811 UPPER ANCHOR LEG #1 92812 UPPER ANCHOR LEG #2 92813 UPPER ANCHOR LEG #3 92814 UPPER ANCHOR LEG #4 92815 LOWER ANCHOR LEG #1 92816 LOWER ANCHOR LEG #2 92817...
